Congratulations. You have made a wise choice in selecting

the Tower Easy Tote for your field box.

We have engineered this kit to be simple to assemble and

provide enough space to hold everything you need to go fly-

ing without being overly bulky.

Hook

Loop

G G

Parts List

Part A (1)

Part G (1)

Part B (1)

Part H (1)

Part C (1)

Part I (1)

Part D (1)

Part J (2)

Part E (1)

Part L (1)

Part F (2)

Part M (1)

Hardware (not pictured)

Rubber Feet (4)

Drawer Knob (1)

3x12mm Wood

2.6x10mm Wood

Screws (4)

Screws (2)

Cradle Padding

Handle

Decal

Wood Handle (1)

Decals (3)

Cradle Padding

Material (1)

Hook & Loop

Material (2)

3mm Washers (5)

3x10mm Wood

Screw (1)

EASY TOTE

A COMPACT, EASY TO ASSEMBLE FLIGHT BOX

The parts practically hold themselves together without glue, so

you can "dry fit" all the parts to make sure you have everything

in the proper place. Please note that the parts will only fit

together one way, eliminating the chance of error.

When properly assembled and fuel proofed, your Easy Tote

should provide many years of flight line service.

Tools and Items Needed for Assembly:

Medium and Fine Sandpaper.

Hobby Knife & #11 Blade (TOWR1010).

Hobbico

Drill with 1/8" [3mm] and 3/32" [2.4mm] drill bits.

Fuelproof paint or finishing resin.

Choice of Adhesives:

We assembled our Easy Tote

field box using Thick Great

Planes

Pro

(GPMR6015). You may use

this product or 30-Minute

Tower Hobbies BUILD-IT

Epoxy

(TOWR3811),

Great Planes Pro Wood Glue

(GPMR6160). Please note that if you are using epoxy or wood

glue you will need to tape the pieces into place with the prop-

er alignment and wait for the glue to dry.

Specification & Description Changes:

All pictures, descriptions and specifications found in this

instruction manual are subject to change without notice.

Tower Hobbies maintains no responsibility for inadvertent

errors in this manual.

Builders Triangle (HCAR0480).

glue

™

Need help?

Do you have a question about the EASY TOTE and is the answer not in the manual?

Questions and answers

Summary of Contents for Tower Hobbies EASY TOTE

Page 1 We have engineered this kit to be simple to assemble and provide enough space to hold everything you need to go fly- When properly assembled and fuel proofed, your Easy Tote ing without being overly bulky. should provide many years of flight line service.
Page 2 3. Part E is the front of the shelf assembly. Again align the tabs and use a flat surface to firmly hold the assembly in place 6. Part H is the backside of the Easy Tote. Test fit this part on part E as you glue the completed shelf assembly together.
Page 3 Finishing Your Tower Hobbies Easy Tote We strongly suggest that you fuelproof your new field box. You may finish your Easy Tote using a number of methods. You can paint it in your favorite color. Making sure you use a paint that...
Page 4 12. Your Easy Tote Kit includes three colorful Tower 14. Your kit is supplied with hook and loop material to hold Hobbies decals. If you decide to utilize these, apply them your fuel container in place. Locate this material and two now.
