Quick Start Guide
Step 1
Design your fence
Have the local utility companies mark your under-
ground lines. On a sheet of paper, draw your house
and yard. Draw a line around your property that
represents the containment area for your dog.
Step 2
Install the wall-mount transmitter
Most people find that the inside of an exterior wall of
a garage or basement is ideal. From the sample lay-
outs included, you can see the twisted wire running
from the house attaches directly to the transmitter.
Step 3
Layout the fence wire
Run the containment wire around the property as
outlined in your plan.
Step 4
Final connections
Splice the containment loop wires to the twisted
wire using the supplied waterproof splices.
Connect the other end of the twisted wire to the
wall-mount transmitter. Plug the AC adapter,
connect it to the transmitter and turn it on. The
red light should illuminate on the transmitter
indicating a successful loop.
Step 5
Power Up
Install batteries positive side out as shown.
1
Boundary
Wire
10'
90°
10'
Boundary Wire
Splice
To wall-mount transmitter
Advertisement
Table of Contents
Summary of Contents for Intellipet ZW18900-05
- Page 1 Quick Start Guide Step 1 Design your fence Boundary Wire 10’ Have the local utility companies mark your under- ground lines. On a sheet of paper, draw your house 90° and yard. Draw a line around your property that represents the containment area for your dog. 10’...
- Page 2 Quick Start Guide continued Step 6 Test your fence Set your FIELD WIDTH ADJUSTMENT KNOB to the number 2 position. Using the supplied test light, walk the dog’s collar up to the fence wire. Listen for the warning tone and look for the test light to light. Try a number of different places around the fenced area, in order to verify the range is consistent.
-
Page 3: Important Safety Information
• Risk of electric shock. Use the Fence Transmitter indoors in a dry location only. Risk of injury. Wire on top of the ground may be a trip hazard; Place wires carefully. CAUTION This Intellipet ™ In-Ground Dog Fence is not a solid barrier. This system is designed to act as a deterrent CAUTION to remind pets by Static Stimulation to remain in the boundary established. -
Page 4: Limited Warranty
You may need to trim the hair in the area of the probes. Never shave the dog’s neck; this may lead to a CAUTION rash or infection. • The Collar Receiver should not be on your dog when the system is tested. Your pet may receive an unintended correction. - Page 5 Enhanced attempt to leave the yard. lightning protection is available for the in-ground dog Fitting the collar on your dog. fence by calling Intellipet ™ at 1-800-638-5754. The collar strap should fit snugly towards the top of your Lightning damage is not covered under your product dog’s neck with the collar receiver box on the bottom of...
- Page 6 Hourglass Loop Step 1 Design your fence Allows your dog to be contained in either the front or back yard but not around the side of the house. When the wire runs parallel to itself, as it goes toward the side •...
- Page 7 Customized Loops Step 2 Install wall transmitter You can create off limit areas, such as pools and gar- dens by encircling the area with wire. Run twisted wire from the fence loop to the encircled area and splice the ends together. 1.
-
Page 8: Important Tips
Step 3 Layout fence wire With the transmitter installed and the hole drilled for the IMPORTANT TIPS! wire, you can position the boundary wire that will form your fence. DO NOT bury the wire until you are sure that • DO NOT run wire within 10 feet or parallel to cable the system is running properly. - Page 9 Step 5 Step 4 Power up Final connections 1. Splicing to the boundary wire. 1. Install batteries. Pull the twisted wire to the perimeter location of the two Unscrew collar battery cap turning counter clockwise. ends of your boundary wire loop. Splice the ends of the Insert battery with the + facing out toward the battery twisted wire to the ends of the boundary wire with the cap.
- Page 10 Step 6 Step 7 Test your fence Bury your wire You should have your boundary wire laid out and proper- You may need the following tools for efficient installation: ly connected. DO NOT test the system on your dog. Straight edge spade or a gas powered edger. If you plan on running the wire across a driveway you may also need 1.
- Page 11 Step 8 Train your dog Follow the training steps outlined in the Training and Troubleshooting Guide. You may see your dog respond immediately to the training, however continue to follow the Training Guide to fully train your dog. The conven- ience that your new fence offers, plus the added safety for your dog are well worth the time invested.
- Page 12 IN-GROUND DOG FENCE TRAINING AND TROUBLESHOOTING GUIDE TRAINING Lesson 1: The Retreat Pattern To get the most out of your containment system, keep The goal for day 1 is to introduce your dog to the these tips in mind: boundary and to help him understand he/she should retreat when he/she hears the warning sound.
-
Page 13: Troubleshooting
Lesson 4: Off Leash Supervision Lesson 6: Removing the Flags After several sessions of distractions, your dog should After 2 weeks of successful unsupervised containment, be ready for off-leash play. You must stay in the yard for you can begin removing the flags. Start by removing off-leash training. - Page 14 TEST LOOP INSTRUCTIONS 5. Insert the RF Choke 1. Cut a piece of wire at least and boundary wire INDICATOR LIGHT 10 feet long (test loop). leads into the loop SMART DOG Field Width 2. Remove the boundary wires terminals on the from the transmitter.
- Page 16 © Top Pets Products Beverly, MA 01915 1-800-638-5754 400-1246...
