PRESENCE DETECTOR PD-2210HF
This manual is not to be used for
matters.
A Warning is given for installation of this detector
without proper technique knowledge.
Basic knowledge before projection is to be collected
from the handbook "Presence Detection" (Art. No.
35100 )
Introduction
1.
PD-2210HF is a detector for presence detection with
double detection technology. It is using passive
infrared detection and acoustic detection. The
acoustic detector senses only a limited frequency
range between about 3 and 7 kHz.
The IR-detector has a very sensitive dual-element,
low-noise pyroelectric
software in PD-2210HF microprocessor is specially
constructed for presence detection.
Software will analyse the signal from the pyroelectric
detector and measure noise level and signal power and
sum of pulses. Counting the pulses is a slower method
that detects presence in a locality with low activity with
week signals as a result.
With a switch you can alter the signal process to be
adapted to premises with high or low activity.
Another part of the software analyse the sound level.
A build in photocell can be used for blocking the
switching light on function when there is enough daylight.
The lens in the detector, collects heat radiation from
different fields, in to the sensor element. There are
several different lenses for different type of premises
(office, corridor, and culvert a.s.o)
When a person passes cross over one field, there will
be a strong signal in the sensor element. When one
moves along the field (away from or toward the
Extronic AB • Tel: 08-771 26 00
Installation instructions
Art. No. 13136
projection
detector. Electronics
detector) in its direction, will also a signal occur, but
weaker.
The detector should therefor be placed so one passes
across (90º) through the lens field. Corner placing of
the detector is more or less always the most optimal.
(See handbook for "Presence Detection" for placing
advice)
2. Connection – Adjustment.
Opening of the front.
The cover opens in the
middle at the
underneath
screwdriver that turns.
See picture!
and
Terminals
Walking test diode
HF detection, green
HF-
detection
jumper
Activity
jumper
Detector
element
Photocell
Relay
Relay; NO (Normal Open), C (Closed), C (Common),
NC (Normal closed).
Change over contacts. At detecting C and NO close.
After chosen time laps, contact C and NO in relay
open.
1
Lens E-51
168 field in 7 layers
Detection is
best when
crossing the
fields.
top or
with a
LED Selector,
Walking test diode
walking test
HF detection, green
LED Ind.
5m
On 2,5m 10m
MIK.
Off
Time
2 s 20m
HF IR
PD-2210HF
Yes IR-
sens.
No
(Cont.)
(No Start)
High
Low/Office
HF-
sound
+10 sens.
+5
Up
0
Photocell
Down
-5
-10
-15
-20 Off
Pattern
Degrees
NO C NC - 12V + TP
NO C NC + TP
PD-2210HF
Low detection
when moving
along the
fields.
Adjustment of:
- TIME Delay
- Sensitivity, IR
- Sensitivity, HF
- Photocell
Light level
08 04 29
