, packaging , an d t hi s owner s m anual . G04865W Y ou r Mode l Numbe r 2 - G04865W - - HL Dat e Cod e...
Page 2
IMPORTANT! READ EACH STEP IN THIS MANUAL BEFORE YOU BEGIN THE ASSEMBLY. FOUR ADULTS ARE REQUIRED TO ASSEMBLE THIS TOP SHELF 90” AIR HOCKEY TABLE Tools Required: T1 - Allen Wrench (Included) Phillips Screwdriver Furniture Polish and Cloth Assembly Tips Make sure you understand the following tips before you begin to assemble your hockey table.
Page 3
List H1 = 28 pcs H2 = 32 pcs H3 = 4 pcs H4 = 16 pcs 8 mm x 35 mm 8.5 mm x 22 mm 8 mm x 28 mm 4 mm x 45 mm Phillips Flat Allen Head Bolt Flat Washer Allen Head Bolt Head Screw...
Page 4
s List P1 = 1 pc P3 = 2 pcs P4 = 2 pcs P2 = 2 pcs Air Hockey Left Leg Right Leg End Apron Table Cabinet P5 = 1 pcs P6 = 1 pcs P7 = 2 pcs P8 = 2 pcs Side Apron Side Apron with...
Page 5
PARTS REQUIRED: P1 Air Hockey Table Cabinet 12 pcs - H2 8.5 x 22mm Flat Washer 2 pcs - P2 Left Leg 2 pcs - P3 Right Leg H1 8 x 35mm Allen Head Bolt 12 pcs - 1 pc - T1 Allen Wrench STEP:1 Leave Air Hockey Table Cabinet (P1) face down in carton to assemble.
Page 6
PARTS REQUIRED: 16 pcs - H1 8 x 35mm Allen Head Bolt 20 pcs - H2 8.5 x 22mm Flat Washer 4 pcs - H4 4 x 45mm Philips Flat Head Screw 2 pcs - P7 End Leg Panel 4 pcs - H3 8 X 28mm Allen Head Bolt 2 pcs - P8 Side Leg Panel...
Page 7
PARTS REQUIRED: H8 3.5x 33mm Philips Round Head Screw 4 pcs - H4 4 x 45mm Philips Flat Head Screw 12 pcs - 8 pcs - 1 pc - P6 Side Apron with ON/OFF Slot H5 3.5 x 12mm Philips Round Head Screw 2 pcs - P4 End Apron 1 pc - P5 Side Apron 4 pcs - P11 Corner Post...
Page 8
PARTS REQUIRED: 2 pcs - H6 3.5 x 14mm Philips Flat Head Screw 1 pc - C1 ON/OFF Switch STEP:4 Install ON/OFF Switch (C1) onto inside of Side Apron with ON/OFF Slot (P6) using pre-drilled holes with Philips Flat Head Screws (H6) as shown in FIGURE 4. Tighten, but do not strip out Screws (H6).
Page 9
PARTS REQUIRED: H7 3.5 x 18mm Philips Round Head Screw P12 Scorer Console 2 pcs - 1 pc - STEP:5 With the help of at least four other adults, carefully lift and rotate table into upright position. First,feed the Scorer Console (P12) plug down through the hole on one side of the long top rail as shown in FIGURE 6.
Page 10
Congratulations! You have now assembled your Hockey Table. Please note the Care and Use instructions below to ensure many years of trouble free use of your Hockey Table. NOTE: Use A8 and A9 Shim packs alone with a carpenter’s level to level table. CARE AND USE OF YOUR HOCKEY TABLE .
Page 11
ELECTRICAL CONNECTIONS & SPARE PARTS DRAWINGS - ON/OFF To Wall Switch Outlet - Junction Box C2-A/C Adapter C11 Red LED Goal C4 Right LED Lights C13 Air Blower C12 Blue LED Goal C10 Right Sensor C4 Left LED Lights C10 Left Sensor -Scorer Console PRODUCT PARTS LIST MODEL: G04865...
Page 12
Replacement of LED Light Rail STEP ONE : STEP TWO : Remove Corner Caps (C5) from the table top rail. Unscrew Bolts (C7) and slide Side Top Rail (C6) from Air Hockey Table Cabinet (P1). And then unplug the Lighting LED Rail (C4). STEP THREE : Unscrew Screws (C8), and separate Lighting LED Rail (C4) from each other.
Page 13
LED PUCK BATTERY CHANGE INSTRUCTION STEP ONE: STEP TWO: IF BATTERY HOLDER BRACKET Remove screws and back Remove CR2016 Lithium MOVES, RE-INSTALL IT TO LED PUCK AS SHOWN IN DIAGRAM. cap from LED Puck using Small Battery 3V from LED Puck. Phillips Screwdriver (not provided).
Page 14
y ESCALADE P " . ) " l a i l l a v i t 888-996-2729 ® l l i l i a gameroom Other than shipping requirements, no charge will be made for such replacement of in-warranty products. o l l e i l l a i...
