November 1, 2012
Lit. No. 43991, Rev. 01
Low-Profi le Tailgate Spreader
94444
LP-8
Owner's Manual
Original Instructions
CAUTION
Read this manual before installing or
operating the spreader.
This manual is for BLIZZARD
LP-8 Tailgate Spreaders with serial numbers
®
beginning with 090324 and higher.
This manual supersedes all editions with an earlier date.
Advertisement
Table of Contents
Related Manuals for Blizzard LP-8
Summary of Contents for Blizzard LP-8
- Page 1 Owner's Manual Original Instructions CAUTION Read this manual before installing or operating the spreader. This manual is for BLIZZARD LP-8 Tailgate Spreaders with serial numbers ® beginning with 090324 and higher. This manual supersedes all editions with an earlier date.
-
Page 3: Spreader Owner Data Sheet
SPREADER OWNER DATA SHEET Register your spreader online at www.blizzardplows.com Owner Name: ______________________________________________________________________________ Date Purchased: ____________________________________________________________________________ Dealer Name: ______________________________________________ Phone: _________________________ Dealer Address: _____________________________________________________________________________ Vehicle Model/Year: _________________________________________________________________________ Spreader Type/Size (Model): _________________________________________ Weight: ______________ lb/kg Spreader Serial Number:______________________________________________________________________ Lit. No. 43991, Rev. 01 November 1, 2012... -
Page 5: Table Of Contents
TABLE OF CONTENTS SPREADER OWNER DATA SHEET ......3 REMOVING THE SPREADER ......... 16 PREFACE ..............6 Receiver Mount ........... 16 SAFETY INFORMATION ..........7 Removing the Spreader ....... 16 Safety Defi nitions ..........7 SWING AWAY Mount .......... 16 Safety Precautions .......... -
Page 6: Preface
PREFACE This manual has been prepared to acquaint you with When service is necessary, bring your spreader to the safety information, operation and maintenance of your local dealer. They know your spreader best and your new spreader. Please read this manual carefully are interested in your complete satisfaction. -
Page 7: Safety Information
SAFETY INFORMATION SAFETY DEFINITIONS WARNING Do not install the control for this product in WARNING the deployment path of an air bag. Refer to vehicle manufacturer's manual for air bag Indicates a potentially hazardous situation deployment area(s). that, if not avoided, could result in death or serious personal injury. -
Page 8: Fuses
SAFETY INFORMATION FUSES VENTILATION The electrical system contains automotive blade-style WARNING fuses. If a problem should occur and fuse replacement Vehicle exhaust contains lethal fumes. is necessary, the replacement fuse must be of the Breathing these fumes, even in low same type and amperage rating as the original. -
Page 9: Torque Chart
SAFETY INFORMATION TORQUE CHART CAUTION Read instructions before assembling. Fasteners should be fi nger tight until instructed to tighten according to torque chart. Use standard methods and practices when attaching spreader including proper personal protective safety equipment. Recommended Fastener Torque Chart (ft-lb) Torque Size... -
Page 10: Warning And Caution Labels
SAFETY INFORMATION WARNING/CAUTION LABELS Please become familiar with the Warning and Caution labels on the spreader. NOTE: If labels are missing or cannot be read, see your sales outlet. Warning Label (receiver mount only) Caution Label (both sides, SWING AWAY mount only) ®... -
Page 11: Serial Number Label
SAFETY INFORMATION SERIAL NUMBER LABEL Code Defi nition 2-Digit Year ############################## 2-Digit Month 2-Digit Day 2-Digit Location Code YYMMDDLLXXXXZZZZZ XXXX 4-Digit Sequential Number ZZZZZZ 5–7-Digit Assembly PN YYMMDDLLXXXXZZZZZ Lit. No. 43991, Rev. 01 November 1, 2012... -
Page 12: Loading
Salt = 40 lb/cu ft (avg.) Very Coarse = 35 lb/cu ft Coarse = 45 lb/cu ft Fine = 50 lb/cu ft Plus approximate base unit weight of 154 lb for LP-8 Model, including mount. Lit. No. 43991, Rev. 01 November 1, 2012... -
Page 13: Mounting The Spreader
MOUNTING THE SPREADER RECEIVER MOUNT SPREADER SWING AWAY SPREADER ® CAUTION During removal or mounting, securely grip CAUTION spreader to avoid dropping. During removal or mounting, securely grip spreader to avoid dropping. NOTE: The spreader shall be installed according to instructions supplied. Your local outlet is NOTE: The spreader shall be installed according trained to provide this service and service your to instructions supplied. -
Page 14: Operating The Spreader
OPERATING THE SPREADER DRIVING AND SPREADING ON SNOW VARIABLE SPEED (PWM) CONTROL AND ICE ON/Maximum Diagnostic Speed Button Indicator Light CAUTION Drinking and then driving or spreading is very dangerous. Your refl exes, perceptions, attentiveness and judgement can be affected by even a small amount of alcohol. -
Page 15: Adjusting The Spinner Speed
OPERATING THE SPREADER Adjusting the Spinner Speed NOTE: Always place the cover on the hopper to prevent moisture buildup. Do not let the spreader The speed setting can be adjusted when the spreader sit idle with material in the hopper for an extended is either ON or OFF. -
Page 16: Removing The Spreader
REMOVING THE SPREADER SWING AWAY MOUNT ® CAUTION Empty the hopper before removing the Removing the Spreader spreader. 1. Unplug the spreader and CHMSL. CAUTION 2. Remove the hitch pin from the latch-side hinge pin. During removal or mounting, securely grip the spreader to avoid dropping. -
Page 17: Maintenance
MAINTENANCE 4. If bearings pass inspection be sure to thoroughly CAUTION grease them with a good quality multipurpose Disconnect electric power at spreader grease. See "Bearing and Set Screw electrical wiring harness connection and tag Maintenance" in this section. out if required before servicing or performing maintenance. -
Page 18: Postseason Maintenance
MAINTENANCE POSTSEASON MAINTENANCE DRIVE BELT REPLACEMENT Before storing the unit for the off-season, taking a few Disconnect the electrical plug between the spreader minutes to do the following will extend the service life and truck before drive belt replacement. of your spreader: CAUTION 1. -
Page 19: Bearing And Set Screw Maintenance
MAINTENANCE BEARING AND SET SCREW FUSE REPLACEMENT MAINTENANCE See the Harness Wiring Diagrams on the following pages for fuse ratings and locations. Disconnect the electrical plug between the spreader and the truck before performing any maintenance. If a problem should occur and fuse replacement is necessary, the replacement fuse must be of the same 1. -
Page 20: 4-Pin Harness Wiring Diagram
4-PIN HARNESS WIRING DIAGRAM – LOW-PROFILE SPREADERS Cab Control White Connector Two-Way Molded Connector Red Connector 6 Amp Fuse 14 ga Red 8 ga Red To vehicle ignition 8 ga Red (accessory wire or fuse box) 30 Amp Fuse 10 ga Red 14 ga Black 8 ga Black 14 ga Yellow... -
Page 21: Troubleshooting Guide
TROUBLESHOOTING GUIDE For control operation and use of diagnostic indicator lights, refer to "Variable Speed (PWM) Control" in the Operating the Spreader section of this manual. Problem Possible Cause Suggested Solution 1. Control connector plug is loose. 1. Check plug connection at cab control. 2. - Page 22 TROUBLESHOOTING GUIDE Problem Possible Cause Suggested Solution Unplug the spreader harness and tag out, if required, before performing any of the following repairs. 1. Obstruction is preventing rotation. 1. Clear obstruction. 2. Drive belt is loose or damaged. 2. Adjust tension or replace belt if worn or damaged.
- Page 24 Blizzard outlets or spreader owner is granted. Blizzard reserves the right under its product improvement policy to change construction or design details and furnish equipment when so altered without reference to illustrations or specifi cations used. Blizzard or the vehicle manufacturer may require or recommend optional equipment for spreaders.
