Summary of Contents for ClonerAlliance HDML-Cloner Box
-
Page 2: Safety Precautions
Safety Precautions... -
Page 3: Product Diagram
Product Diagram... - Page 4 1. ON/OFF: Press and hold this button to turn on/turn off the power. 2. 5V/2A: Plug the power adapter into this port and power on HDML-Cloner Box. 3. IN: Connect an HDMI cable between the source video player and HDML-Cloner Box.
-
Page 5: Connection Guide
Connection Guide USB flash drive POWER NOTE: The USB flash drive is not included in the product box. You need to purchase it separately. - Page 6 1. Connect Xbox 360/Xbox One to IN on HDML-Cloner Box via an HDMI cable. 2. Connect HDML-Cloner Box from OUT to TV via an HDMI cable. 3. Connect the HDD or USB stick to the USB port of HDML-Cloner Box.
- Page 7 USB flash drive POWER NOTE: The USB flash drive is not included in the product box. You need to purchase it separately.
- Page 8 2. Connect HDML-Cloner Box from OUT to TV via an HDMI cable. 3. Connect the HDD or USB stick to the USB port of HDML-Cloner Box. 4. Plug the power adapter into the power socket and plug the other end...
- Page 9 USB flash drive POWER NOTE: The USB flash drive is not included in the product box. You need to purchase it separately.
- Page 10 2. Connect HDML-Cloner Box from OUT to TV via an HDMI cable. 3. Connect the HDD or USB stick to the USB port of HDML-Cloner Box. 4. Plug the power adapter into the power socket and plug the other end...
- Page 11 How to record/capture videos? 1. Turn on HDML-Cloner Box. The LED light will illuminate solid Blue or Green. 2. Prior to gameplay or video playback, press the REC/STOP button. Start playing game or video, then recording will start simultaneously. The LED light will blink Blue or Green.
- Page 12 The LED light of HDML-Cloner Box will illuminate different colors/ways to indicate functions. LED Status Indication Solid Green The current video is 720p/others. Solid Blue The current video is 1080p. Blink Blue/Blink Green Recording Blink Blue/Green alternately Buffering, please wait.
- Page 13 Tips 1. When the storage space of the USB flash drive or mobile hard disk is full, HDML-Cloner Box will stop recording. 2. If you press and hold the REC/STOP button for a few seconds, it will work as a switch between 720p and 1080p.
- Page 14 Tips on selecting a proper USB flash drive: 1. Recommended brands: Toshiba, SanDisk, Kingston 2. Interface specifications: USB 2.0, USB 3.0 3. Connector type: Type A 4. Make sure the actual reading speed is not less than 30Mbps, and the writing speed is not less than 10Mbps.
-
Page 15: Supported Resolutions
Supported Resolutions 1920x1080 (50p), 1920x1080 (60p) 1920x1080 (24p), 1920x1080 (25p), 1920x1080 (30p) 1920x1080 (50i), 1920x1080 (60i), 1280x1024 (60p) Input/Output 1280x720 (60p), 1280x768 (60p), 1280x800 (60p) 720x480 (60i), 720x480 (50i) 640x480 (60p), 720x480 (60p), 720x576 (50p) 1920x1080 (30p), 1280x720 (60p), 1280x720 (30p) Recording 640x480 (60p), 720x480 (60p), 720x576 (50p) -
Page 16: Product Specifications
Bitrate Max: 10Mbps HDML-Cloner Box will record several 2GB files if the USB is in FAT32 format. Note: If in NTFS format, HDML-Cloner Box will record only 1 file with greater size. Maximum storage capacity Power supply DC 5V, 2A Weight 5.3 oz... -
Page 17: Microphone Function
Microphone Function Note: Please use a microphone with a plug like this. - Page 18 HDMI is a registered trademark of HDMI Licensing, LLC. Xbox is a registered trademark of Microsoft Corporation. Wii is a registered trademark of Nintendo Inc. HDMI®, Xbox®, Wii®, DVD®, Blu-ray® and USB® are trademarks of their respective companies. ClonerAlliance Inc. is not affiliated with those companies.
- Page 19 https://www.cloner-alliance.com...
