Owner's Manual
SR- 1 12
Time Code
Distripalyzer
Operation Manual
Software version 2.0.1
BRAINSTORM ELECTRONICS, INC.
www.brainstormtime.com
...Intelligent Solutions For The Recording Studio
Distributed Exclusively by
plus24
1155 N. La Brea Avenue, West Hollywood, CA 90038 - USA
Tel: (323) 845-1171 - Fax: (323) 845-1170
www.plus24.net
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Brainstorm SR-112
Summary of Contents for Brainstorm SR-112
- Page 1 SR- 1 12 Time Code Distripalyzer Operation Manual Software version 2.0.1 BRAINSTORM ELECTRONICS, INC. www.brainstormtime.com ...Intelligent Solutions For The Recording Studio Distributed Exclusively by plus24 1155 N. La Brea Avenue, West Hollywood, CA 90038 - USA Tel: (323) 845-1171 - Fax: (323) 845-1170...
- Page 2 Owner’s manual Version 2.01 October 2012 All materials herein © Brainstorm Electronics, Inc. Brainstorm Electronics reserves the right to change or modify the contents of this manual at any time. Credits Concept: A ID, Brainstorm Electronics Software: Gerry Lester Manual: Bernard Frings, Gerry Lester...
- Page 3 SR-112 Web Page ........
- Page 4 SR-112 User Manual SR-112 User Manual Page 5 NOTE: The SR-112 reshapes and distributes time code. With a software upgrade (TCG), it also repairs and generates time code. For instructions on those features, please refer to the TCG manual. SR-112 redundancy.
- Page 5 Left Right Down Note: Holding the [SET UP] key for 3 seconds or more will reset the SR-112 (see page 15 for more on Reset). Note: Repair and Generate are only available when the optional TCG software has been installed.
- Page 6 Page 8 SR-112 User Manual SR-112 User Manual Page 9 7. Menu Navigation 8. Menus Description Menu 01 only appears when the TCG software option has been ] key. installed since, without it, Reshape is the only mode available. DOWN...
- Page 7 Page 10 SR-112 User Manual SR-112 User Manual Page 11 Simply multing a time code source can cause serious problems and is not rec- ommended. buffered and balanced outputs. Level fluctuations or improper level can also render time code unreadable.
- Page 8 Page 12 SR-112 User Manual SR-112 User Manual Page 13 played separately setting (as needed). NOTE: SMPTE time code was developed for analog television operating with rates up to 30 f/s. With digital television, progressive video systems have frame rates up to 50 and 60 f/s.
- Page 9 Page 14 SR-112 User Manual SR-112 User Manual Page 15 Video Drift LED were away. Reporting Errors on the SR-112 front panel of 5 seconds or more. ] button for 3 seconds or SET UP...
- Page 10 Page 16 SR-112 User Manual SR-112 User Manual Page 17 of programming. Simply press any key and start again. new firmware to update your SR-112. Future versions will include additional features. 13. Firmware Updates restore your SR-112. DOWN ARROW SETUP...
- Page 11 13.4. FIRMWARE UPDATES & FLASH MEMORY |PgLn 00.00.00.00| |---- 00.00.00.00| The SR-112 FLASH memory is divided in several sections, storing the parameters settings, the application software, the Loader software and the FPGA image. When updating your playspeed mode. unit, 2 types of image files are available: complete and software (see diagram below).
- Page 12 Page 20 SR-112 User Manual SR-112 User Manual Page 21 FATAL NON FATAL 525i/29.97 NTSC 1080i/25 1080p/23.976 525i/30 1080i/25 295M 1080p/24 Drop out (“DROP OUT”) Code out of sync 625i/23.976 PAL- 1080i/29.97 1080p/25 625i/24 PAL- 1080i/30 1080p/29.97 625i/25 PAL 1080sF/23.976...
- Page 13 Page 22 SR-112 User Manual SR-112 User Manual Page 23 different.
- Page 14 Page 24 SR-112 User Manual...
