OPERATING INSTRUCTIONS AND
SYSTEM DESCRIPTION FOR THE
POWER SUPPLY FOR EMPS
or
EXT-16DX systems
VERSION 1.0
npi 2014
npi electronic GmbH, Bauhofring 16, D-71732 Tamm, Germany
Phone +49 (0)7141-9730230; Fax: +49 (0)7141-9730240
support@npielectronic.com; http://www.npielectronic.com
Advertisement
Table of Contents
Summary of Contents for NPI PWR-03D
- Page 1 OPERATING INSTRUCTIONS AND SYSTEM DESCRIPTION FOR THE PWR-03D POWER SUPPLY FOR EMPS EXT-16DX systems VERSION 1.0 npi 2014 npi electronic GmbH, Bauhofring 16, D-71732 Tamm, Germany Phone +49 (0)7141-9730230; Fax: +49 (0)7141-9730240 support@npielectronic.com; http://www.npielectronic.com...
- Page 2 VERY IMPORTANT: Instruments and components supplied by npi electronic are NOT intended for clinical use or medical purposes (e.g. for diagnosis or treatment of humans), or for any other life-supporting system. npi electronic disclaims any warranties for such purpose. Equipment supplied by npi electronic must be operated only by selected, trained and adequately instructed personnel.
- Page 3 EXT-16DX amplifier with R/I-T1DX. Each housing is connected by a 6-pole cable from one of three connectors on the front panel of the PWR-03D to the rear panel of the respective EPMS-E or EXT-16DX / R/I-T1DX housing (see Figure 1, Figure 3). A POWER LED indicates that the PWR-03D is powered on (see Figure 1).
