Summary of Contents for EMRAX One Man Rigging Aid
- Page 1 User’s Manual for One Man Rigging Aid www.emrax.com...
-
Page 2: Table Of Contents
3. Adjustments of One Man Rigging Aid ............................6 3. How to use the One Man Rigging Aid? ............................8 4. How to use Remote Control?..............................9 5. Testing of One Man Rigging Aid on a bigger glider plane ......................11 www.emrax.com Version 1.1 / November 2016... - Page 3 Figure 11: Remote control ................................9 Figure 12: Remote control transmitter ............................10 Figure 13: Global frequency bands - you have to select the area where the One Man Rigging Aid will be used when placing the order ......................................11 Figure 14: Testing on Duo Discus glider plane..........................
-
Page 4: One Man Rigging Aid Features
It is a Slovenian product. The device was developed by Mr. Roman Sušnik, dipl. ing. (Company EMRAX d.o.o.; till March 2016 company name was Enstroj d.o.o.). The first prototype was tested on Apis EA1 in 2006. -
Page 5: One Man Rigging Aid Parts
User’s manual for advanced axial flux synchronous motors and generators 2. One Man Rigging Aid parts Figure 2: One Man Rigging Aid parts 12 V / 7,2 Ah battery is not included. One charging of the battery lasts for one season (for approximately 50 assemblies). -
Page 6: Adjustments Of One Man Rigging Aid
User’s manual for advanced axial flux synchronous motors and generators Figure 4: Wing stand 3. Adjustments of One Man Rigging Aid Figure 5: Manually adjustable vertical cradle position from 62 to 100 cm www.emrax.com Version 1.1 / November 2016... -
Page 7: Figure 6: Manually Adjustable Horizontal Cradle Position - 3 Positions Spaced 80 Mm
User’s manual for advanced axial flux synchronous motors and generators Figure 6: Manually adjustable horizontal cradle position - 3 positions spaced 80 mm Figure 7: Adjustable screws for wing curvature www.emrax.com Version 1.1 / November 2016... -
Page 8: How To Use The One Man Rigging Aid
! Note: - When the One Man Rigging Aid is being moved around without a wing on it the supporting bracket must be parallel (in the same line) as the horizontal iron bar. - Never push the button on the remote control transmitter if the supporting bracket is parallel to the horizontal iron bar. -
Page 9: How To Use Remote Control
Figure 10: Supporting bracket position must be parallel during dragging the rigging aid. Remote control must not be used in this position of the supporting bracket. Video of the One Man Rigging Aid usage (no editing was done from the beginning to an end): https://youtu.be/XyWSmN_3spM 4. -
Page 10: Figure 12: Remote Control Transmitter
Fuse: 6,3 A ! Note: The main switch on the remote control box must be OFF, when One Man Rigging Aid is not in use. If the switch is not switched off manually, it switches off after half hour automatically. Therefore the main switch needs to be reset before next usage. -
Page 11: Testing Of One Man Rigging Aid On A Bigger Glider Plane
User’s manual for advanced axial flux synchronous motors and generators Figure 13: Global frequency bands - you have to select the area where the One Man Rigging Aid will be used when placing the order 5. Testing of One Man Rigging Aid on a bigger glider plane Figure 14: Testing on Duo Discus glider plane www.emrax.com...
