GEONAUTE ONpower 710 User Manual

A. LED indicators :
4
B. Features
- High capacity of 7800mAh.
- Two USB output.
- Built-in LED lighting function.
- Smart LEDS display of remaining power.
- Water proof design IPX4 (rain and projections).
- Multiple safety protection system to ensure devices safety protection for overcharge overvoltage overburdens and short circuit.
C. Specification
Battery Type: Li-ion Battery.
Capacity: 7800mAh / 28.9Wh.
Input: Micro USB 5V/IA.
Output: USB1 5V/1A USB2 5V/2. 1A.
Dimension: 115*69*27mm.
Weight: 261g +- 10g.
Accessory : 1 USB cable.
D. How to use the ONPOWER 710
1. Turn on the ONPOWER 710: Short press the power key, make the LED power indicator start constantly, it means the power start.
2. Turn off the ONPOWER 710: Short press the power key, make the LED power indicator close, it means the power close.
3. Open the LED Light; Long press the button (3s), it means the torch start.
4. Close the LED Light Long press me button (3s), it means the torch dose.
E. How to charge ONPOWER 710
1. Charge by Computer or Adapter : connect the ONPOWER 710 with USB cable.
2. The LED indicators will flicker when charging the ONPOWER 710.
3. The LED indicators will all light when full charging.
Note: Please charge and restart the ONPOWER 710 while it is under lock. Status or in shortcut protection caused by incorrect operation.
F. How to test remaining power
Press the power button to check remain power.
Power status:
ON
LED Light
OFF
EN User Manual ONPOWER 710
6
3
7
5
2
8
Capacity
<10%
10%-35%
35%-65%
65%-85%
85%-100%
1
Lanyard hole
1 :
Power key
2 :
USB1 Output
3 :
USB2 Output
4 :
Micro USB Input
5 :

LED indicators

6 :
LED Light
7 :
Cover
8 :
LED indicator
flash
LED indica-
tor close
LED
indicator
light
