Summary of Contents for Serma EVA4201
- Page 1 Documentation EVA4201/4301 – User Guide Evaluation Board for Power Factor Corrected (PFC) Supply Featured Products: PE4201/PE4301...
-
Page 2: Table Of Contents
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply Table of Contents Revision History ........................2 Safety Instructions ........................3 Introduction ..........................3 Features ........................... 3 IC`s General Description ......................3 How to design an application ....................4 Given board specification ......................4 Calculating the Current ...................... -
Page 3: Safety Instructions
Please take caution - the board operates at 405V DC and is directly plugged into the power network. Operating this Board requires an isolated transformer! The EVA4201/4301 was designed to help understand and evaluate the features of two Power Factor Correction IC`s. Used external devices are standard components chosen for safe operation and do not represent a completely fine-tuned OEM application. -
Page 4: How To Design An Application
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply How to design an application 4.1 Given board specification PE4201/PE4301 The board setup in the original state has the following specification parameters. The following chapters show, what has to be changed to design an active PFC supply towards different parameters. Please take caution when calculating. - Page 5 EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply PE4301 The input power: 86,96W η 86,96W The input current: 0,40A ACin_LL 110V 86,96W 0,33A ACin_HL 265V The ripple current ∆I is set to 20% ∆I 0,40A 0,11A ∗ ∗ ∗ ∗...
-
Page 6: Inductor
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 4.3 Inductor PE4201 For CRM operation, the maximum 'on' time and the maximum 'off' time control the lowest frequency. The minimum CRM inductance L at low and high line input voltage can be calculated as follows: (CRM) −... -
Page 7: Current Sense Resistor
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply ∗ ∗ (21) ∆I ∗ 110V 0,615 ∗ ∗ (22) 21425 µH CCM_LL 40kHz ∗ 265V 0,074 ∗ ∗ (23) 7536 µH CCM_HL 40kHz 0,093A ∗ For high line voltage and high output power the inductor set to 8000µH. The switching frequency at low line voltage obtains as: ∗... - Page 8 EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 2.5 Output Bypass Capacitor PE4201/PE4301 The bypass capacitor on the output of the circuit has to be able to suppress the ripple of the switching frequency and the residues of the full-wave rectified input frequency (2 * f (28) ∗...
- Page 9 EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply The figure shows the input voltage (230V~) in orange color, the current (I =0.20A) in blue color and the ripple of the output voltage in green color (only AC, C13=47µ, C6=0.1µ). The ripple is lower than 20V peak-to-peak (<5%).
-
Page 10: Error Amplifier Compensations
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply Input Filter PE4201/PE4301 A high-frequency has to be applied in the primary AC input to reduce reflections from and to the power grid. Figure 1: Input Filter The capacitor C following the bridge rectifier provides the peak current and reduces the voltage ripple. This is typical for a 330nF or for a 470nF capacitor. -
Page 11: Self Biasing
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 6,028k (34) 2 π 2 π 100Hz 220nF ∗ ∗ ∗ ∗ R4=5,6kOhm shall be chosen here. The frequency of the second pole shall be at about 1/7 of the switching frequency. This defines the capacitance of C 4,6nF (35) -
Page 12: Emi And Driver Slewrate
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 150kHz 8,5V 1,275mA (37) ∗ ∗ ∗ ∗ Gdyn Gmax 8,5V Gmax 0,2125mA (38) ∗ ∗ Gohm 20kΩ Total current consumption calculates according to equation (39). 0,45mA 1,275mA 0,2125mA 1,9375mA (39) stat Gdyn Gohm... -
Page 13: Description
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply In the range up to 80W, there is no need to use a bypass diode; the current depends on C in addition with possible start current on the load. In case of C 47µF there is a max. -
Page 14: Evaluation Board Specifications
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 5.1 Evaluation Board Specifications AC Line Input voltage ........85 Vac - 265 VAC AC Line Frequency .......... 47 – 65 Hz Switching Frequency in the middle ....40 – 170 kHz Output voltage .......... -
Page 15: Schematic
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 5.3 Schematic Figure 5: Board Schematic ISO 9001 / ISO 14001 01/06/2016 © Productivity Engineering GmbH Page 15 of 22... -
Page 16: Component Placement
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 5.4 Component Placement Figure 6: Board device population ISO 9001 / ISO 14001 01/06/2016 © Productivity Engineering GmbH Page 16 of 22... -
Page 17: Board Picture And Layout
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 5.5 Board Picture and Layout Figure 7: Board photograph (8cm x 5cm) Figure 8: PCB Layout ISO 9001 / ISO 14001 01/06/2016 © Productivity Engineering GmbH Page 17 of 22... -
Page 18: Bill Of Material
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 5.6 Bill of Material Reference Used Description/Package Vendor PE4X01_SO08 PE4X01_SO08 PE4201 or PE4301 C1,C4 2.2n/3kV C2N2 Res. f. Prot. Earth 150n/250V~ C150-084X183 47n/250V~ C102-064X133 470n/400V C150-084X183 100n/630V C15B6 100n C1206K 10µ/35V 153CLV-0405 4,7n C0805... -
Page 19: Operating
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply Operating 6.1 Caution The Evaluation board has been designed to operate between 40VAC and 80VAC input power grid voltages and 405VDC output voltage. Powering the board outside specified operating conditions will destroy devices and might cause severe damage and harm people. -
Page 20: List Of Abbreviations
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply List of Abbreviations Abbreviation Explanation AC-IN Input Voltage Input Current Bill of material Continuous Conduction Mode Capacitor for EMI Capacity of the gate (MOSFET) Capacitor for reduction of HF- transmitting Output Capacitor Output Capacitor out2 Cap. -
Page 21: Notes
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply Notes ISO 9001 / ISO 14001 01/06/2016 © Productivity Engineering GmbH Page 21 of 22... -
Page 22: Contact Addresses
EVA4204/4301 User Guide Evaluation Board for 80W PFC Supply 9. Contact Addresses Germany Stuttgart Dresden Productivity Engineering Productivity Engineering GmbH Process Integration GmbH Branch Behringstrasse 7 Sachsenallee 9 D-71083 Herrenberg D-01723 Kesselsdorf Germany Germany Phone.: +49 (0) 70322798 0 Phone.: +49 (0) 35204777 00 Fax: +49 (0) 70322798 29 Fax: +49 (0) 35204777 000 Email: info@pe-gmbh.com...
