Summary of Contents for Hydra-Stop Hydra-Power
- Page 1 Hydra-Power Hydraulic Power Pack Operation Instructions HSPWRPK v1.11 Revised March 2016 Specifi cations subject to change without notice.
- Page 2 Table of Contents Section Title Page Hydra-Power Specifi cations Features and Controls Safety Warnings Hydra-Power Setup Instructions Hydra-Power Operation Replacement Parts Hydra-Power Hydraulic Power Pack Operation Instructions HSPWRPK v1.11 Revised March 2016 Specifi cations subject to change without notice.
-
Page 3: Hydra-Power Specifi Cations
Output: 9 GPM @ 1700-1800 psi. motor (nipples not included) 15 gallon hydraulic oil reservoir with in-tank fi lter kit Gauges and fi lters necessary for Hydra-Power Power- 12v battery rated to 230cca at 0deg. Pack operation Power Unit is skid mounted with protective cage. -
Page 4: Safety Warnings
When operating the Hydra-Power PowerPack: DO NOT wear loose-fi tting clothing, dangling drawstrings or items that could become caught. DO NOT move or tip the Hydra-Power PowerPack or allow fuel or oil to spill. When transporting or servicing the Hydra-Power Pow- erPack: Sparks can result in fi... - Page 5 3/8 cap screws as in power output or improved performance. shown. PRE-USE INSPECTION Check Hydra-Power PowerPack for any engine oil or hydraulic oil leaks. Check all fl uid levels. Add fl uids if necessary. IMPORTANT: TO AVOID DAMAGE TO ENGINE AND HYDRA-POWER POWERPACK PUMP DO NOT AT- 2) Lift and remove fi...
-
Page 6: Hydra-Power Operation
SECTION 5 - Hydra-Power Operation 6) Move throttle lever slightly to the left. Starting the Engine 1) Make certain the Hydra-Power PowerPack is on a fl at, level surface. 2) Connect all hoses to both the power pack and drive motor before starting engine. - Page 7 NOTE: Engine will not start if hydraulic fl uid is not able to cycle through the pump and return to the oil reservoir. 3. Run the Hydra-Power PowerPack for a few minutes so the treated fuel cycles through the fuel system and carburetor.
- Page 8 SECTION 6 - Replacement Parts Replacement parts for your hydra-Power are available from Hydra-Stop. Please contact your inside sales rep- resentative to order or for additional information. Part number Quantity per machine Part Description SLF1-12S-0-ZSLE110 ASSY Filter Assembly (tank top canister and fi...
