- Page 1 Installation and Operation Manual OP+OER+S, OP+OER+HI+S, OP+OER+SF+D and OP+OER+SF+HI+D 3 Gb/s HD-SDI Optical-to-Electrical Receivers Edition B 175-100080-00 Delivering the Moment...
-
Page 2: Contact Information
This publication does not in any way warrant description accuracy or guarantee the use for the product to which it refers. Imagine Communications reserves the right, without notice to make such changes in equipment, design, specifications, components, or documentation as progress may warrant to improve the performance of the product. - Page 3 OP+OER+S OP+OER+HI+S OP+OER+SF+D OP+OER+SF+HI+D 3 Gb/s HD-SDI Optical-to-Electrical Receivers Installation and Operation Manual Edition B July 2010...
-
Page 5: Table Of Contents
General Description .................1 Main Features ...................1 Module Types ...................2 Back Modules ..................3 Signal Flow ....................4 OP+OER+S and OP+OER+HI+S Single-Slot .........4 OP+OER+SF+D and OP+OER+SF+HI+D Dual-Slot .....4 Chapter 2: Installation and Operation Maximum Frame Power Ratings .............5 Setting Jumpers ..................7 Installing and Removing the Modules .............9 Installation Overview ................9... - Page 6 Contents Chapter 3: Specifications Power Consumption ................23 Start-Up Time ..................23 Temperature ..................23 Electrical Specifications ................ 24 Optical Specifications ................25 Appendix A: Laser Safety Guidelines Laser Safety ................... 27 Precautions for Enclosed Systems ..........28 Precautions for Unenclosed Systems ..........28 Labels ....................
-
Page 7: Preface
Preface Manual Information Purpose This manual details the features, installation procedures, operational procedures, and specifications of the OP+OER 3 Gb/s HD-SDI Optical-to-Electrical Receivers. Audience This manual is written for engineers, technicians, and operators responsible for the installation, setup, and operation of the OP+OER 3 Gb/s HD-SDI Optical-to-Electrical Receivers. - Page 8 Preface Writing Conventions To enhance your understanding, the authors of this manual have adhered to the following text conventions: Table P-2. Manual Style and Writing Conventions Term or Description Convention Bold Indicates dialog boxes, property sheets, fields, buttons, check boxes, list boxes, combo boxes, menus, submenus, windows, lists, and selection names.
-
Page 9: Unpacking/Shipping Information
Preface Unpacking/Shipping Information This product was carefully inspected, tested, and calibrated before shipment to ensure years of stable and trouble-free service. 1. Check equipment for any visible damage that may have occurred during transit. 2. Confirm that you have received all items listed on the packing list. 3. -
Page 10: References
Preface References ANSI/SMPTE 259M-1997 10-Bit 4:2:2 Component and 4fsc NTSC Composite Digital Signals - Serial Digital Interface (144/243/270/360 Mb/s SDI) SMPTE 424M-2006 3Gb/s Signal/Data Serial Interface SMPTE 425M-2006 3Gb/s Signal/Data Serial Interface - Source Image Format Mapping SMPTE 372M-2002 Dual Link 292M Interface for 1920 x 1080 Picture Raster SMPTE 344M-2000 540Mb/s Serial Digital Interface SMPTE 292M-1999... - Page 11 Preface IEC 60874-14-2 Detail Specification for Fiber Optic Connector Type SC-PC Tuned Terminated to Single-Mode Fiber Type B1 IEC 60874-14-5 Detail Specification for Fiber Optic Connector Type SC-PC Un-Tuned Terminated to Single-Mode Fiber Type B1 FCC Code of Federal Regulations (CFR) 47, part 15 •...
-
Page 12: Safety Standards And Compliances
Preface Safety Standards and Compliances “Laser Safety” on page 27 to find the safety standards and compliances for this product. A safety manual is included in the Harris Infrastructure and Networking Documentation and Product Resources DVD, and it can be downloaded from our website. Alternatively, contact your Customer Service representative for a copy of this safety manual. - Page 13 Preface Waste from Electrical and Electronic Equipment (WEEE) Directive The European Union (EU) Directive 2002/96/EC on Waste from Electrical and Electronic Equipment (WEEE) deals with the collection, treatment, recovery, and recycling of electrical and electronic waste products. The objective of the WEEE Directive is to assign the responsibility for the disposal of associated hazardous waste to either the producers or users of these products.
- Page 14 Preface Safety Terms and Symbols This product manual uses the following safety terms and symbols to identify certain conditions or practices. See “Laser Safety” on page 27 and the frame Safety Instructions and Standards Manual for more information. Table P-3. Safety Terms and Symbols WARNING: Identifies conditions or practices that can result in personal injury or loss of life—high voltage is present.
-
Page 15: Chapter 1: Introduction
Chapter 1 Introduction General Description OP+OER modules are 3 Gb/s HD-SDI Optical-to-Electrical Receivers. They are available in a single- and double-slot versions (the double-slot version adds a passive splitter and additional reclocked outputs), and in standard-sensitivity PIN and high-sensitivity APD versions. Main Features •... -
Page 16: Module Types
Chapter 1: Introduction Module Types Table 1-1. Module Types Product Description OP+OER+S Single-slot standard-sensitivity SD-SDI PIN fiber receiver with SC-type rear connector OP+OER+HI+S Single-slot high-sensitivity SD-SDI APD fiber receiver with SC-type rear connector OP+OER+SF+D Dual-slot standard-sensitivity SD-SDI PIN fiber receiver with... -
Page 17: Back Modules
OPTICAL IN SDI OUT SDI OUT OPTICAL OUT SDI OUT SDI OUT SDI OUT SDI OUT SDI OUT SDI OUT OP+OER+S and OP+OER+SF+D and OP+OER+HI+S OP+OER+SF+HI+D Figure 1-1. Back Modules OP+OER Installation and Operation Manual Copyright © 2010, Harris Corporation... -
Page 18: Signal Flow
Chapter 1: Introduction Signal Flow OP+OER+S and OP+OER+HI+S Single-Slot 3Gb/s / HD / SD-SDI Out Cable Driver 3Gb/s / HD / SD-SDI Out Fiber-optic 3Gb/s / HD / 3Gb/s / HD / receiver Reclocker Fanout SD-SDI Fiber In O/E Converter... -
Page 19: Chapter 2: Installation And Operation
Chapter 2 Installation and Operation Maximum Frame Power Ratings OP+OER modules operate only in fan-cooled 6800+ frames, subject to the limitations shown in Table 2-1. These modules cannot be installed in FR6802+DM or 6800/7000 series frames. CAUTION To maintain proper temperatures, ensure the front panel is closed at all times, and the fan module is fully operational. - Page 20 Chapter 2: Installation and Operation CAUTION To prevent damage, ensure that you mate single-slot front modules with single-slot back modules, and dual-slot front modules with dual-slot back modules. Do not mix-and-match different front and back modules. Before installing this product, read the Safety Instructions and Standards Manual .
-
Page 21: Setting Jumpers
Chapter 2: Installation and Operation Setting Jumpers All of the jumpers on the OP+OER modules are located at the card edge. Table 2-2 lists the default settings. See page 18 for more jumper information. Table 2-2. Jumper Default Settings Jumper Default Description Auto... - Page 22 Chapter 2: Installation and Operation CAUTION To prevent overload damage, ensure that you observe the following: Harris Corporation does not recommend installing high-sensitivity (APD) optical receivers on multimode fiber. Due to its dispersion characteristics, multimode fiber is typically limited to shorter distance applications with very little signal attenuation.
-
Page 23: Installing And Removing The Modules
Chapter 2: Installation and Operation Installing and Removing the Modules Installation Overview Front and back modules in the OPTO+ series have plastic caps that protect the fragile laser connections from damage. You must remove these protective covers before you install the back and front modules (see Figure 2-2). -
Page 24: Back Module Installation
Chapter 2: Installation and Operation Back Module Installation Follow these steps to install the back module into a frame: 1. Remove a blank back plate from the frame. Do not discard the blank back plates. They may be needed for future configurations. -
Page 25: Front Module Installation
Chapter 2: Installation and Operation Front Module Installation OP+OER front modules are hot-swappable and can be installed with the power supply either turned on, or turned off. Procedure Follow these steps to install the front modules: 1. Pull out the finger-release screws on the right and left side of the front panel of the frame, and then open it. -
Page 26: Removing Modules
Chapter 2: Installation and Operation Removing Modules NOTE The removal steps provided here are similar to those outlined in your frame Installation and Operation Manual. Refer to that manual for detailed information about installing and operating a frame and its components. Front Module Follow these steps to remove a front module from the frame: 1. -
Page 27: Inspecting And Cleaning Fiber Optic Connections
Chapter 2: Installation and Operation Inspecting and Cleaning Fiber Optic Connections Small amounts of microscopic dust or other contaminants can seriously impair or disable a fiber optic network. To ensure that your network operates reliably, you must carefully inspect and clean each connection when installing OPTO+ products. - Page 28 Chapter 2: Installation and Operation • Never touch the dispenser tip of an alcohol bottle or any clean portion of a tissue or swab. • Use care when handling the fiber; do not twist or pull. • Keep your cleaning fluids away from open flame or spark. Figure 2-3 describes the acceptable limits of defects in a fiber connection.
-
Page 29: Inspection And Cleaning Procedure
Chapter 2: Installation and Operation Inspection and Cleaning Procedure Inspection To inspect and clean the fibers, follow these steps: 1. Ensure the fiber is not “live.” WARNING Eye damage may occur if an optical instrument such as a microscope, magnifying glass, or eye loupe is used to stare at an energized fiber end. - Page 30 Chapter 2: Installation and Operation Wet Cleaning Using 99.8% isopropyl alcohol and lint-free wipes, follow these steps to wet clean the fiber: 1. Fold the wipe into a square, about 4 to 8 layers thick. 2. Moisten one section of the lint-free wipe with one drop of 99.8% alcohol, ensuring that a portion of the wipe remains dry.
-
Page 31: Ccs Parameter List
Chapter 2: Installation and Operation CCS Parameter List Table 2-4 on page 17 lists the parameters that are available when you use CCS-enabled control panels or software. Read-only parameters are indicated by the [RO] symbol and grey shading. Default option settings are shown in bold. - Page 32 Chapter 2: Installation and Operation Table 2-4. OP+OER and OER+SF Parameters in CCS (Continued) Parameter Name Function Options or Values • Unknown Input Format [RO] Indicates the format of the incoming signal • 270M • 1.5G • 3G • Mismatch Signal Strength [RO] Displays the optical input power strength String (dBm)
-
Page 33: Leds And Alarms
Chapter 2: Installation and Operation LEDs and Alarms LEDs The OP+OER LEDs are located on the card edge of the front module (see Figure 2-4). Table 2-5 on page 20 describes the meanings of the LEDs and their colors. Module Status indicator Status LEDs Jumpers... - Page 34 Chapter 2: Installation and Operation Table 2-5. LED Descriptions Color Meaning When Lit Module Status None (off) There is no power to the module; the module is not operational. Green The module is operating normally. One or more alarms have been triggered. Flashing red The module has not booted up properly.
-
Page 35: Alarms
Input Power Too High Minor The optical input power is too high. This alarm is generated when the input power is greater than the following: • 0 dBm (OP+OER+S) • +3 dBm (OP+OER+SF+D) • -9 dBm (OP+OER+HI+S) • -6 dBm (OP+OER+SF+HI+D) OP+OER Installation and Operation Manual Copyright ©... - Page 36 Chapter 2: Installation and Operation OP+OER Installation and Operation Manual Copyright © 2010, Harris Corporation...
-
Page 37: Chapter 3: Specifications
Chapter 3 Specifications Power Consumption The power consumption for all OP+OER modules is <5 W. Start-Up Time The start-up time for all OP+OER modules is <10 seconds. Temperature The operating temperature range for the OP+OER modules is 32° to 113°F (0° to 45°C). Propagation Delay The propagation delay for an OP+OER module is <16 ns. -
Page 38: Electrical Specifications
Chapter 3: Specifications Electrical Specifications Table 3-1. Electrical Specifications Item Specification Input connector 75Ω BNC per IEC169-8 • 3 BNC (OP+OER) Number of outputs • 8 BNC (OP+OER+F+D) • SD-SDI Signal type • ASI • 1.5 Gb/s HD-SDI • 3 Gb/s HD-SDI •... -
Page 39: Optical Specifications
Table 3-3. Optical Performance Item Minimum Typical Maximum Units Conditions Input wavelength 1260 1620 Sensitivity (OP+OER+S) 3 Gb/s, Pathological* All rates color bars, up to 1.5 Gb/s, Pathological** Sensitivity 3 Gb/s, Pathological* (OP+OER+SF+D) All rates color bars, up to 1.5 Gb/s, Pathological**... - Page 40 Chapter 3: Specifications OP+OER Installation and Operation Manual Copyright © 2010, Harris Corporation...
-
Page 41: Appendix A: Laser Safety Guidelines
Appendix A Laser Safety Guidelines Laser Safety WARNING Use of controls, adjustments, and procedures other than those specified in this document may result in hazardous laser radiation exposure. Optical fiber telecommunication systems use semiconductor laser transmitters that emit infrared light that is normally not visible to the human eye. -
Page 42: Precautions For Enclosed Systems
Appendix A: Laser Safety Guidelines Precautions for Enclosed Systems In its normal operating mode, an optical fiber communication system is totally enclosed and presents no risk of eye injury. However, if the fiber optic cables that interconnect various components of an optical fiber disconnect or break, you may be exposed to laser emissions. -
Page 43: Labels
Appendix A: Laser Safety Guidelines 2. Ensure that only authorized, trained personnel use optical test equipment during installation or servicing. 3. Turn off all laser sources before scanning a fiber with an optical test set. 4. Keep all unauthorized personnel away from the immediate area of the optical fiber systems during installation and service. - Page 44 Appendix A: Laser Safety Guidelines OP+OER Installation and Operation Manual Copyright © 2010, Harris Corporation...
-
Page 45: Appendix B: Communication And Control Troubleshooting Tips
Appendix B Communication and Control Troubleshooting Tips Software Communication Problems The frame is powered up, but the module does not communicate with + Pilot Lite or CCS Pilot/Navigator. Solutions • Ensure you have specified the proper module slot. See your frame Installation and Operation Manual for more information about slot identification. - Page 46 Appendix B: Communication and Control Troubleshooting Tips b. Unscrew and remove the back module. c. Inspect the 20- or 30-pin spring connector at the bottom of the back module (Figure B-1 on page 32), and verify that the connector does not have any slightly bent or pressed pins. d.
- Page 47 Appendix B: Communication and Control Troubleshooting Tips + Pilot Lite control is disabled if an ICE6800+ or 6800+ETH • control module is installed in the frame. • Set the Frame ID DIP switch settings correctly (the Frame ID DIP switch is located at the rear of the frame.) •...
-
Page 48: Hardware Communication Problems
Appendix B: Communication and Control Troubleshooting Tips + Pilot Lite and CCS software show a module in the control window, but cannot control it. Solution 1. Set the module’s Local/Remote jumper to Remote. 2. Ensure the module name in the Control window matches the module type in the frame. -
Page 49: Index
Index Keywords – Alarms Inspecting and cleaning connections – Installing and removing modules Back module installation Parameters removal – Pilot Lite troubleshooting Power consumption specification Protective laser connector covers – CCS troubleshooting – Cleaning connections Copyright information Removing front and back modules RoHS directive Dry cleaning connections –... - Page 50 Index Temperature specifications Warranty information – Troubleshooting WEEE directive Wet cleaning connections Upgrades, hardware and software OP+OER Installation and Operation Manual Copyright © 2010, Harris Corporation...
