- Page 1 For Technical support, call 1-800-888-2710, M-F 9am-6pm EST Made in Italy Bike Nashbar, 6103 Rt. 446, Canfield,OH 44406 www.Nashbar.com NB-T5000E, V.1 – June 2004...
- Page 2 Watt Master Mag Trainer Congratulations on your purchase of the Nashbar Watt Master bicycle training system. Your new trainer provides the same data on speed, distance and time that is available from a full-featured cycling computer, plus information on power output (expressed in watts), elevation gain and slope (percent grade). Your indoor training has never been as fun or effective as it will be with your new Watt Master! NOTE: This trainer is intended for single-rider bicycles only.
- Page 3 Set-Up ...........4 VI. Using Your Nashbar Watt Master Trainer ......4 A.
- Page 4 VIII. Changing the Batteries The computer console uses 2 “AA” batteries. When the low battery life indicator appears in the display, or if the display is erratic, faint or disappears altogether, new batteries are needed. 1. To replace the batteries, remove the battery cover from the underside of the com- puter console.
- Page 5 When battery life is low, a battery icon will flash in the display screen to indicate only a few hours of battery life remain. See Figure 13. When the battery icon appears, replace the batteries as soon as possible (See section VIII, “Changing the Batteries”). Battery C.
- Page 6 II. Parts List Part Part Code Quantity Trainer Base............A ........1 Mag Resistance Unit ..........B ........1 Knob Bolt ..............C ........1 Resistance Shift Lever and Cables ......D ........1 Computer Console ..........E ........1 Pivot Bolt, Washer, Nut ........F ........1 each Handle ..............G ........1 Locking Ring ............H ........1 Axle Support Cups ..........I ........2 Rubber Feet ............J ........4...
- Page 7 erly positioned in the axle support cups, and that the right side axle support cup is securely tightened. 12. Tighten the knob bolt (C) until the drive roller contacts the rear tire. Then, turn the knob bolt an additional 3 complete rotations. If the tire slips on the roller, turn the knob bolt by additional turns as necessary to eliminate any slippage.
- Page 8 1. Press either button (SET or MODE) or begin pedaling to activate the computer. Current Speed and other data should immediately appear in the display screen. 2. Adjust the resistance level (simulated slope) using the shift lever. Rotating the shift lever from the lowest setting (1) to the highest setting (5) will increase the resist- ance.
