- Page 1 ENGLISH ProxiGuard THE FUTURE IN GUARD TOUR GPRS Communication Station User’s Manual PG-3300 Please read this manual carefully, before starting to operate the station.
- Page 2 Main Features The PG-3300 is able to upload data collected from guard tour readers over the Internet remotely and real time via GPRS. A computer with TCP/IP Server Utility and Patrol Management Software installed need to be connected to the Internet and assigned a Static Public IP Address.
-
Page 3: Table Of Contents
TABLE OF CONTENT GPRS OVERVIEW..........................3 DESCRIPTION OF THE PG-3300 HARDWARE................3 LED L ........................... 3 TATUS IGHTS ..........................4 UDIO IGNALS ..........................4 OWER OURCE OPERATING INSTRUCTIONS ......................5 TCP/IP S & D GPRS S TCP/IP S ....5 NSTALLING ERVER TILITY OWNLOAD ETTINGS FROM ERVER... -
Page 4: Gprs Overview
Internet access. There is a detail framework of the GRPS working procedure. PG-3300 could use the SIM card and work as a mobile station to send data by GPRS. ProxiGuard PG-3300 could work with 900/1800/1900MHz frequency GSM network. The mobile network allows GPRS connectivity. -
Page 5: Audio Signals
∼ Flashing: the GSM module is working correctly. ∼ Constant on: the network cannot be found. ∼ Constant off: the GSM module is not working. Blue LED – Lower-Right ∼ Flashing once per second: the PG-3300 is operating normally/standby status. ∼... -
Page 6: Operating Instructions
The PG-3300 is able to use multiple types of power supplies: ∼ Rechargeable battery ∼ USB connection to the computer. ∼ 9V AC adapter. ∼ Car adapter. The PG-3300 will turn on after being connected to a power source. The rechargeable battery in the PG-3300 automatically recharges whenever an external power source is connected, including the 9V AC adapter, car adapter, and the USB connection. -
Page 7: Collecting Data From Guard Tour Readers
When you have inset the SIM card, please replace the back case on the station. Collecting data from guard tour readers Compatible readers include models PG-2002S, PG-2002F, PG-2002-W. Ø Turn on the PG-3300 Ø Set the reader into the indentation on the PG-3300. For reader model PG-2002S, please place its reading head between the status lights, and set its top flush against the inside edge of the PG-3300. -
Page 8: Local Data Upload
Every time the data has been sent out, the station will wait for response from the server PC. The remained data will not be sent out unless the response from the server PC has been received. This cycle continues until finishing sending out all the data. During this process, if no server response received over a period of time, the station would make 3 short beeps and 1 long beep, and then shut down. -
Page 9: Pg-3300 Data Sheet
PG-3300 cannot be found by Patrol Management System. Check to see if the Status LED lights flashing properly, if not, please disconnect and reconnect the power supply to reinitialize the unit. Check the condition of the hardware installation, please right-click ‘My Computer’, and then select Properties->Hardware->Device Manager to see if the driver for the Communication Station has been installed in the PC.
