SCANNA MSC LIMITED
104 New Bond Street
London
W1Y 9LG
United Kingdom
OPERATING AND MAINTENANCE MANUAL
SCANMAX 25 C
DESK TOP CABINET
SECURITY X-RAY SCREENING SYSTEM
FITTED WITH COLOUR CAMERA
Telephone
Nat: 0207 355 3555
Int.: (00 +44) 207 355 3555
ISSUE 1
(230V)
Facsimile
Nat: 0207 355 3556
Int.: (00 +44) 207 355 3556

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCANMAX 25 C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Scanna Msc SCANMAX 25 C

  • Page 1 OPERATING AND MAINTENANCE MANUAL ISSUE 1 SCANMAX 25 C DESK TOP CABINET SECURITY X-RAY SCREENING SYSTEM FITTED WITH COLOUR CAMERA (230V) SCANNA MSC LIMITED 104 New Bond Street Telephone Facsimile London Nat: 0207 355 3555 Nat: 0207 355 3556 W1Y 9LG Int.: (00 +44) 207 355 3555...
  • Page 2 Date Amendment Page No Details...
  • Page 3 WARNING NOTICE Safety precautions for use and operation of x-ray producing equipment X-RAY PRODUCING EQUIPMENT CAN BE DANGEROUS TO BOTH THE OPERATOR AND PERSONS WITHIN THE IMMEDIATE VICINITY UNLESS SAFETY PRECAUTIONS ARE STRICTLY OBSERVED. Exposure to excessive quantities of X-radiation may be dangerous to health. Users must avoid exposing any parts of their person, not only to the direct beam, but also to secondary or scattered radiation that occurs when an x-ray beam strikes or has passed through any material.

  • Page 4: Table Of Contents

    SCANMAX 25 C 14/02/01 ISSUE 1 OPERATION MANUAL FOR THE SCANMAX 25C CONTENTS PAGE INTRODUCTION UNPACKING INSTRUCTIONS FITTING HANDLES FITTING THE WHEELED TROLLEY BASE PRE-INSTALLATION GUIDE INSTALLATION GUIDE SAFETY PRECAUTIONS SAFETY INSTRUCTIONS INTRODUCTION TO X-RAYS OPERATING INSTRUCTIONS X-RAY SCREENING PROCEDURES...

  • Page 5: Introduction

    INTRODUCTION The SCANMAX 25 is a fluoroscopic X-ray cabinet specifically designed for the detection of explosive devices, hate mail and other contraband material concealed in incoming mail and packages. Items are placed in the inspection chamber and simply by pressing a push button switch a high resolution image is displayed on the video monitor.

  • Page 6: Unpacking Instructions

    UNPACKING INSTRUCTIONS The installation of the SCANMAX 25 is relatively simple and requires no special tools. It is shipped as a whole in a sturdy ply wood container mounted on a wooden pallet. The shipping crate is designed to withstand normal handling during overseas shipments. Despite these safeguards, damage may occur in transit.

  • Page 7: Fitting Handles

    Fitting of Handles Handles have been provided for the location of the units at the time of installation, when they require to be dismounted from their wheeled base or for relocation of the unit. The handles are universal in that they are designed to fit any of the range of Scanmax units. The outer holes are for the Scanmax 20 the centre for the Scanmax 25 and the inner holes for the Scanmax 15.

  • Page 8: Pre-Installation Guide

    PRE INSTALLATION GUIDE WARNING: To ensure operator safety, radiation emission levels must be checked before putting the SCANMAX into operation (See page 20) Prior to first time operation, it is essential for the safety of the operator and for the long life of the equipment that the following instructions are strictly observed.

  • Page 9: Installation Guide

    INSTALLATION GUIDE Take unit out of box (following the instructions in the previous section) and place on a strong table/base, or the trolley if provided, capable of supporting up to 200 kgs. Take extreme care when lifting as the unit is very heavy (160 kgs/352 lbs). Use a lifting trolley or fork lift truck.

  • Page 10: Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS The SCANMAX 25 utilises an X-ray generator that is lead shielded against radiation emissions. The generation of X-rays stops automatically as soon as the door is opened, accidentally or otherwise. This high level of safety conforms to the strictest protective measures against radiation. The SCANMAX 25 is inspected, and the results documented, prior to shipment to ensure that radiation emission levels are well within the legal requirements.

  • Page 11: Safety Instructions

    SAFETY INSTRUCTIONS WARNING: Radiation hazard can result if this unit is operated improperly. Below is a list of common ways in which this might occur. This is not an exhaustive list and final responsibility for safe operation is rests with the user. Never operate with the safety interlocks defeated.

  • Page 12: Introduction To X-Rays

    Scanna are non residual. That is the x-rays are produced electrically and as soon as the power is removed from the x-ray generator there are no x-rays in the system. The following safety measures and devices are included in the equipment supplied by Scanna MSC. Low x-ray dose.

  • Page 13: Operating Instructions

    OPERATING INSTRUCTIONS Switch on mains isolating switch on the rear panel. Note that the front panel “POWER ON “ indicator on the front control panel illuminates. Insert the key into the key switch and turn a quarter turn to the right ensure that the TV monitor is turned on.
  • Page 14 The SCANMAX 25 should be turned off when not in use and the key removed from the equipment. The key should be kept by a designated key-holder/supervisor Operator maintenance involves only the cleanliness of the unit both inside the inspection chamber and the outside of the unit and regular safety checks to include mains lead etc.

  • Page 15: X-Ray Screening Procedures

    X-RAY SCREENING PROCEDURES Envelopes may be processed in batches, or evenly spread out within the inspection chamber. Larger packages or briefcases should be placed towards the centre of the unit and processed flat and one at a time. Any item screened which shows the presence of anything unusual (i.e., wires, electrical switches, batteries etc), or which contains high density (black) materials which cannot be penetrated should be treated with extreme caution.

  • Page 16: Maintenance

    A radiation leakage check should be carried out using a calibrated radiation level monitor. Please contact your service representative or SCANNA MSC. for most maintenance needs. A few common procedures are described below and all should be referred to your service representative.

  • Page 17: X-Ray Generator And Controller Replacement

    X-ray Generator and Controller Replacement – Trained Service Personnel Only In the event of failure of either the Generator or the controller the Serial number of both the unit and the faulty x-ray generator must be given to SCANNA to ensure that the correct replacement will be supplied.

  • Page 18: Door Adjustment

    Fit the new Controller in reverse order Fit the Controller module. Refit the connectors to the Controller module. Refit the rear connection panel and test the unit. Check the panel interlock for correct operation Door Adjustment: This must be carried out by service representative To re-seat the door in case of mechanical trauma or accidental loosening of screws, use the following procedure: Loosen screws on right side of door and back out the set screws until flush with the...

  • Page 19: Testing For Radiation Leakage

    The camera lens may after a period of time become dusty. It is recommended that any loose dust on the lens should be initially orally blown off and then clean the lens using a proprietary lens or spectacle cleaning cloth ensuring that the lens is not scratched. The lens is normally kept with the aperture wide open (f1.6).

  • Page 20: Illustrations

    View of front panel View of rear panel From Left Mains input (with fuse under) Mains isolating switch Mains for Monitor (if applicable) From bottom Remote “X-ray On” SVGA video Out Trackball...

  • Page 21: Rear Panel Inside & Controller

    View of controller with rear panel open...

  • Page 22: Maintenance Report Sheet

    MAINTENANCE EPORT SHEET Customer Site The Ionising Radiation Regulations (1999) and the Approved Code of Practice, regulate the use of the equipment’s listed. this report and attached Radiation Test Certificate comply with the requirements of the regulations. Equipment Serial No. Item Check Result...

  • Page 23: Radiation Leakage Report Sheet

    SCANNA MSC LIMITED CRITICAL EXAMINATION REPORT Customer: Equipment Type Order No.: Model Serial No.: Date: 1. Scan all seams and mark with an ‘’X’’ any areas than the specified limit 2. Radiation levels are not to exceed 1µSv/hr. at any inspection point.

  • Page 24: Specifications

    SPECIFICATION Height: 1275 cm (42.5 inches) Physical Specifications- Width: 42.8 cm (16.85 inches) Depth: 61.0 cm (24 inches) Weight: 150 kg (330 lb) Height: 53.5 cm (21 inches) Inspection Chamber size Width: 42 cm (16.5 inches) Depth: 56 cm (22 inches) Door Opening Height: 53.5 cm (18 inches)

  • Page 25: Camera

    Camera Specifications VC21 Pick-up device 1/2” Interline-Transfer CCD. No. of Elements 795 (h) x 595 (v) 473025 Sensing Area 4.9 mm x 3.7 mm Scanning System CCIR & SVGA Sync. System Internal. Resolution 752 X 582 Lens Mount C Mount. Minimum illumination 0.02 Lux, F1.4 Output Voltage will work to 0.011x Cpu BOARD...
  • Page 26 CCD CAMERA The VC21 camera has been specifically modified for use with the Scanmax 25 camera system and care must be taken when handling the camera and the lens mountings to ensure that connection of the multi way connector is not damaged or broken. RECAUTIONS •...

  • Page 27: Warranty

    WARRANTY NOTICE: THIS SHIPMENT LEFT OUR FACTORY IN PERFECT CONDITION. If merchandise is delivered in damaged condition, do not reject shipment. Purchaser must have the driver note the damage (or the fact that possible damage exists and inspection will follow, or any shortage or overage) and sign all copies of the freight bill duly noted as damaged.

  • Page 28: Crime Prevention Advice

    CRIME PREVENTION ADVICE Bombs in the Post... Be Alert Look for the unusual:- Shape Wrapping Writing Size Grease Marks Spelling Thickness Postmark Unsolicited mail Scaling Signs of wire or batteries Wrong name, title address If you are suspicious:- DON’T Don’t try to open it. Keep calm Don’t press squeeze or prod it.

  • Page 29: Trouble Shooting

    SCANMAX 25 C TROUBLE SHOOTING Is Power light lit Check that the mains lead is connected. the wall socket and then to the rear Insert key and turn on power. connection panel. Check that the mains socket is active. If not contact electrician...
  • Page 30 SCANMAX 25 C Is X-ray On light lit Is the TV Monitor Switched on Switch on Cont. Are the TV Monitor mains and video cables If faulty replace connected or damaged. Is the Monitor working If faulty, replace Is the camera working.
