Summary of Contents for Arvento Treyki
- Page 1 GPS Mini-Tracking Device INTRODUCTION & USER GUIDE Arvento Mobil Sistemler A.Ş. Cyberpark, Cyberplaza A Blok 5.Kat No:501-A, 06800 Bilkent / ANKARA P: +090 312 265 0595 F: +090 312 265 0544 www.treyki.com www.treyki.com...
- Page 2 GPS Mini-Tracking Device...
-
Page 3: Table Of Contents
CONTENTS 1. Introduction 1.1. Product Description 1.2. Main Features 1.3. Package Content 2. Getting Started 2.1. Charging the Battery 2.2. Install SIM Card 2.3. Appearance 2.4. Button Description 2.5. LED Indicators 2.5.1. Normal Operation 2.5.2. Voice Call 3. Operating the Device 3.1. -
Page 4: Introduction
Internet and can be monitored on a mobile phone or PC. Voice calls can be made using Treyki. Treyki users can answer an incoming call or place outbound calls to pre-defined numbers. -
Page 5: Main Features
1.2.Main Features » GPS personal locator » GSM/SMS/GPRS communication » Omni-directional high sensitive GPS antenna which can receive GPS signal from all direction » Operates all over the world, provided that the region is inside GSM coverage. Supports quad band GSM 850/900/1800/1900 MHz and GPRS Class 10 »... -
Page 6: Package Content
INTRODUCTION 1.3.Package Content Treyki Li-Ion Battery 220 VAC Power Adaptor INTRODUCTION & USER GUIDE... -
Page 7: Getting Started
Only the 220 VAC power adaptor supplied should be used. Using other type of adaptors may damage your Treyki device. Charging with USB cable (optional), via connecting to PC: Connect Treyki device to PC with USB cable... -
Page 8: Install Sim Card
Insert the SIM card into the holder and close the cartridge » Place the battery in Treyki, and close the battery cover. Please, ensure that the SIM PIN is unlocked before inserted into the device. (SIM PIN can be disabled through an ordinary mobile phone). -
Page 9: Appearance
2.3.Appearance Battery LED YES Button GSM LED Speaker (Turn On / Accept Call) Mini USB Connector GPS LED Battery Cover Programmable Button #1 Microphone Programmable Button #2 Belt Apparatus S.O.S. Button NO Button (Turn Off / Reject or End Call) -
Page 10: Button Description
GETTING STARTED 2.4.Button Description When the device is turned off; if you keep pressing the “YES” button for 3 seconds, all LEDs blink for 3 times and the device turns on When there is an incoming call, you may press this button to answer the call When the device is turned on;... -
Page 11: Led Indicators
2.5.LED Indicators 2.5.1.Normal Operation Battery When the AC adapter or USB cable is plugged for charging the battery: The LED turns ORANGE, while the charging process continues. The LED turns GREEN, when the battery is fully charged. When the device is on: The LED blinks in RED, when the battery power level is critically low The LED blinks in ORANGE, when the battery power is low... -
Page 12: Voice Call
GETTING STARTED 2.5.2.Voice Call GSM LED is used for indicating the status of a voice call. The LED blinks in ORANGE quickly, when any programmable button is pressed The LED blinks in quickly with idle intervals, while it is ringing The LED turns GREEN, when the voice call is active The LED blinks in quickly, when dialed number is busy... -
Page 13: Operating The Device
OPERATING THE DEVICE 3.1. Turn On / Off When the device is off: BATTERY Press and hold the YES button for 3 seconds, all LEDs will blink for 3 times in GREEN and the device turns on When the device is on: Press and hold the NO button for 3 seconds, all LEDs will blink for 3 times in RED and the... -
Page 14: Technical Specifications
TECHNICAL SPECIFICATIONS Operating Temperature: 0°C to 60°C deg Dimensions: 66x38x19 mm Weight: 55 g Battery Type: Li-Ion 900mAh Data Storage: 64 Mb GSM Modem Quad-Band GSM/GPRS 850-900-1800-1900 MHz Output power: Class 4 (2W) @ 850 / 900 MHz Class 1 (1W) @ 1800 / 1900 MHz Sensitivity: -108 dBm @ 850 / 900 MHz -107 dBm @ 1800 / 1900 MHz... - Page 15 GSM Antenna Internal Sensors G Sensor (for motion and acceleration detection) Buttons “YES” “NO” “S.O.S.” “1” “2” LED Indicators Battery Connector Mini USB (B) (for PC connection and charging) SAR, Certificates: * The battery life varies depending on the frequency of sending the data requested from the device.
-
Page 16: Safety
FCC regulations prohibit using your wireless device during any air flight. Turn off your Treyki during flight and at all other times as requested by the flight crew by removing the battery. -
Page 17: Battery Safety Precaution
Promptly dispose of used batteries in accordance with local regulations. Battery usage by children should be supervised. Avoid dropping Treyki or its battery. If Treyki or the battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection. -
Page 18: Certification
We, the undersigned Manufacturer, Arvento Mobil Sistemler A.S. Cyberpark, Cyberplaza A Blok 5.Kat No:501-A 06800 Bilkent-Ankara Declare under our sole responsibility that the following product: Product Name : Treyki Brand Name : Arvento Product Type : GPS Mini-Tracking Device to which this declaration relates is in conformity with the essential requirements and other relevant requirements of the R&TTE Directive (1999/5/EC). -
Page 19: Rf Exposure Information (Sar)
15mm away from body. Please keep this distance at all times when the device is turned on and in operation. Product Name: Treyki Brand Name: Arvento Product Type: GPS Mini-Tracking Device to which this declaration relates is in conformity with the essential requirements and other relevant requirements of the R&TTE Directive (1999/5/EC). -
Page 20: Warnings And Notes
WARNINGS AND NOTES 7.1.General Rules The user is obliged to abide by the following rules: The device should be handled and operated in environments that provide the conditions specified in the instruction manual. Otherwise, the guarantee provided by the manufacturer shall be considered void. Spillage on the device of any kind of liquid, opening the case, attempting to alter the internal hardware or contacting the internal hardware with any foreign object may lead to a... -
Page 21: Guarantee
GUARANTEE 8.1.Guarantee Provisions The guarantee period is valid for duration of 1 year starting from the delivery of the product. The product and all its parts are covered by the guarantee provided by our company. In the event that the device fails during the guarantee period, the duration of repair is added to the guarantee period. - Page 22 GUARANTEE In the event that the company's servicing station, or in the absence thereof, the vendor, retailer, agency, representative, importer or manufacturer-producer, respectively, determines in their report that the malfunction is irreparable. Modification of the product, or malfunction due to unauthorized maintenance carried out by the customer or products that our company is not responsible are considered to be outside the scope of guarantee.
-
Page 23: Guarantee Information
8.2.Guarantee Information THE MANUFACTURER AND IMPORTER COMPANY Title : Arvento Mobil Sistemler A.Ş. Address : Cyberpark, Cyberplaza A Blok 5.Kat No:501-A, 06800 Bilkent-Ankara Phone : +090 (312) 265 05 95 : +090 (312) 265 05 44 : www.arvento.com SIGNATURE AND SEAL...
