Summary of Contents for SnowLizard SLXTREME 5
- Page 2 Congratulations on your purchase! Thank you for purchasing the SLXtreme5 for iPhone® 5/5S – the GO-ANYWHERE, DO ANYTHING CASE. It’s more than just a protective case for the iPhone; it’s your essential gear for any outdoor adventure. We hope that you enjoy the freedom and peace of mind that comes from hours, perhaps days of extended use between charges of your...
- Page 3 • Do not place this product near an open • Do not crush or puncture the battery. • Keep away from high voltage devices. • Recharge battery every three months when not in use. • Use soft cloth to clean exterior. Do not use harsh chemicals or strong cleaning solvents.
-
Page 4: Package Contents
PACKAGE CONTENTS 1 – Micro USB cable 1 – SLXtreme5 case for iPhone 5/5S 2 – Audio Plug 1 – Carabiner 1 – Water-tight earphone 1 – Lanyard jack extender... -
Page 5: Product Specifications
PRODUCT SPECIFICATIONS NAME SLXtreme CELL TYPE Lithium-ion Polymer INPUT DC 5V – 500 mAh OUTPUT DC 5V – 1A CAPACITY 2,550 mAh DIMENSIONS 144.5 x 74 x 27 mm WEIGHT 283.5 grams with iPhone 5 COMPATIBILITY iPhone 5/5S ADDED STANDBY TIME Additional 408 hours* ADDED TALK TIME Additional 16.35 hours*... - Page 6 KEY FEATURES 1.LED Charging Indicator Lights 2.Battery recharge button 4.Micro USB Lock Screw 5.Audio Plug 6.Removable watertight earphone jack extender...
- Page 7 7.Speaker 8.Microphone 9.Micro-USB Jack 10.Top Cover 11.Top Cover latch...
-
Page 8: Getting Started
GETTING STARTED The SLXtreme 5 is partially charged and can be used right out of the package, but for best results it is recommended that you fully charge the case’s internal battery. 1.Twist the Micro USB Lock Screw at the bottom of the case to open the bottom compartment and expose the Micro USB Jack. - Page 9 3.The SLXtreme5 case will automatically turn on and four LED light indicators will show the current charge level. The indicators will blink at each level until the integrated battery stays fully illuminated at each level. LED behavior while charging: The LEDs are divided to show an estimated percentage of the battery’s charge.
- Page 10 To determine the power level of the SLXtreme case, press the Battery Re- charge Button: LED lights from left to right: (see more on solar charging, page 13). Example of LED indicating charging by solar panel...
- Page 11 Using SLXtreme5 to Power & Protect your iPhone 5/5S is designed for submerging in water to 30 minutes. Keep the top cover seal free from debris and sand to prevent any leakage. Note: Before using SLXtreme underwater, it is recommended to test fully locked SLXtreme with a paper...
- Page 12 towel folded inside instead of your iPhone to check for leaks prior to use. Submerge in 1 foot of water for 30 minutes and check inside to make sure all locks and seals are water tight. 1.Remove any case or accessory that may be on or connected to your iPhone, including polyurethane removing the phone from the case.
- Page 13 3.Re-latch the Top Cover and the iPhone 5/5S is now secured into the SLXtreme case and is sealed. Make sure cables are removed from their ports and the bottom compart- ment is closed and the Micro USB Lock tightened. Note: To remove phone from case, grip the front and back of phone using top corners of the phone.
- Page 14 Taking Images and Video While Underwater 1.The SLXtreme is meant for water sports enthusiasts, adventurers and extreme outdoor lifestyles. While the touch screen is not responsive underwater, you can still capture photos and video with your iPhone. 2.Use the volume shutter button to snap photos in and out of water or to begin/end recording video.
- Page 15 Using Your Ear Buds and Bluetooth headsets The SLXtreme5 is compatible with ear buds and Bluetooth headsets with the Watertight Earphone Jack Adapter. 1.To connect ear buds, remove the audio plug, close the USB /Audio door and connect the audio jack adapter. 2.Turn 1 quarter to lock.
- Page 16 Using the Rear Solar Panel for Emergency Trickle Charge To charge the SLXtreme5 using the solar panel, face the panel towards the charging. For every hour of sunlight, the SLXtreme5 case’s power is replenished enough to provide approximately 10 minutes of talk time when you are away from an electric power source.
- Page 17 number of apps in use and other variables. Do not allow iPhone battery The Solar Panel trickle charges the SLXtreme case. To charge iPhone enough for a short call, press the Recharge Button for four seconds. For added security, Snow Lizard Products recommends using the carabiner and lanyard included with the SLXtreme.
- Page 18 Further, this warranty applies only to the original purchaser of the Product and all claims must be accompanied by and submitted with proof of purchase. SnowLizard will have no liability for any Product returned if SnowLizard determines that: The product was not purchased from an authorized reseller.
- Page 19 90 days from the date of shipment of the repaired or replaced Product, whichever is longer. There are no warranties that extend beyond the face of the SnowLizard™ Limited Warranty. SnowLizard™ disclaims all other warranties, express or implied, regarding the Products,...
- Page 20 SnowLizard™’s entire liability for any defective Product shall in no event exceed the purchase price of the defective Product. This limitation applies even if SnowLizard™ cannot or does not repair or replace any defective Product and your exclusive remedy fails its essential purpose.
- Page 21 Support For any support regarding your Snow Lizard Product, please contact us at: support@snowlizardproducts.com www.snowlizard.com...
- Page 22 Please note that the use of this accessory with iPhone iPhone® is a registered trademark of Apple, Inc. and iPhone® is a trademark of Apple, Inc. SnowLizard™ is a trademark of Snow Lizard Products, LLC. LLC.
- Page 26 SNOWLIZARD.COM © 2014 Snow Lizard Products, LLC...
