Page 1: User Manual
User Manual Kudos Pro UHD1000 Single Channel Linear SD/HD/3G/UHDTV1 Converter www.s-a-m.com... -
Page 2: Information And Notices
Kudos Pro UHD1000 Information and Notices Information and Notices Copyright and Disclaimer Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc. -
Page 3: Safety Information
Kudos Pro UHD1000 Safety Information Safety Information Issue 1 Rev 2 Page 3 © 2016 SAM... - Page 4 Kudos Pro UHD1000 Safety Information Issue 1 Rev 2 Page 4 © 2016 SAM...
-
Page 5: Mains Power Supplies
Kudos Pro UHD1000 Safety Information Mains Power Supplies This equipment has two 3-pin IEC power sockets, one for the main power supply unit and one for the redundant power supply unit. The power supply is auto switching for input voltages in the ranges of 100 V to 240 V nominal. -
Page 6: Compliance Standards
Kudos Pro UHD1000 Safety Information Compliance Standards This equipment conforms to the following standards: EN60950-1: 2006 Safety of Information Technology Equipment Including Electrical Business Equipment. UL1419 (3rd Edition) - UL File E193966 Standard for Safety – Professional Video and Audio equipment. -
Page 7: Table Of Contents
Kudos Pro UHD1000 Contents Contents Information and Notices ..........2 Copyright and Disclaimer . -
Page 8: Introduction
Kudos Pro UHD1000 Introduction Introduction 1.1 Description The UHD1000 is a motion-adaptive up/down format converter for a range of applications, including: • Integration of HD programming into UHDTV productions. • Provision of HD simultaneous transmissions alongside UHDTV services. • Mixed usage of four quadrant square-division and pixel-interleaved UHDTV content. -
Page 9: Block Diagram
Kudos Pro UHD1000 Introduction • Dual PSU as standard. • Automatic Aspect Ratio Conversion (AFD, VI, L23). • Powerful picture enhancement tools. • User-friendly front panel. • Web interface remote control. • Closed caption, teletext subtitle, and timecode handling. •... -
Page 10: Technical Specification
Kudos Pro UHD1000 Technical Specification Technical Specification Inputs and Outputs Signal Inputs Serial Digital Inputs 4 x 75 Ohm SD/HD/3Gb/s serial digital with embedded audio Input Standards UHDTV1 video interfaces • Square division (4 x 1.5Gbps links) for <= 30fps •... - Page 11 Kudos Pro UHD1000 Technical Specification Output Standards 525 59i 625 50i 720/1080 23/24/25/29/30/50/59/60p 1080 50/59/60i 1080 23/24/25/29/30/50/59/60p 1080 23/24/25/29psf, with film detection and processing 2160 23/24/25/29/30/50/59/60p Conversion Functions Modes SD/HD/3G/UHDTV Up, Down, and Cross Conversion Conversion Linear/Motion Adaptive Aspect Ratio Conversion...
- Page 12 Kudos Pro UHD1000 Technical Specification Mechanical Temperature Range 0 to 40°C operating Cooling Internal fan, side venting Weight 2.4 kg Case Type 1RU, rack mounting Dimensions 44mm x 430mm x 170mm (H x W x D) The AES audio connector may be assigned as either input or output.
-
Page 13: Installation
Kudos Pro UHD1000 Installation Installation Refer to Safety Information on page 3 before installing and connecting power to the unit. Important: 3.1 Unpacking the Unit The unit is packed in a single cardboard box. Unpack the box carefully and check for any shortages or shipping damage. -
Page 14: Connections
Kudos Pro UHD1000 Connections Connections This section describes the physical input and output connections provided by the UHD1000 and UHD1000 with audio option. 4.1 UHD1000 (Base Model) The rear panel accommodates SDI, AES and analog connections. Ethernet Dual PSU Balanced AES &... -
Page 15: Fiber Connectivity
Kudos Pro UHD1000 Connections 4.3 Fiber Connectivity A dual fiber port is available as an option. The port can be configured as one of the following: • Dual receiver (RX/RX) • Dual transmitter (TX/TX) • Transceiver (RX/TX) • Not fitted If no fiber option is fitted on the rear panel, do not remove the safety covers from the option slots. -
Page 16: Audio Connection Pin Numbers (Option)
Kudos Pro UHD1000 Connections 4.4 Audio Connection Pin Numbers (Option) AES audio and analog audio support are available as an option. Connection is via 25-way D-type. Balanced AES audio I/O connectors can be configured as either input or output. Analog Audio I/O... -
Page 17: Front Panel Features
Kudos Pro UHD1000 Front Panel Features Front Panel Features The front panel provides a user-friendly interface for complete control of the unit. Various buttons provide easy access to the unit’s features. 5.1 Front Panel Layout Rotary Control for fast Standby... - Page 18 Kudos Pro UHD1000 Front Panel Features Item Description PSU Status LEDs Shows the status of the dual PSUs. • PSU A illuminated green: PSU A (primary) in use. • PSU B illuminated green: PSU B (secondary) in use. • PSU illuminated red: unit in standby (power saving) mode.
-
Page 19: System Operation
Kudos Pro UHD1000 System Operation System Operation The UHD1000 can be controlled directly, using the front panel hardware buttons, or remotely, using a software UI in a browser window. All operations are possible from either interface. The operating instructions given here focus on operation via the front panel. Operation via the browser-based UI follows the same basic control sequences, and should be self-explanatory. -
Page 20: Using The Front Panel - Basics
Kudos Pro UHD1000 System Operation 6.3 Using the Front Panel - Basics The front panel buttons provide access to the UHD1000 control menus. • Turn the rotary control clockwise to scroll down through a menu list, or anti-clockwise to scroll up. -
Page 21: Resetting Menu Options To Default Values
Kudos Pro UHD1000 System Operation 6.3.4 Resetting Menu Options to Default Values To reset a menu option to its default value: • With the menu option selected, press and hold the rotary control for a few seconds. Issue 1 Rev 2 Page 21 ©... -
Page 22: Front Panel Buttons
Kudos Pro UHD1000 System Operation 6.4 Front Panel Buttons 6.4.1 Input Press Input to specify a video input source. Available functions are: Menu Option Operation Input select Choose from: • Input 1 • Input 2 • Input 3 • Input 4 •... -
Page 23: Output
Kudos Pro UHD1000 System Operation Menu Option Operation In 1-4 conn status None: UHD has not been detected Inconsistent: The detected input is a possible UHD format but does not match the other inputs 2SI input [n]: UHD has been detected. The format is Two-Sample Interleaved. -
Page 24: Video
Kudos Pro UHD1000 System Operation Menu Option Operation UHD 2SI PID Sets the embedded Payload ID for Sample Interleaved. Choose from: • UHD - some monitors may not operate with UHD PID. In these cases, select HD/3G • HD/3G UHD ANC Embed Sets whether ANC (VANC + HANC) data is inserted on all links or just link 1. -
Page 25: Audio
Kudos Pro UHD1000 System Operation Menu Option Operation Color correct Allows corrections to be made to the video color. See section 6.4.3.2. 6.4.3.2 Color Correct Menu Option Operation Enable correct Select On to activate Color correct functions. Red lift Red channel offset can be adjusted from -200mV to +200mV in steps of 0.8mV. - Page 26 Kudos Pro UHD1000 System Operation Audio menus are: • Audio routing • Audio shuffle • Audio control • Analog I/O (audio option only) • AES I/O (audio option only) • In pair status • Out pair status These are described in the sections below.
- Page 27 Kudos Pro UHD1000 System Operation Audio Shuffle Available Choices Invert phase Allows the phase of the left and right audio channels to be inverted. This is useful for dealing with input audio discrepancies. Choices are: • Off (default) • Ch [x] control Choices are: •...
- Page 28 Kudos Pro UHD1000 System Operation 6.4.4.3 Audio Control Audio control adjusts the audio on each processing channel. Audio Control Available Choices Audio gain Audio gain can be adjusted from -18dB to +18dB in steps of 0.1dB. Default is 0dB. First select the required output channel from the list of channels (Out Ch 1 to Out Ch 16), then adjust the gain using the rotary control.
- Page 29 Kudos Pro UHD1000 System Operation Analog I/O Available Choices Out 1 level Adjusts the analog audio DAC level for analog audio output Pair 1, from 12dB to 24dB in steps of 0.5dB. Default is 18dB. Out 2 level Adjusts the analog audio DAC level for analog audio output Pair 2, from 12dB to 24dB in steps of 0.5dB.
-
Page 30: Memory
Kudos Pro UHD1000 System Operation • Silence • Forced silence 6.4.4.7 Out Pair Status Status information is available for each output pair from the output pair list (Output pair 1 to Output pair 8). • • Muted • Test tone •... - Page 31 Kudos Pro UHD1000 System Operation 6.4.7.1 Clean cut Clean cut processing detects scene changes and prevents interpolation across the cut. Only permitted if film cadence is off. Default = Off. 6.4.7.2 Film mode Use Film mode if input is interlaced (1080i or 525 or 625) and contains film-originated content.
- Page 32 Kudos Pro UHD1000 System Operation This control allows the user to define the position of timecode when the 2:3 sequence begins. The assumption is made that the start of the 2:3 sequence is aligned with the start of program and under normal working practices, that the start of program is coincident with an integer hour value.
-
Page 33: Arc
Kudos Pro UHD1000 System Operation This control allows the user to define the starting position of the 2:3 sequence with respect to timecode. It is active only when 2:3 is set to Output timecode and the Timecode generator is set to Drop-Frame, or, when following input timecode, the source has Drop-Frame Timecode present. - Page 34 Kudos Pro UHD1000 System Operation 6.4.8.4 Scaler The Scaler offers preset controls for management of the aspect ratio. The following controls are available: Scaler Presets • Use presets: Enables all presets • SD input is 702: Use for SD incoming content that uses a 702 sample line rather than a 720 sample line.
- Page 35 Kudos Pro UHD1000 System Operation Signaling Src When an SD source contains more than one style of signalling, select the appropriate item: • SMPTE 2016 (default) • L23 ETSI • L23 AFD • VI SMPTE • VI AFD Alternate Center Cut Alternate center cut is Off by default.
- Page 36 Kudos Pro UHD1000 System Operation HD Input Format For HD/UHD inputs, manually select forced format from the list: • Normal (default): use default aspect ratio • 14:9 pillarbox: preserves the original aspect ratio of HD content with a 14:9 aspect ratio, with bars visible at the sides of the screen.
- Page 37 Kudos Pro UHD1000 System Operation In the SD domain, take care to avoid a line clash if embedded VITC and SMPTE 2016 are Note: both enabled. In the event of both VITC and SMPTE being required: • For SD 625 signals, SMPTE2016 is relocated to the line before the VITC line, i.e. if VITC is at default 19 and 21, SMPTE2016 will be placed on either 18 or 20 respectively when there is a clash.
- Page 38 Kudos Pro UHD1000 System Operation Control Options Out line Selects the output line on which L23 information is placed. The range is from line 10 to line 23 in one-line steps. Default = line 23 Out line status Displays line number of where the signaling is placed.
-
Page 39: Enhance
Kudos Pro UHD1000 System Operation AFD: Inserts valid AFD codes when none are present on the input and force mode is enabled. Available codes are: 4:3 AFD 0 16:9 AFD 0 4:3 AFD 1 16:9 AFD 1 4:3 AFD 2... - Page 40 Kudos Pro UHD1000 System Operation Vertical Filter • Narrow: Reduces vertical bandwidth of the HD source prior to up-conversion. May be useful when HD source contains excessive enhancement (ringing), which may be unacceptable in UHD. • Normal (default): Passes all source vertical frequencies without attenuation or boost.
- Page 41 Kudos Pro UHD1000 System Operation Vertical Transient Enhance Sharp horizontal edge detail in the HD source, such as captions and graphics, is identified. The gradient of these transients is increased to occupy the full UHD bandwidth. Some degradation of fine textures may be evident when using higher settings.
- Page 42 Kudos Pro UHD1000 System Operation • Wide 1: Allows some alias frequencies to pass, which may give an apparent increase in picture sharpness. • Wide 2: Allows a wider band of alias frequencies to pass. H Enhance Level Applies horizontal frequency boost to make image visually sharper. Adaptive processing prevents an increase in noise level and excessive boost on textures.
-
Page 43: System
Kudos Pro UHD1000 System Operation • Normal: Optimized bandwidth setting. Passes all horizontal frequencies compatible with the output format. • Wide 1: For HD to SD conversion, allows some alias frequencies to pass which may give an apparent increase in picture sharpness. Will have limited effect in HD to HD conversion. - Page 44 Kudos Pro UHD1000 System Operation source, giving consistent and repeatable delay. If the video output frame rate differs from the genlock source frame rate, the output will 'clock lock' to the genlock source. Clock lock ensures that the output audio 48kHz clock remains locked to the genlock source.
- Page 45 Kudos Pro UHD1000 System Operation Menu Option Operation TC mode • Follow input (default): When active, only the selected source type of ANC packet is inserted into the output video. So, the action on timecode loss is applicable only to the selected ATC type.
- Page 46 Kudos Pro UHD1000 System Operation Closed Captions The Closed captions controls allow closed captions to be enabled or disabled, and the input and output lines used to be specified. Menu Option Operation In status Reports the captions that have been detected.
- Page 47 Kudos Pro UHD1000 System Operation Menu Option Sub-Option RDD08 Out line pkt 1: select line from 8 to 20. Default is line 10. Out line pkt 1 status: reports line number. Out line pkt 2: select line from 8 to 20. Default is line 10.
- Page 48 Kudos Pro UHD1000 System Operation 6.4.10.4 Network Control Function Current IP address Reports the IP address currently assigned to the unit. Current IP gateway Reports the IP address of the gateway currently used by the unit. Current IP netmask Reports the IP netmask currently used by the unit.
-
Page 49: Operation Via Web Browser
Kudos Pro UHD1000 System Operation 6.5 Operation Via Web Browser The UHD1000 can be operated from a web browser as well as from the front panel. Simply type the unit's IP address, shown on the bottom of the Home screen, into a browser address bar. - Page 50 Kudos Pro UHD1000 System Operation Figure 2 Browser Control Interface - Ethernet Set IP Configuration to Fixed Address. Enter IP Address, IP Gateway and IP Netmask details as required. Factory default values can be restored by clicking Default. Click Apply IP Changes to update the network configuration.
- Page 51 Kudos Pro UHD1000 System Operation 6.5.1.3 Upgrading UHD1000 Software New versions of the UHD1000 software are released periodically. Follow the instructions below to install these updates. • Ensure that the upgrade package is readily accessible before beginning the Note: upgrade.
