Vecow IVH-9016-PoER505M User Manual

Quad core intel xeon / core i7/ i5/ i3 fanless in-vehicle system high performance, rugged, extended temp, power protection, ivh-9000 series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Quad Core Intel
®
Xeon
High Performance, Rugged, Extended Temp, Power Protection
IVH-9000
®
/ Core
™
i7/ i5/ i3 Fanless In-Vehicle System
USER
USER
Manual
Manual
1.3.0 Edition 20170509

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVH-9016-PoER505M and is the answer not in the manual?

Questions and answers

Summary of Contents for Vecow IVH-9016-PoER505M

  • Page 1 USER USER IVH-9000 Manual Manual Quad Core Intel ® Xeon ® / Core ™ i7/ i5/ i3 Fanless In-Vehicle System High Performance, Rugged, Extended Temp, Power Protection 1.3.0 Edition 20170509...
  • Page 2 Record of Revision Version Date Page Description Remark 07/13/2016 Preliminary Release 07/28/2016 Official Release 09/06/2016 Update 04/21/2017 Update 05/09/2017 Update...

  • Page 3: Declaration Of Conformity

    This manual is released by Vecow Co., Ltd. for reference purpose only. All product offerings and specifications are subject to change without prior notice. It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation or any infringements upon the rights of third parties, which may result from such use.
  • Page 4 Order Information Part Number Description ® ® IVH-9016- IVH-9000, Quad Core Intel Xeon E3-1505M v5, 18 GbE LAN w/ PoER505M 16 PoE , 4 SSD Tray, 4 COM, 4 USB 3.0, 4 SIM, Isolated DIO, 16 GPIO ® IVH-9016- IVH-9000, Quad Core Intel Core™...
  • Page 5 Order Accessories Part Number Description DDR4 16G Certified DDR4 16GB 2133MHz RAM DDR4 8G Certified DDR4 8GB 2133MHz RAM DDR4 4G Certified DDR4 4GB 2133MHz RAM PWA-280WB-WT 280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin Terminal Block (7.62mm pitch), Wide Temperature -30°C to +70°C PWA-160WB-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin...

  • Page 6: Table Of Contents

    Table of Contents CHAPTER 1 GENERAL INTRODUCTION 1.1 Overview 1.2 Features 1.3 Product Specification 1.3.1 Specifications of IVH-9016-PoER 1.3.2 Specifications of IVH-9008-PoER 1.3.3 Specifications of IVH-9000-2R 1.4 Supported CPU List 1.5 Mechanical Dimension 1.5.1 Dimensions of IVH-9016-PoER 1.5.2 Dimensions of IVH-9008-PoER 1.5.3 Dimensions of IVH-9000-2R CHAPTER 2 GETTING TO KNOW YOUR IVH-9000 2.1 Packing List...
  • Page 7 3.5 Installing CFast Card and SIM Card 3.6 Installing SSD/HDD 3.7 Mounting Your IVH-9000 CHAPTER 4 BIOS AND DRIVER SETTING 4.1 Entering Setup 4.2 Main Menu 4.3 Advanced Functions 4.4 Chipset Functions 4.5 Security Functions 4.6 Boot Functions 4.7 Save & Exit APPENDIX A : ISOLATED DIO GUIDE APPENDIX B : GPIO &...

  • Page 8: Chapter 1 General Introduction

    6V to 78V power input with 200V surge protection, configurable ignition power control, intelligent circus protection and rugged reliability in harsh environments, Vecow IVH-9000 Series Fanless Vehicle Computing System is your perfect choices for Rolling Stock System, Machine Vision, Intelligent Transportation System (ITS), Mobile DVR/NVR, Intelligent Surveillance, Fleet Management, Industry 4.0, Internet of Things (IoT) and any...

  • Page 9: Product Specification

    6 SATA III (6Gbps) support software RAID 0, 1, 5, 10 mSATA 1 SATA III (Mini PCIe Type, 6Gbps) Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector • 4 Front-access 2.5" SSD/ HDD Tray ©Vecow IVH-9000 User Manual GENERAL INTRODUCTION...
  • Page 10 Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219 Gigabit LAN supports iAMT 11.0 ® LAN 2 Intel I210 Gigabit LAN ® LAN 3 to LAN 18 Gigabit IEEE 802.3at (25.5W/48V) PoE by Intel I350 Power...

  • Page 11: Specifications Of Ivh-9008-Poer

    Shared Memory, up to 1.7GB Interface • DVI-D : Up to 1920 x 1200 @ 60Hz • DisplayPort 1 : Up to 4096 x 2304 @ 60Hz • DisplayPort 2 : Up to 4096 x 2304 @ 60Hz ©Vecow IVH-9000 User Manual GENERAL INTRODUCTION...
  • Page 12 Storage SATA 6 SATA III (6Gbps) support software RAID 0, 1, 5, 10 mSATA 1 SATA III (Mini PCIe Type, 6Gbps) Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector • 4 Front-access 2.5" SSD/ HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out...

  • Page 13: Specifications Of Ivh-9000-2R

    4 Mini PCIe Socket : • 1 Mini PCIe Socket for PCIe/ USB/ Internal SIM Card/ Optional mSATA • 3 Mini PCIe Socket for PCIe/ USB/ External SIM Card SUMIT A, B 2 SUMIT Slot (Optional) ©Vecow IVH-9000 User Manual GENERAL INTRODUCTION...
  • Page 14 Graphics ® Graphics Processor Intel HD Graphics P530/ 530 Display Memory Shared Memory, up to 1.7GB Interface • DVI-D : Up to 1920 x 1200 @ 60Hz • DisplayPort 1 : Up to 4096 x 2304 @ 60Hz • DisplayPort 2 : Up to 4096 x 2304 @ 60Hz Storage SATA 6 SATA III (6Gbps) support software RAID 0, 1, 5, 10...

  • Page 15: Supported Cpu List

    Up to 2.80 GHz Core i5-6440HQ Up to 3.50 GHz Core i5-6350HQ Up to 3.20 GHz Core i5-6300HQ Up to 3.20 GHz Core i5-6440EQ Up to 3.40 GHz Core i5-6442EQ Up to 2.70 GHz ©Vecow IVH-9000 User Manual GENERAL INTRODUCTION...

  • Page 16: Mechanical Dimension

    1.5 Mechanical Dimension 1.5.1 Dimensions of IVH-9016-PoER 297 (11.7) 282 (11.1) 297 (11.7) 260 (10.2) Unit: mm (inch) 1.5.2 Dimensions of IVH-9008-PoER 297 (11.7) 282 (11.1) 297 (11.7) 260 (10.2) Unit: mm (inch) 1.5.3 Dimensions of IVH-9000-2R 297 (11.7) 282 (11.1) 297 (11.7) 260 (10.2) Unit: mm (inch)

  • Page 17: Chapter 2 Getting To Know Your Ivh-9000

    IVH-9000 series may contain SSD/HDD and DDR4 SO-DIMM. Please verify these items if necessary.) Accessory box, which contains ● Vecow Drivers & Utilities DVD ● Wall-mounting bracket ● KHS#6-32x6 screw for wall-mounting bracket ● M2.5x6 screw for Mini PCIe socket ●...

  • Page 18: Front Panel I/O Functions

    2.2 Front Panel I/O Functions In Vecow IVH-9000 series family, all I/O connectors are located on front panel and rear panel. Most of the general connections to computer device, such as USB, LAN Jack, Display, DVI-D, Display Port and any additional storage, are placed on the front panel.
  • Page 19 Please do note that a 4-second interval between each 2 power-on/ power-off operation is necessary in normal working status. (For example, once turning off the system, you have to wait for 4 seconds to initiate another power-on operation). ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 20 2.2.3 CFast Card SIM 3 SIM 4 DVI-D DP 1 DP 2 LAN 1 LAN 2 USB 3.0 USB 3.0 RESET SIM 2 WLAN CFast POWER There is a CFast socket on the front panel supporting Type-I/II Compact Flash card. It is implemented by a SATA III Port from CM236 PCH.
  • Page 21 1920 x 1200 resolution and output mode supports up to 1920 x 1200 resolution. The DVI is automatically selected according to the display device connected. You will need a DVI-D cable when connecting to a display device. ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 22 2.2.6 DisplayPort SIM 3 SIM 4 DVI-D DP 1 DP 2 LAN 1 LAN 2 USB 3.0 USB 3.0 RESET SIM 2 WLAN CFast POWER Onboard Display Port support auxiliary channel dual mode, connection supports up to 4096x2304 resolution at 60 Hz. Multi-Stream Transport Display Resolutions Table: Multi-Stream Transport Display Max.
  • Page 23 The SIM card sockets do not support hot-plug. Please make sure to unplug the system power before inserting the SIM card(s). Mini Mini Mini PCIe 4 PCIe 3 PCIe 2 Mini PCIe 1 mSATA ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 24 2.2.9 10/ 100/ 1000 Mbps Ethernet Port SIM 3 SIM 4 DVI-D DP 1 DP 2 LAN 1 LAN 2 USB 3.0 USB 3.0 RESET SIM 2 WLAN CFast POWER There are 2 8-pin RJ-45 jacks supporting 10/ 100/1000 Mbps Ethernet connections in the front side.
  • Page 25 There are 4 front-access 2.5” SSD/ HDD trays in the front side of IVH-9000. Just trigger to open the SSD/ HDD tray, up to 8TB is available. HDD Tray MB Connector HDD 1 SATA1 HDD 2 SATA2 HDD 3 SATA3 HDD 4 SATA4 ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...

  • Page 26: Rear Panel I/O And Functions

    2.3 Rear Panel I/O and Functions 2.3.1 Power Terminal Block DC-IN 6~78V PIN 1 ~ 8 PIN 11 ~ 18 LED+ LED On / Off Power LAN 17 LAN 15 LAN 13 LAN 11 LAN 9 LAN 7 LAN 5 LAN 3 Switch LAN 18...
  • Page 27 SIO_GPI86 OUTPUT 5 SIO_GPO75 INPUT 7 SIO_GPI87 OUTPUT 6 SIO_GPO76 DI_COM ----------- OUTPUT 7 SIO_GPO77 ----------- N.C. ----------- OUTPUT 0 SIO_GPO70 External 6V to 36V DC ----------- OUTPUT 1 SIO_GPO71 Input ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 28 24V Application Diagram : GPI SINK Mode Isolated GPI input circuit in SINK mode (NPN) is illustrated as follow : GPI SOURCE Mode Digital GPI input signal circuit in SOURCE mode (PNP) is illustrated as follow : GPO SINK Mode Digital GPO output circuit in SINK mode (NPN) is illustrated as follow : GETTING TO KNOW YOUR IVH-9000...
  • Page 29 Port (5-wire) (9-wire) (3-wire) TXD- TXD- DATA- TXD+ TXD+ DATA+ RXD+ RXD+ ----------- RXD- RXD- ----------- 1 to 4 ----------- RTS- ----------- ----------- RTS+ ----------- ----------- CTS+ ----------- ----------- CTS- ----------- ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 30 2.3.6 PoE (Power over Ethernet) Ports DC-IN 6~78V PIN 1 ~ 8 PIN 11 ~ 18 LED+ LED On / Off Power LAN 17 LAN 15 LAN 13 LAN 11 LAN 9 LAN 7 LAN 5 LAN 3 Switch LAN 18 LAN 16 LAN 14 LAN 12...
  • Page 31 Intel High Definition Audio (Azalia) specifications. To utilize the audio function in Windows platform, you need to install ® corresponding drivers for both Intel CM236 chipset and Realtek ALC892 codec. ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...

  • Page 32: Main Board Expansion Connectors

    2.4 Main Board Expansion Connectors 2.4.1 Inside View of IVH-9000 Main Board With Connector Location CN22 CN37 CN40 CN17 SATA4 SATA6 SATA2 SATA5 SATA1 SATA3 CN32 CN29 CN20 JP5 CN18 CN31 CN28 CN21 JP6 CN19 CN26 SUMITB CN10 CN39 BAT1 SUMITA GETTING TO KNOW YOUR IVH-9000...
  • Page 33 LED indicator, reset button, power LED indicator, and power-on/ off button, which already can be accessed by front panel and top panel. The pin-outs of Miscellaneous port are listed in following table: ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 34 Group Pin No. Description HDD_LED_P HDD LED HDD_LED_N FP_RST_BTN_N RESET BUTTON Ground PWR_LED_P POWER LED PWR_LED_N FP_PWR_BTN_IN POWER Ground BUTTON 2.4.4 CN26 : Internal Remote Header For External Remote Terminal Block, 2.0mm 1x6p Header CN26 Pin No. Definition Pin No. Definition Power LED+ Power LED-...
  • Page 35 Slot1 / U2 DDR4 Channel A Slot2 / U3 DDR4 Channel B 2.4.6 CN1 : BIOS Socket If the BIOS needs to be changed, please contact the Vecow RMA service team. ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 36 2.4.7 SATA 1 to 6 Connector Standard 7 PIN SATA Connector There are 6 onboard high performance Serial ATA III. It supports higher storage capacity with less cabling effort and smaller required space. The pin assignments of SATA 1 to 6 are listed in the following table : SATA4 SATA6 SATA2...
  • Page 37 Pin No. Definition USB +VCC DATA- (+V5/Max. 0.5A) DATA+ Ground 2.4.10 SUMIT A, SUMIT B This system have standard SUMIT A and SUMIT B for SUMIT type add on cards. SUMITB SUMITA ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 38 SUMIT A Pin Out: Pin No. Function Pin No. Function +5V_AUX +12V +3.3V SMB_DATA +3.3V XMB_CLK Reserved Reserved Reserved SPI_MISO USB_OC# SPI_MOSI Reserved SPI_CLK SPI_CS10 USB_3+ SPI_CS1# USB_3- Reserved LPC_DRQ1# USB_2+ LPC_AD0 USB_2- LPC_AD1 LPC_AD2 USB_1+ LPC_AD3 USB_1- LPC_FRAME# SERIRQ# USB_0+ Reserved USB_0-...
  • Page 39 B_PER_N0 C_CLKP B_CLKP C_CLKN B_CLKN CPRSNT#/C_PE_CLKREQ# C_PET_P0 C_PER_P0 C_PET_N0 C_PER_N0 C_PET_P1 C_PER_P1 C_PET_N1 C_PER_N1 C_PET_P2 C_PER_P2 C_PET_N2 C_PER_N2 C_PET_P3 C_PER_P3 C_PET_N3 C_PER_N3 PERST# WAKE# Reserved Reserved Reserved +3.3V +3.3V +3.3V +5V_AUX ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 40 2.4.11 CN4 : Mini PCIe 1/ mSATA Mini PCIe and mSATA share the same form factor and similar electrical pinout assignments on their connectors. There is no clear mechanism to distinguish if a mSATA drive or a Mini PCIe device is plugged into the socket until recently that SATA I/O issued an ECN change (ECN #045) to redefine pin-43 on mSATA connector as “no connect”...
  • Page 41 Reserved +3.3Vaux USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V PERn0 PERp0 +3.3Vaux PERST# Reserved reserved Reserved Mechanical Key UIM_VPP REFCLK+ UIM_RESET REFCLK- UIM_CLK UIM_DATA CLKREQ# UIM_PWR Reserved 1.5V Reserved WAKE# 3.3Vaux ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 42 2.4.12 CN6, 8,10 : Mini PCIe 2, 3, 4 Standard full length Mini PCIe slot CN10 Mini PCIe 2 Mini PCIe 4 Mini PCIe 3 CN6, 8, 10: Pin No. Signal Name Pin No. Signal Name Reserved +3.3Vaux Reserved Reserved +1.5V Reserved Reserved...
  • Page 43 USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V PERp0 PERn0 +3.3Vaux PERST# Reserved reserved Reserved Mechanical Key UIM_VPP REFCLK+ UIM_RESET REFCLK- UIM_CLK UIM_DATA CLKREQ# UIM_PWR Reserved 1.5V Reserved WAKE# 3.3Vaux ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 44 2.4.13 CN12 : GPIO This system offers sixteen programmable I/O within TTL 5V (1mA max. /pin) tolerance. If the GPIO is logic high, it indicates that the mapping SIO GPIO pin is logic high level. If the GPIO is logic low, it indicates that the mapping SIO GPIO pin is logic low level.
  • Page 45 The system’s real-time clock is powered by a lithium battery. It is equipped with Panasonic BR2032 190mAh lithium battery. It is recommended that you do not the lithium battery on your own. If the battery needs to be changed, please contact the Vecow RMA service team. BAT1 2.4.15 FAN1 : FAN Header Fan power connector supports for additional thermal requirements.
  • Page 46 2.4.16 CN37 : LPC Port 80 Header The systems provide a LPC Port 80 Header for debug card. CN37 Pin out: Pin No. Function Pin No. Function SERIRQ LFRAME# +3.3V LAD0 RESET# Ground LAD1 CLOCK LAD2 Ground 2.4.17 J6 : LAN 2 i210 Reserved Header LAN 2 provides a header for IEEE1588 related applications.
  • Page 47 CN29: Pin No. Description LAN Port Pin No. Description LAN Port Ground Ground SPD0_0 LAN7 SPD2_0 LAN8 SPD0_1 LAN7 SPD2_1 LAN8 SPD0_2 LAN7 SPD2_2 LAN8 SPD0_3 LAN7 SPD2_3 LAN8 Ground Ground ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 48 Ground Ground SPD1_0 LAN9 SPD3_0 LAN10 SPD1_1 LAN9 SPD3_1 LAN10 SPD1_2 LAN9 SPD3_2 LAN10 SPD1_3 LAN9 SPD3_3 LAN10 Ground Ground CN31: Pin No. Description LAN Port Pin No. Description LAN Port Ground Ground SPD0_0 LAN11 SPD2_0 LAN12 SPD0_1 LAN11 SPD2_1 LAN12 SPD0_2 LAN11...
  • Page 49 Pin No. Description Port Pin No. Description Port Ground_Frame COM3 Ground_Frame COM4 Ground COM3 Ground COM4 COM3 COM4 COM3 COM4 COM3 COM4 COM3 COM4 COM3 COM4 COM3 COM4 COM3 COM4 COM3 COM4 ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 50 2.4.20 CN39 : GPS Module Header P1/External Antenna Cable connector The system optional with a GPS module and provides a pair of inputs for the hardware speed-pulse and forward/reverse direction indication. The dead- reckoning capability relies on speed information from either the hardware speed- pulse or messages indicating vehicle speed.

  • Page 51: Main Board Jumper & Deep Switch Settings

    You may configure your card to match the needs of your application by DIP switch as shown below (the deep switch on and off) 1 : OFF 1 : ON 1 : ON 2 : OFF 2 : OFF 2 : ON ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 52 2.5.2 JP1, JP2 : USB Wake Up Front Plane View : SIM 3 SIM 4 DVI-D DP 1 DP 2 LAN 1 LAN 2 USB 3.0 USB 3.0 RESET SIM 2 WLAN CFast POWER Jumper Setting Function USB Port Non Wake Up support As front plane view blue mark Supported Wake Up(Default) As front plane view blue mark...
  • Page 53 COM2 +12V (0.5A max.) RI(Default) Pin Header Pin No. Description +5V (1A max.) COM3 +12V (0.5A max.) RI(Default) Pin Header Pin No. Description +5V (1A max.) COM4 +12V (0.5A max.) RI(Default) ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 54 2.5.4 SW3, SW4 : COM Port RS-422/RS-485 Receiver Terminator DIP Switch Function Description SW 3-1 *Enable COM1 RS-422/485 Receiver Terminator Disable DIP Switch Function Description SW 3-2 *Enable COM2 RS-422/485 Receiver Terminator Disable DIP Switch Function Description SW 4-1 *Enable COM3 RS-422/485 Receiver Terminator Disable...
  • Page 55 2.5.6 SW1 : CMOS & ME Clear DIP Switch Function Description SW 1-1 Clear CMOS CMOS Clear Setting *Normal DIP Switch Function Description SW 1-2 Clear ME ME Clear Setting *Normal ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 56 2.5.7 SW2 : Mini PCIe1 & mSATA Select DIP Switch Function Description SW 2-1 Fixed On PCIe CMOS Clear Default Setting Mini PCIe1 Auto Select (By PIN 43) GETTING TO KNOW YOUR IVH-9000...

  • Page 57: Ignition Control

    2.6.1 Adjust Ignition Control Modes IVH-9000 series provide sixteen modes of different power on/off delay periods adjustable via SW5 switch. The default rotary switch is set to 0 in ATX/AT power mode. ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...
  • Page 58 The modes are listed in the following table: DIP-Switch Power on delay Power off delay Switch Position Position ATX/AT mode No delay No delay No delay 5 seconds No delay 10 seconds No delay 20 seconds 5 seconds 30 seconds 5 seconds 60 seconds 5 seconds...
  • Page 59 3. For proper ignition control, the power button setting should be “Power down” mode. In Windows, for example, you need to set “When I press the power button” to "Shut down." ©Vecow IVH-9000 User Manual GETTING TO KNOW YOUR IVH-9000...

  • Page 60: Chapter 3 System Setup

    SYSTEM SETUP 3.1 How to Open Your IVH-9000 Step 1 Remove six KHS#6-32 screws (circled in red) and two DVI-D #4-40 screws (circled in Yellow) in the front side. Step 2 Take off the front panel. Step 3 Remove one KHS#6-32 screw on the rear panel. HARDWARE INSTALLATION...
  • Page 61 Step 4 Remove four F#6-32x6 screws in the bottom side. Step 5 Turn the bottom side up. Take off the lower cover slowly and carefully. Step 6 Put down the bottom side at rear panel. ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...

  • Page 62: Installing Ddr4 So-Dimm Modules

    3.2 Installing DDR4 SO-DIMM Modules Step 1 DDR4 RAM module into SO-DIMM slot. Step 2 Make sure the RAM module is locked by the memory slot. HARDWARE INSTALLATION...

  • Page 63: Installing Mini Pcie Card

    3.3 Installing Mini PCIe Card Step 1 Install Mini PCIe card into the Mini PCIe socket. Step 2 Fasten one M2.5 screw. ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...

  • Page 64: Installing Antenna Cable

    3.4 Installing Antenna Cable Step 1 Check antenna cable and washers. Step 2 Remove the rubber corks on the rear panel. HARDWARE INSTALLATION...
  • Page 65 Step 3 Put antenna cable connector into the hole on rear panel and fasten washer 1, washer 2, and washer 3 on the antenna cable connector. Step 4 Finish. ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...

  • Page 66: Installing Cfast Card And Sim Card

    3.5 Installing CFast Card and SIM Card Step 1 Remove two F-M3x4 screws on CFast Card and SIM Card cover from the front panel. Step 2 Remove CFast Card and SIM Card cover from the front panel. HARDWARE INSTALLATION...
  • Page 67 Step 3 Before Inserting CFast & SIM Card, make sure the system power is unplugged. Step 4 Insert CFast card and push to lock. Step 5 Insert SIM card and push to lock. Step 6 SIM card and CFast card are installed ready. ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...

  • Page 68: Installing Ssd/Hdd

    3.6 Installing SSD/HDD Step 1 Use the trigger and open SSD/HDD tray. Step 2 Insert 2.5” SSD/HDD into the tray. HARDWARE INSTALLATION...
  • Page 69 Step 3 Close the SSD/HDD tray. Step 4 Lock the SSD/HDD tray with key. ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...

  • Page 70: Mounting Your Ivh-9000

    3.7 Mounting Your IVH-9000 3.7.1 Wall Mount Bracket Step 1 Ensure the screw holes on the right and left side of the upper case match the ones on IVH-9000 wall mount bracket. HARDWARE INSTALLATION...
  • Page 71 ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...
  • Page 72 3.7.2 VESA Mount Step 1 IVH-9000 and VESA Mount. Step 2 Take IVH-9000 and VESA Mount and fasten four KHS#6-32 screws in the four marked corners.. HARDWARE INSTALLATION...
  • Page 73 Step 3 Fasten four KHS#6-32 screws and then finish. Step 4 Finish. Step 5 VESA size have 75x75mm(red) and 100x100mm(yellow). ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...
  • Page 74 3.7.3 Din Rail Kit Step 1 IVH-9000 and Din Rail Kit. Step 2 Take IVH-9000 and Din Rail Kit and fasten four KHS#6-32 screws in the four marked corners. HARDWARE INSTALLATION...
  • Page 75 Step 3 Fasten four KHS#6-32 screws and then finish. Step 4 Finish. Step 5 IVH-9000 With Din Rail. ©Vecow IVH-9000 User Manual HARDWARE INSTALLATION...

  • Page 76: Chapter 4 Bios And Driver Setting

    BIOS AND DRIVER SETTING 4.1 Entering Setup BIOS provides an interface for users to check and change system configuration. The BIOS setup program is accessed by pressing the <Del> key when POST display output is shown. Figure 4-1: Entering Setup Screen BIOS AND DRIVER SETTING...

  • Page 77: Main Menu

    There are two options on Main menu. Figure 4-2: BIOS Main Menu System Date Set the date. Use <Tab> to switch between date elements. System Time Set the time. Use <Tab> to switch between time elements. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...

  • Page 78: Advanced Functions

    4.3 Advanced Functions Select advanced tab to enter advanced BIOS setup options, such as CPU configuration, SATA configuration, and USB configuration. Figure 4 3: BIOS Advanced Menu 4.3.1 ACPI Settings Figure 4 3-1: ACPI Settings Enable Hibernation Enables or disables system's ability to hibernate (OS/S4 sleep state). This option may not be effective with some OS.
  • Page 79 4.3.3 PCH-FW Configuration Figure 4 3-3: PCH-FW Settings ME Unconfig on RTC Clear State Disabling this option will cause ME not to unconfigure on RTC clear. ME State Set ME to Soft temporarily disabled. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...
  • Page 80 4.3.4 SMART Settings Figure 4-3-4: SMART Settings SMART Self Test Run SMART self test on all HDDs during POST. 4.3.5 IT8786 Super IO Configuration Figure 4-3-5: Super IO Settings Serial Port 1 Configuration Set parameters of serial port 1 (COM1). Serial Port 2 Configuration Set parameters of serial port 2 (COM2).
  • Page 81 Console redirection enable or disable. Console Redirection Settings These settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...
  • Page 82 4.3.8 CPU Configuration Figure 4-3-8: CPU Function Settings Hyper-threading Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and disabled for other OS (OS not optimized for Hyper-Threading Technology). When disabled only one thread per core is enabled. Active Processor Cores Number of cores to enable in each processor package.
  • Page 83 Package C State limit Package C State limit. Intel TXT(LT) Support Enables or disables Intel (R) TXT (LT) support. 4.3.9 Intel TXT Information Display Intel TXT information. Figure 4-3-9: Intel TXT Information BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...
  • Page 84 4.3.10 CPU Configuration Figure 4-3-10: SATA Devices Settings SATA Controller(s) Enable or disable SATA Device. SATA Mode Selection Determines how SATA controller(s) operate. Software Feature Mask Configuration RAID OROM/RST driver will refer to the SWFM configuration to enable or disable the storage features. Aggressive LPM Support Enable PCH to aggressively enter link power state.
  • Page 85 4.3.11 Acoustic Management Configuration Figure 4-3-11: Acoustic Management Settings Acoustic Management Configuration Option to enable or disable automatic acoustic management. 4.3.12 CSM Configuration Figure 4-3-12: CSM Settings BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...
  • Page 86 CSM Support Enable/disable CSM support GateA20 Active UPON REQUEST - GA20 can be disabled using BIOS services. ALWAYS - do not allow GA20 to be disabled; this option is useful when any RT code is executed above 1MB. Option ROM Messages Set display mode for Option ROM.
  • Page 87 Maximum time the device will take before it properly reports itself to the Host Controller. 'Auto' uses default value, for a root port it is 100 ms, for a hub port the delay is taken from the hub descriptor. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...

  • Page 88: Chipset Functions

    4.4 Chipset Functions Figure 4-4: BIOS Chipset Menu System Agent (SA) Configuration System Agent (SA) parameters. PCH-IO Configuration PCH parameters. 4.4.1 System Agent (SA) Configuration Figure 4-4-1: System Agent Settings VT-d VT-d capability. GMM Device (B0:D8:F0) Enable/disable SA GMM device. Above 4GB MMIO BIOS assignment Enable/disable above 4GB MemoryMappedIO BIOS assignment.
  • Page 89 DVMT Total Gfx Mem Select DVMT5.0 total graphic memory size used by the internal graphics device. Cd Clock Frequency Select the highest Cd clock frequency supported by the platform. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...
  • Page 90 4.4.4 Memory Information Displays memory information. Figure 4-4-4: Memory Information 4.4.5 PCH-IO Configuration Figure 4-4-5: PCH-IO Settings PCH LAN Controller Enable or disable onboard NIC. Wake on LAN Enable or disable integrated LAN to wake the system. (The wake On LAN cannot be disabled if ME is on at Sx state.) Serial IRQ Mode Configure serial IRQ mode.
  • Page 91 Intel(R) Ethernet Controller I350 LAN 4 Enable or disable of I350 LAN. MiniPCIe Slot 1 MiniPCIe slot settings. MiniPCIe Slot 2 MiniPCIe slot settings. MiniPCIe Slot 3 MiniPCIe slot settings. MiniPCIe Slot 4 MiniPCIe slot settings. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...
  • Page 92 4.4.7 BIOS Security Configuration of PCH-IO Figure 4-4-7: BIOS Security Settings BIOS Lock Enable/disable the PCH BIOS Lock Enable (BLE bit) feature. 4.4.8 SB Porting Configuration of PCH-IO Figure 4-4-8: RAID ROM Settings SATA RAID ROM Legacy ROM: Legacy option ROM UEFI Driver: UEFI Raid Driver Both: Run the Legacy Option ROM and UEFI driver.

  • Page 93: Security Functions

    Discard or save changes option in setup does not have any impact on HDD when password is set or removed. If the 'Set HDD User Password' option is gray, do power cycle to enable the option again. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...

  • Page 94: Boot Functions

    4.6 Boot Functions Figure 4-6: BIOS Boot Menu Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state. Quiet Boot Enables or disables Quiet Boot option. Boot Option Sets the system boot order.

  • Page 95: Save & Exit

    Restore/load default values for all the setup options. Save as User Defaults Save the changes done so far as user defaults. Restore User Defaults Restore the user defaults to all the setup options. BIOS AND DRIVER SETTING ©Vecow IVH-9000 User Manual...

  • Page 96: Appendix A : Isolated Dio Guide

    APPENDIX A : ISOLATED DIO GUIDE A.1 IO Pin Definition GPIO Pin Base Address Usage 10, 13, 14, 17 ----------- 0xA00 11, 12, 15, 16 CN16-GPIO 20 ~ 27 0xA01 ----------- 30, 31, 34 ----------- 0xA02 32, 33, 35 ~ 37 CN16-GPIO 40 ~ 47 0xA03...
  • Page 97 OUTPUT 6 INPUT 7 OUTPUT 7 DI_COM DI COM N.C. DIO GND External DC External 6-36V DC A.3 DIO Signal Circuit 24V Application Diagram: DI in SINK mode (NPN) Signal Circuit of Input NPN Appendix A ©Vecow IVH-9000 User Manual...
  • Page 98 DO in SINK mode (NPN) Signal Circuit of output NPN DI in SOURCE mode (PNP) Signal Circuit of Input NPN A.4 Software Package contain There are three folders with the following inside: ● Driver folder includes x32 & x64 versions ●...
  • Page 99 In Driver folder, you can find the files below inside. Please right click the batch file that is chosen by your OS version, and run as administrator. Please press any key to install Framework 3.5. Please press any key to restart. Appendix A ©Vecow IVH-9000 User Manual...
  • Page 100 On Device Manager,“VECOW Embedded IO Access” will be added. A.6 DIO Demo Tool Execute DIO demo tool (IVH9K.exe). Operation on DIO demo tool utility. Operation on DIO demo tool utility. Click “Read” button to get value; Input any number in Write and Write Mask textbox, and click “Write”...

  • Page 101: Appendix B : Gpio & Wdt Functions

    Return: if success return 1; else return 0. Mask [bit]=0 for read; [bit]=1 for write; If no Mask, write all int Set_WDT(unsigned long time); Description: Set WDT Time for WDT. Return: if success return 1; else return 0. Appendix B ©Vecow IVH-9000 User Manual...

  • Page 102: Appendix C : Raid Installation Guide

    APPENDIX C : RAID Installation Guide C.1 SATA Mode for RAID Please select SATA device to RAID mode on BIOS menu. Advanced → SATA Configuration → SATA Mode Selection C.2 OS Installation IVH-9000 is featured with eight SATA, including six internal SATA, 1 mSata, and 1 CFast.
  • Page 103 C.6 To Create RAID Volume on “Rapid Storage Technology” Software IVH-9000 is featured with six SATA HDDs for RAID volume, so there are three options for choose on this page. Let’s take RAID 1 as an example, please select ”RAID 1”. Appendix C ©Vecow IVH-9000 User Manual...
  • Page 104 C.7 Disk Management : Partition the Disk After RAID 1 volume created, you can see the figure of SATA device allocation. You will find “Volume_0000” in SATA device at BIOS menu. To start Disk Management tool, select "initialize disk." Then add “Logical Device” for Windows access. C.8 If One SATA HDD on RAID Volume is Out-of-use After RAID 1 volume created, you can see the figure of SATA device allocation.
  • Page 105 A warning will pop-up to ask you if the disk is not a member of the original RAID volume. If you press “Rebuild”, it will replace the broken SATA HDD to the last SATA HDD of RAID volume. Appendix C ©Vecow IVH-9000 User Manual...

  • Page 106: Appendix D : Power Consumption

    APPENDIX D : Power Consumption Testing Board IVH-9000 16GB x 2 USB-1 USB Keyboard Logitech K120 USB-2 USB Mouse Microsoft 1113 USB-3 USB Flash Transcend 3.0 8GB USB-4 USB Flash Transcend 3.0 8GB CFAST Innodisk Cfast 3ME3 64GB SATA 0 Transcedn SATA-3 SSD420 256GB SATA 1 Seagate HDD 160GB...
  • Page 107 1505M v5 ® Xeon 2.210A 53.04W 2.520A 60.48W 1505M v5 ® Xeon 1.120A 53.76W 1.230A 59.04W 1505M v5 ® Xeon 0.880A 52.80W 0.980A 58.80W 1505M v5 ® Xeon 0.670A 52.26W 0.740A 57.72W 1505M v5 Appendix D ©Vecow IVH-9000 User Manual...
  • Page 108 D.2 Intel® Core™ i7-6820EQ (8M Cache, 2.80 GHz) Power on and boot to Win7 64bit Idle Status : Standby Mode Sleep Mode CPU usage less 3% Power Input Current Consumption Current Consumption Current Consumption Core™ i7- 1.460A 08.76W 1.650A 09.90W 5.230A 31.38W 6820EQ...
  • Page 109 6440EQ Core™ i5- 0.991A 47.57W 1.133A 54.38W 6440EQ Core™ i5- 0.776A 46.56W 0.904A 54.24W 6440EQ Core™ i5- 0.587A 45.79W 0.690A 53.82W 6440EQ ** If more help is needed, please contact Vecow technical support ** Appendix D ©Vecow IVH-9000 User Manual...
  • Page 110 No part of this publication may be reproduced in any form or by any means, electric, photocopying, or recording, without prior authorization from the publisher. The rights of all the brand names, product names, and trademarks belong to their respective owners. © Vecow Co., Ltd. 2016. All rights reserved.
