18V NI-CD – 20V LITHIUM ION UPGRADE KIT
NOTE:
This upgrade kit
converts existing 18V
Ni-Cad tools with Ni-Cd
battery #134458 to 20V
Li-ion.
Battery:
Charger type:
Will charge battery types:
Charger input:
Charger output:
Need Assistance?
Call us on our toll free customer support line:
1-866-349-8665 Monday – Friday from 9am to 5pm
Eastern Standard Time
Technical questions
Replacement parts
Parts missing from package
Manufactured For and Distributed By
®
True Value
Company, Chicago, IL
©2012 True Value Company
Made in China
PRODUCT SPECIFICATIONS
20V Li-ion, 1.3Ah (Maximum charged battery voltage,
measured without load, is 20V with a nominal value of 18V)
1 Hour, Class 2
20V Li-ion #153928
18V Ni-Cd #134458
120V AC, 60 Hz, 60W
18V DC, 2 AMP for Ni-Cd batteries
20V DC, 2 AMP for Li-ion batteries
148197
Owner's Manual
Advertisement
Table of Contents
Summary of Contents for master mechanic 148197
- Page 1 18V NI-CD – 20V LITHIUM ION UPGRADE KIT 148197 Owner’s Manual NOTE: This upgrade kit converts existing 18V Ni-Cad tools with Ni-Cd battery #134458 to 20V Li-ion. PRODUCT SPECIFICATIONS Battery: 20V Li-ion, 1.3Ah (Maximum charged battery voltage, measured without load, is 20V with a nominal value of 18V)
-
Page 2: Battery & Charger Safety
BATTERY & CHARGER SAFETY WARNING: Do not allow the cord to hang over the edge of a Only use the charger table or counter or touch hot surfaces. The supplied with this kit to charge a 20V Li-ion charger should be placed away from sinks and #153928 battery or an 18V Ni-Cd #134458 hot surfaces. - Page 3 SYMBOLS WARNING: Some of the following symbols may appear on the charger. Study these symbols and learn their meaning. Proper interpretation of these symbols will allow for more efficient and safer operation of this tool. Direct current Volts Amperes No load speed Alternating or direct Hertz current...
-
Page 4: Assembly And Operating
ASSEMBLY AND OPERATING ASSEMBLY AND OPERATING CHARGING THE BATTERY PACK Place the battery charger (1) in a dry location near a 110–120V 60 Hz electrical outlet (Fig. 1). NOTE: Square wave output inverters may damage this charger and the battery. Turn the battery (2) upside down and slide it onto the charger. - Page 5 3-Year Limited Warranty: This product is warranted for 3 years against any defects in material and workmanship. If defective the product will be repaired or replaced free of charge. Simply provide proof of purchase and return the tool to your place of purchase.
