999 3740.9
SERVICE MANUAL
CHAIN SAWS
(45826)
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
© 2001 Greenlee Textron
HCS8160CB (45653)
HCS8163CB (45654)
HCS8200CB (49771)
HCS8203CB (49777)
HCS8240CB (49772)
HCS8243CB (49778)
1/01
Advertisement
Table of Contents
Summary of Contents for Fairmont HPS513CB
- Page 1 SERVICE MANUAL CHAIN SAWS with Chain Brake HPS513CB (45826) HCS8160CB (45653) HCS5130CB (49768) HCS8163CB (45654) HCS5133CB (49774) HCS8200CB (49771) HCS5160CB (49769) HCS8203CB (49777) HCS5163CB (49775) HCS8240CB (49772) HCS5200CB (49770) HCS8243CB (49778) HCS5203CB (49776) Read and understand all of the instructions and safety information in this manual before operating or servicing this tool.
-
Page 2: Table Of Contents
Chain Saws with Chain Brake Table of Contents Purpose Safety ................2 This manual is intended to familiarize personnel with the safe service procedures for the following Fairmont tools: Purpose ................2 HPS513CB (45826) Serial Code GDV Other Publications ............2... -
Page 3: Important Safety Information
Chain Saws with Chain Brake IMPORTANT SAFETY INFORMATION SAFETY Skin injection hazard: ALERT Oil under pressure easily punctures SYMBOL skin causing serious injury, gan- grene or death. If you are injured by escaping oil, seek medical attention This symbol is used to call your attention to hazards immediately. -
Page 4: Important Safety Information
Chain Saws with Chain Brake IMPORTANT SAFETY INFORMATION Tool, chain, and other components Do not change accessories, inspect, adjust or may be hot during and after opera- clean tool when it is connected to a power source. tion. Allow to cool before handling, Accidental start-up can result in serious injury. -
Page 5: Disassembly
Complete disassembly of the tool is not recommended. If a complete overhaul is necessary, return the tool to 1. Loosen the lock screw on the Bowden pin (68) to your nearest authorized Fairmont distributor or to ensure the cable (70) can slide easily within the pin. Fairmont. -
Page 6: Inspection
Chain Saws with Chain Brake Disassembly (cont’d) Inspection Oil Metering Screw Clean all parts with an appropriate cleaning solution and dry them thoroughly. Inspect each component as Remove the oil metering screw (30) from the saw head described in this section. Replace any component that (1). -
Page 7: Assembly
Chain Saws with Chain Brake Assembly Metering Screw Refer to the Illustration and Parts List for correct orienta- tion and placement of parts. Install a new O-ring (31) on the metering screw (30). Install the metering screw (30) in the saw head (1). Replace any O-rings and gaskets on parts that have been disassembled. - Page 8 Chain Saws with Chain Brake Assembly (cont’d) Mount Plate, Spike Rack, Standoffs, and Studs 2. Install the Woodruff key (34), drive shaft spacer (44), spline adapter (45), rim sprocket (47), washer 1. If the two standoffs (46) or the two 5/16–18 x 1 (48), and lock nut (49) onto the drive shaft.
-
Page 9: Assembly
Chain Saws with Chain Brake Assembly (cont’d) Front Handle, Lower Handle, and Cover Chain Brake Assembly 1. Prior to installing the button head cap screws, clean 1. Install the spool (77) into the spool bore, ensuring that the holes through the spool align with the fluid the internal and external threads and apply a small passages in the bore. -
Page 10: Adjustments
Chain Saws with Chain Brake Adjustments Checking and Setting the Automatic Chain Oiler Checking Chain Tension The automatic chain oiler provides a constant supply of 1. Stop the hydraulic power source. Disconnect the hoses. Allow the bar and chain to cool. oil to lubricate the bar and chain whenever the saw is operating. -
Page 11: Sharpening The Saw Chain
Chain Saws with Chain Brake Sharpening the Saw Chain The saw chain must be sharpened to the If using a filing guide or hand-held grinder, refer to the manufacturer’s specifications. If the saw chain is not manufacturer’s instructions provided with the unit. properly sharpened, the risk of kickback increases. -
Page 12: Sharpening The Saw Chain
Chain Saws with Chain Brake Sharpening the Saw Chain (cont’d) Filing Depth Gauges 2. File the cutters on one side of the saw chain from the inside out. File on the forward stroke only. 1. If the cutters are sharpened with a file holder, check and lower the depth gauges before sharpening the Filing Cutters cutters. -
Page 13: Illustration And Parts List
Chain Saws with Chain Brake Illustration (without Chain Brake) Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070... - Page 14 Chain Saws with Chain Brake Illustration of Chain Brake Assembly Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070...
-
Page 15: Parts List
Adapter, Sprocket ..............1 55137 905 5137.0 Standoff ..................2 55101 905 5101.0 Rim Sprocket, .325" Pitch (HPS513CB, HCS5XXXCB) ... 1 55103 905 5103.6 Rim Sprocket, 3/8" Pitch (HCS8XXXCB) ........1 43309 F030137 Washer, Flat, .530" x 1.50" x .050" ........... 1... - Page 16 PART 78-3310- DESCRIPTION QTY. 55140 905 5140.0 Bar, Guide, 13" x .058" Ga (HPS513CB and HCS513XCB) ..1 55180 905 5180.0 Bar, Guide, 16" x .058" Ga (HCS516XCB) ....... 1 55141 905 5141.9 Bar, Guide, 16" x .050" Ga (HCS816XCB) ....... 1 55182 905 5182.6...
