Thanks for shopping with Improvements
!
OWNER's INSTRUCTIONS MANUAL
MESA SQUARE PROPANE FIREPIT TABLE
User's Guide and Instruction Manual
ITEM # 532761
If you have questions regarding this product, call
1-800-642-2112 Mon.-Fri. 9:00-5:00 EST (Ohio)
ImprovementsCatalog.com
and ask for our product specialists, or e-mail:
To order, call
productspecialist@improvementscatalog.com
Made in China
1-800-642-2112
See many more products on the Internet!
1116
West Chester, OH 45069
www.ImprovementsCatalog.com
#532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 1 of 24
MESA SQUARE PROPANE FIREPIT TABLE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 532761 and is the answer not in the manual?

Questions and answers

Summary of Contents for Improvements 532761

  • Page 1 To order, call productspecialist@improvementscatalog.com Made in China 1-800-642-2112 See many more products on the Internet! 1116 West Chester, OH 45069 www.ImprovementsCatalog.com #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 1 of 24 MESA SQUARE PROPANE FIREPIT TABLE...

  • Page 2: Limitation Of Warranty And Liability

    This Limitation of Warranty and Liability may not be amended by any oral or written agreement. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 2 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 3 Save this Owner's Manual and these instructions for future use. If you are assembling this unit for someone else, give this Owner's Manual to them to read. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 3 of 24 MESA SQUARE PROPANE FIREPIT TABLE...

  • Page 4: Safety Information

    • Use LP propane tanks with the following dimensions: diameter 12 in, height 18 in - capacity 20lbs. • You must use a Propane Gas Tank that has a collar to protect the Gas Valve. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 4 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 5 • Keep all electrical cords and fuel supply hose away from heated surfaces. • Combustible material should NOT be within 72 inches of the top of the unit, and within 48 inches around the entire unit. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 5 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 6 • The LP Gas tank must have a listed overfilling prevention device and a QCCI or Type I, LP Gas tank connection. • This heating appliance should NOT be used on plastic, artificial wood desks or any desk. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 6 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 7 NOTE: You must follow all steps to properly assemble this Fire Table / Column. Make sure the Gas Valve is turned “OFF” before assembling. DO NOT attempt to assemble without proper tools. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 7 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 8 1) Push and turn the Control Knob clockwise to the ”OFF” position. 2) Turn the gas off at its source (cylinder or quick connect). IGNITER PUSH #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 8 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 9 In some cases, some Customers purchases separate Gas Tank Holder to hold the Gas Tank. In this case, the 5 feet distance between the Fire Table / Column to the Gas Tank applies too. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 9 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 10 If you smell gas or a leak is discovered, IMMEDIATELY turn the gas valve off, disconnect Propane Gas tank. Do not use the appliance until the leak is repaired #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 10 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 11 Qualified Service Technician. This line art below demonstrates the internal components of the Burner. For your conveneince all of the above components are individually desribed herebelow. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 11 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 12 Burner Ring Nozzle Corrugated Pipe Switching Valve Regulator Valve with Gas Hose Control Knob Ignitor Foot CSA Warning Label Wing Screw with Nut Metal Stand #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 12 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 13 1 box Battery(AAA) Panel with door Panel with window PVC Cover Panel F Panel G Metal Stand Hardware Label Picture Description Bolt (M6*10MM) ① Screwdriver ② #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 13 of 24 MESA SQUARE PROPANE FIREPIT TABLE...

  • Page 14: Assembly Instructions

    4. Do not fully tighten Bolts. 3.Turn over , Fixed the bottom part using 4pss of Bolts(01) with Screwdriver(02) Pls do not fully tighten. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 14 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 15 2pcs of Bolts(01) with Screwdriver(02). And tighten the Bolts . 6.Fixed the metal base with top using 4pcs of Bolts(01) with S crewdriver(02). And tighten the Bolts 7.Turn over the Fire Table #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 15 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 16 Make sure the Propane Gas Tank is placed completely into the Metal Stand (18 ). Turn the preassembled Wing Screw (17) in a clockwise direction in to the Nut (17) to secure the Propane Gas Tank tightly. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 16 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 17 (14). Make sure the positive side of the Battery( B ) faces outwards. Screw the Electronic Ignitor Cap (14) over the battery, tightly. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 17 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 18 Note : Do not place more than 3KG of lava rocks above the burner holes. Doing so will suffocate the flame. To ensure proper function, the Guard (01) on the Burner (08) should never have lava rocks (A) covered over it. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 18 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 19 2. ) Flame height burns at 2 - 10 inches high. Wait 10 minutes after extinguishing flame prior to replacing a lid (if applicable) or protective cover onto the Fire Table / Column. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 19 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 20 8. Observe flame height when lit: 8.1. ) Flame color should be yellow / blue. 8.2. ) Flame height burns at 2 - 10 inches high. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 20 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 21 • Visually inspect Burner (08) for obstructions and keep tank enclosure free and clear from debris. • Place Lid (if applicable) and Protective Cover (E) on the Fire Table / Column when not in use. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 21 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
  • Page 22 Store your product indoors during winter months, leave the gas tank outside. Avoiding extreme cold temperatures, as extreme cold temperatures may cause cracking of the tabletop. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 22 of 24 MESA SQUARE PROPANE FIREPIT TABLE...

  • Page 23: Troubleshooting

    Check that the gas tank isn’t empty No gas flow easily Excess flow safety valve has See ‘Sudden drop in gas flow’ above been activated #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 23 of 24 MESA SQUARE PROPANE FIREPIT TABLE...

  • Page 24: Warranty

    • Use any component part / change to parts that are NOT manufactured or approved by manufacturer • Use and installation other than what is listed in this Owner's Manual. #532761 Current instructions at www.improvementscatalog.com 1-800-642-2112 Page 24 of 24 MESA SQUARE PROPANE FIREPIT TABLE...
