Tru-Test JR 3000 Quick Start Manual

JR3000 Features
Installing the
Indicator
The ultimate in weight management
QUICK START GUIDE
!
Messages prompt you through the weighing sequence for each animal.
!
The indicator learns the data entry sequence for fast data entry.
!
The indicator automatically maximises the viewable size of the weight display.
!
The back-lit display with light sensor allows the indicator to be used in low light conditions.
!
An on-screen help system provides on-the-spot assistance when you need it.
!
Printed reports can be created for files, statistics and weighing session data.
!
Up to 10,000 individual animal records can be stored.
!
The indicator stores four digits of data with each weight, together with two IDs.
!
Animals can be drafted/sorted into two ranges.
1. Mount the indicator bracket on a flat surface, such as a timber rail or concrete structure, using
screws or nails. Alternatively, mount the bracket onto horizontal pipework with the U-bolts
supplied.
2 Connect the load sensor cables to the indicator. Connect the dust caps together to keep out
dirt and moisture.
3. Connect the power cable (if using an external 12 V supply).
Communications connectors
for connecting to computer,
printer, EID reader etc.
Power connector for connecting 12 V vehicle battery
(red clip to positive terminal) or Tru-Test power adaptor.
To connect power adaptor, pull battery clips off indicator
lead and plug lead into power adaptor lead (red to red).
Dust caps screw together to keep
out dirt and moisture when cables
are connected to the indicator.
Screw back on indicator/cables
when cables removed.
Loadcell connectors
®
