AVR250

EXPLODED VIEW PARTS LIST

Reference No.
0101 *CE BLACK / UL BLACK
0101 *CE SILVER / UL SILVER
0102 *CE SILVER / UL SILVER
0102 *CE BLACK / UL BLACK
0103
0104
0105 *CE BLACK / CE SILVER / UL BLACK
0105 *UL SILVER
0106
0107
0108
0109
0110 *CE SILVER / UL SILVER
0110 *CE BLACK / UL BLACK
0111 *CE BLACK / UL BLACK
0111 *CE SILVER / UL SILVER
0112
0113
0114
0115
0116
0117
0118
0119
0121
0122
0123
0124
0125
0126
0127
0128
0129
0130
0131
0132 *CE SILVER / UL SILVER
0132 *CE BLACK / UL BLACK
0133, 0134, 0135, 0136, 0137, 0138, 0139, 0142,
0143, 0144, 0159, 0160, 0162, 0163, 0165, 0166,
0167, 0168, 0169, 0177, 0178, 0179, 0180, 0181,
0182
SURROUND SOUND RECEIVER
Part No. Description
1403-6246-0 FRONT PANEL BLACK AVR250
1403-6247-0 FRONT PANEL SILVER
1405-1002-0 TOP COVER SILVER AVR300 0102
1405-1001-0 TOP COVER BLACK AVR300
1403-6261-0 FRONT BRACKET AVR300
1405-1101-0 CHASSIS AVR300
1405-0911-0 REAR PANEL AVR250
1405-0911-0 REAR PANEL AVR250
4135-4101-0 PHONE BRACKET AVR300
4135-4051-0 TRANSFORMER BRACKET
2446-6601-0 BASS AND TREBLE KNOB
4134-2820-0 VOLUME KNOB
4134-2831-0 END CAP (LEFT)
4134-2830-0 FRONT ORNAMENT (LEFT)
4134-2840-0 FRONT ORNAMENT (RIGHT)
4134-2841-0 END CAP (RIGHT)
4135-4071-0 POWER BRACKET AVR300
4152-0451-0 L-BRACKET
4152-4631-0 RUBBER FOOT (522) 14MM
8901-4500-0 POWER LED LENS W/LIGHT
4152-7522-0 LENS AVR300
4152-7531-0 TUNER KNOBS
4152-7560-0 VOLUME KNOB HOLDER
2446-6501-0 FONCTION KNOBS AVR300
4152-4641-1 CUSHION FOOT W/RUBBER WA
4154-1502-0 POWER KNOB
4134-9071-0 BRACKET PCB MOUNTING
4135-4091-0 HEATSINK BRK2 AVR300
3716-9906-0 LED POST AVR300
4135-4081-0 HEATSINK BRK1 AVR300
5400-3852-0 HEATSINK RIGHT AVR300
5400-3851-0 HEATSINK LEFT AVR300
4135-4061-0 LONG BRACKET AVR300
4157-0611-0 TRANSFORMER RUBBER PAD
4135-0942-0 TRANSFORMER STEEL COVER
2900-4006-4200 SCM PAN M4X6 RPZIDRIVE
2900-4006-3200 SCM PAN M4X6 RPZIDRIVE
2954-3008-3000 T3X8MM SELF TAPPING
