NetGuardian 224A
USER MANUAL
D-PK-NG224-12003
Visit our website at www.dpstelecom.com for the latest PDF manual and FAQs.
May 30, 2017
D-UM-NG224

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetGuardian 224A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DPS Telecom NetGuardian 224A

  • Page 1 NetGuardian 224A USER MANUAL D-PK-NG224-12003 Visit our website at www.dpstelecom.com for the latest PDF manual and FAQs. May 30, 2017 D-UM-NG224...
  • Page 2: Revision History

    Notice The material in this manual is for information purposes and is subject to change without notice. DPS Telecom shall not be liable for errors contained herein or consequential damages in connection with the furnishing, performance, or use of this...
  • Page 3: Table Of Contents

    NetGuardian 224A Front Panel NetGuardian 224A Back Panel Amphenol Pinouts Pluggable Connectors 66Block diagrams Quick Start: How to Connect to the NetGuardian 224A ...via Craft Port (using TTY Interface) ...via LAN TTY Interface Configure Serial Port via TTY Quick Turn Up...
  • Page 4 10.10.2 Script Sensors 10.11 Ping Targets 10.12 System Alarms 10.13 Timers 10.14 Date and Time Monitoring via the Web Browser 11.1 Alarms 11.2 Controls 11.3 Sensors 11.4 User Analogs 11.5 Ping Targets 11.6 System Alarms 11.7 Graph Device Access Descriptions Backup Configuration Firmware Upgrade Reference Section...
  • Page 5: Netguardian 224A Overview

    Don’t wait until the day your AC unit fails and your server closet overheats to start protecting your gear. This small, 1RU device alerts you of changing conditions 24 hours a day, 7 days a week, either to your cell or SNMP manager. The NetGuardian 224A is the cost-effective way to stay proactive in your monitoring.
  • Page 6 NetGuardian 224A cannot simultaneously report DCP over LAN and DCP over serial port connection. In addition to its 24 discrete input points, the NetGuardian 224A has 2 control relays, both form C, for user defined NO/NC connections, 2 analogs, and dwire. The control relays allow network administrators to respond remotely to threats to system integrity.
  • Page 7: Specifications

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Secure Web: TLS v1.2 and AES128 with built in self signed certificate by DPS Telecom for 128bit key exchange...
  • Page 8: Shipping List

    Shipping List Please make sure all of the following items are included with your NetGuardian 224A. If parts are missing, or if you ever need to order new parts, please refer to the part numbers listed and call DPS Telecom at 1-800-622-3314.
  • Page 10 3/8" Ear Screws Metric Rack Screws 1-000-60375-05 2-000-80750-03 Two Standard Rack Screws Pads 1-000-12500-06 2-015-00030-00...
  • Page 11: Optional Shipping Items - Available By Request

    Optional Shipping Items - Available by Request Small WAGO connector 2-802-01020-00...
  • Page 12: Installation

    The NetGuardian 224A can be flush or rear-mounted The NetGuardian 224A mounts in a 19" rack or a 23" rack using the provided rack ears for each size. Two rack ear locations are provided. Attach the appropriate rack ears in the flush-mount or rear-mount locations shown in Figure 6.2.1.
  • Page 13: Power Connection

    Power Connection The NetGuardian 224A uses single or dual (Optional) power inputs, powered through two barrier plug power connectors. NetGuardian 224A Power Terminals and Fuses To connect the NetGuardian 224A to a power supply: 1. Locate the metal grounding lug next to the symbol .
  • Page 14: Netguardian 224A Front Panel

    NetGuardian 224A Front Panel NetGuardian 224A Front Panel Status Description Solid Green Power Supply OK Power No Voltage (or) Power Leads Reversed Solid Red Blown Fuse Fuse OK Flashing Green Application Running Status Flashing Red Bootloader Running Flashing Red New Alarm...
  • Page 15: Netguardian 224A Back Panel

    NetGuardian 224A Back Panel Amphenol Pinouts If your unit has only one amphenol connector, your controls are pluggable. See next section for wiring. For alarms 1-24, the inputs are TTL 5V biased. Pluggable Connectors If your controls use a pluggable connector, attach your wires into the included screw-down 6-pin phoenix connector. Refer to the labels on the unit.
  • Page 16: 66Block Diagrams

    66Block diagrams 66 block pinout for Amphenol 1 (TTL Discretes 1-24)
  • Page 17 66 block pinout for Amphenol 2 (Controls 1-2)
  • Page 18: Quick Start: How To Connect To The Netguardian 224A

    Quick Start: How to Connect to the NetGuardian 224A Most NetGuardian 224A users find it easiest to give the unit an IP address, subnet and gateway through the front craft port (TTY interface) to start. Once these settings are saved and you reboot the unit, you can access it over LAN to do the rest of your databasing via the Web Browser interface.
  • Page 19 2. Select "Install from a list or specific location (Advanced)" 3. Click "Next >" 4. Select "Search for the best driver in these locations." 5. Insert NetGuardian 224A Resource Disc (CD) into your PC. 6. Click "Browse"...
  • Page 20 7. Select the "Driver" folder of your NetGuardian 224A Resource Disc Disc (CD) and click "OK" The following message will confirm installation of a new "USB Communications Port" 8. Click "Finish" to close the Wizard. Now that the driver has been installed, a new COM port is being emulated on your PC. Before using hyperterminal, you must confirm the identity of that new COM port (COM1, COM2, COM3...) in the Windows...
  • Page 21 9. Right-click the "My Computer" icon on your desktop, then click "Manage" 10.Click "Device Manager" in the left pane.
  • Page 22 11.Expand the "Ports (COM & LPT)" section in the right pane. Look for "USB Communications Port (COMx)". Note the number of the COM port ("COM3" in the example above). 12.Click on the Start menu > select Programs > Accessories > Communications > HyperTerminal. 13.
  • Page 23 Once connected, you will see a blank, white HyperTerminal screen. Press Enter to activate the configuration menu. 17. The NetGuardian 224A's main menu will appear. 18. ESC to the main menu. When asked if you'd like Type C for C)onfig, then E for E)thernet. Configure the to save your changes, type Y for Y)es.
  • Page 24 Now you're ready to do the rest of your configuration via LAN. Plug your LAN cable into the NetGuardian 224A and see "Logging On to the NetGuardian 224A" to continue databasing using the Web Browser.
  • Page 25: Tty Interface

    TTY Interface The TTY interface is the NetGuardian 224A's built-in interface for basic configuration. From the TTY interface, you can: · Edit the IPA, subnet, and gateway · Set DCP info for T/Mon polling · Configure primary port · Ping other devices on the network ·...
  • Page 26: Configure Serial Port Via Tty

    Configure Serial Port via TTY Serial port configuration 1. To enter configuration setting for the Serial Port, login to the TTY interface and press C)onfig > s(E)rial. 2. Press the hot keys to toggle through the following options. (* Indicates default settings:) NOTE: Default settings may not reflect the primary interface that shipped in the unit.
  • Page 27: How To Send Email Notifications

    How to Send Email Notifications 1. Click on the Notifications button in the Provisioning menu. You can setup as many as 8 different notifications. Begin the setup "wizard" by clicking Edit for a notification number. In this example, we'll setup Notification 1 to send emails.
  • Page 28 4. At the Schedule screen, you'll select the exact days/times you want to receive email notifications. You can set 2 schedules per notification. For example, you may want to receive notifications at certain times during the week, and at different hours on the weekend. Use the check boxes to select the days of the week, and select the time from the drop down menus.
  • Page 29: How To Send Snmp Traps

    How to Send SNMP Traps 1. Click on the SNMP button in the Provisioning menu. Enter the SNMP GET and SNMP SET community strings for your network, then click Save. The typical SNMP SET and GET community strings for network devices is "public".
  • Page 30 4. At the SNMP Notification screen, you'll enter your network's SNMP settings. Enter the IP address of your SNMP Trap Server. Enter the Trap Port Number (usually 162) and the Trap Community password. Click Save and Next. 5. At the Schedule screen, you'll select the exact days/times you want to receive SNMP notifications. You can set 2 schedules per notification.
  • Page 31: Provisioning Menu Field Descriptions

    Provisioning Menu Field Descriptions NetGuardian 224A configuration is performed from the Provisioning menus, the menu options in green on the left- side of the web interface. The following pages provide a brief description of the options available in each menu.
  • Page 32: System

    A name for this NetGuardian 224A unit. (Optional field) Location The location of this NetGuardian 224A unit. (Optional field) Contact telephone number for the person responsible for this NetGuardian 224A unit. Contact (Optional field) DCP Responder Settings (For use with T/Mon)
  • Page 33 Event Log Download a log of all alarm events in either plain text (event.log, open with notepad) or Get Log spreadsheet format (eventlog.csv, open with Excel). Bypass Login File can be downloaded without logging in when checked. Purge Log Erase the log of all alarm events.
  • Page 34: History Log Format And Operation

    10.1.1 History Log Format and Operation GET parameters can be used with the history.csv or the eventlog.csv request to filter the returned data. When no GET parameters are supplied, all data will be returned in CSV format. To add GET parameters: qRight-click the history.csv link on the Provisioning >...
  • Page 35: User Profiles

    User Profiles Clicking User Profiles gives you access to modify the default username and password, and to edit the administrator profile and create up to 9 additional unique user profiles, each with different access rights to the NetGuardian 224A's web interface.
  • Page 36 User Profile factory defaults NetGuardian 224A to factory default settings. All user settings will be lost. Upload new firmware, Allows the user to upload firmware or backed-up configuration files. or config Get audit log Allows the user to access the Audit Log (Get Log command).
  • Page 37: Ethernet

    Unit IP IP address of the NetGuardian 224A. A road sign to the NetGuardian 224A, telling it whether your packets should stay on your Subnet Mask local network or be forwarded somewhere else on a wide-area network. An important parameter if you are connected to a wide-area network. It tells the Gateway NetGuardian 224A which machine is the gateway out of your local network.
  • Page 38: Serial Port

    Serial Port The Provisioning > Serial Port menu allows you to change settings depending on the port type of your NetGuardian 224A. From this menu, you can select a mode of operation and enable reach-through serial port functionality. The Provisioning > Serial Ports menu...
  • Page 39: Snmp

    Community name for SNMP requests. Set Community Community name for SNMP SET requests. This field defines how the NetGuardian 224A unit may be accessed via SNMP. This can be set to the following: Read and Write · Access Disabled- Restricts all access to unit via SNMP Access ·...
  • Page 40: Notifications

    Displays the email address (defined in the Edit menu > System) that the "From" E-mail Address NetGuardian 224A will send emails from. Not editable from this screen. The email address of the person responsible for this NetGuardian 224A, who "To" E-mail Address will receive email alarm notifications.
  • Page 41 SNMP Notification Fields Editing SNMP notification settings SNMP Notification SNMP Trap Server IP The SNMP trap manager's IP address. The SNMP port (UDP port) set by the SNMP trap manager to receive Trap Port No. traps, usually set to 162. Trap Community Community name for SNMP TRAP requests.
  • Page 42: Schedule

    10.6.2 Schedule The notifications scheduling menu is where you will tell the NetGuardian 224A exactly which days and times you want to receive alarm notifications. You set 2 different schedules for each. The Schedule creation screen Notification Scheduling Days of the week From either Schedule 1 or 2, check which days you want to receive notifications.
  • Page 43: Alarms

    10.7 Alarms Discrete alarms are configured from the Provisioning > Alarms menu. Descriptions for the alarm points, polarity (normal or reversed) and notification type(s) are defined from this menu. You also have the option to use Basic or Advanced configuration methods, explained in this section. The Provisioning >...
  • Page 44: Controls

    10.8 Controls The NetGuardian 224A's 2 control relays can be configured in the Provisioning > Controls menu. You can enter your own description for these relays and designate them to a notification device(s). The Provisioning > Controls screen Basic Controls Configuration ID number for the control relay.
  • Page 45: User Analogs

    10.9 User Analogs The NetGuardian 224's two multi-purpose analog inputs measure continuous ranges of voltage or current. Analog alarms are typically used to monitor battery voltage, charging current, temperature, humidity, wind speed, or other continuously changing conditions. To configure a user analog, simply fill in your description, thresholds, and other fields listed in the table below, then click Save.
  • Page 46: Sensors

    The NetGuardian 224A supports up to 32 daisy-chained D-Wire sensors via its D-Wire input. Sensors connected to the NetGuardian 224A will appear on the web interface. The background color of the ROM field informs the user of the sensor's configuration state.
  • Page 47 The unit will refresh the sensor ID on that channel. Description User-definable description for the sensor channel. Parse Checks to see if the Description field contains a valid equation. Check which notification device(s), 1 through 8, you want to send alarm notifications Notification Devices for that alarm point.
  • Page 48: Hvac Monitoring

    10.10.1 HVAC Monitoring Temperature / Air Flow sensors can be used to monitor HVAC health. Enabling HVAC Monitoring on this sensor adds the extra fields below. Sensor with HVAC Monitoring enabled. HVAC Monitor Mode The time the HVAC has between starting and reaching operational Air Flow and Vent HVAC Start Time Temperature Mate...
  • Page 49: Script Sensors

    10.10.2 Script Sensors A Script Sensor can be setup by entering a script type in the sensor ID field. The following types are currently supported: ~count - The equation will be evaluated continuously. If the evaluation changes at any point, the sensor's value increases by an increment of 1.
  • Page 50 How equations are evaluated: Calculations are performed from left-to-right until the end of the equation is reached. As the equation is parsed, each token's value is pushed onto a stack until an operator is found. When an operator is found, the previous 2 values are popped from the stack and are used to perform the operation (the first item popped is the SECOND operand).
  • Page 51: Ping Targets

    10.11 Ping Targets The Provisioning > Ping Targets menu allows you to configure the Description, IP Address, and Notification Devices for each of your ping targets. The Provisioning > Ping Targets menu Provisioning Ping Targets ID number for the ping target. Enab Check this box to enable the ping target.
  • Page 52: System Alarms

    10.12 System Alarms See "Display Mapping" in the Reference Section for a complete description of system alarms. The Provisioning > System Alarms menu Editing System Alarms Pnt (Point) The system alarm point number Description Non-editable description for this System (housekeeping) Alarm. Silence Check this box to choose to silence this alarm.
  • Page 53: Timers

    10.13 Timers Enter the amount of time in seconds (sec) or minutes (m), in each value field and click Save. The Provisioning > Timers menu...
  • Page 54: Date And Time

    Select your time zone from the drop-down menu. Adjust Clock for Daylight Savings Time (DST) Enable DST Check this box to have the NetGuardian 224A observe Daylight Savings. Start Day Select the month, weekday, and time when Daylight Savings will begin.
  • Page 55: Monitoring Via The Web Browser

    Monitoring via the Web Browser 11.1 Alarms This selection provides the status of the base alarms by indicating if an alarm has been triggered. Under the State column, the status will appear in red if an alarm has been activated. The status will be displayed in green when the alarm condition is not present.
  • Page 56: Controls

    3. To issue the control, click on a command (OPR - operate, RLS - release, or MOM - momentary) View and operate control relays from the Monitor > Controls menu Control Relay Operation ID number for the control relay. Description for the NetGuardian 224A's control relay defined in the Provisioning > Description Controls menu. State Status of the control relay.
  • Page 57: Sensors

    11.3 Sensors This selection provides the status of the system's analog channels by indicating if an alarm has been triggered. The Monitor > Sensors screen provides a description of each analog channel, the current reading, the units being read, and alarm conditions (major under, minor under, major over, minor over) according to your temperature settings. If configured under Provisioning >...
  • Page 58: User Analogs

    11.4 User Analogs On the Monitor > User Analogs menu, you can monitor all analog inputs. The most recent measurement will be shown, and any alarm thresholds crossed will be shown in shown in either orange for minor alarms or red for major alarms. Fig.
  • Page 59: Ping Targets

    11.5 Ping Targets Ping Targets can be viewed by going to Monitor > Ping Targets. Here you can view the state (either Clear or Alarm) for each of your configured Ping Targets. View the status of Ping Targets from the Monitor > Ping Targets menu.
  • Page 60: System Alarms

    11.6 System Alarms System alarms are not-editable, housekeeping alarms that are programmed into NetGuardian 224A. The Monitor > System Alarms screen provides the status of the system alarms by indicating if an alarm has been triggered. Under the State column, the status will appear in red if an alarm has been activated. The status will be displayed in green when the alarm condition is not present.
  • Page 61: Graph

    11.7 Graph The Graph section of the monitor menu lets you build a graph of past analog and sensor measurements, which gives you a visual indication of data over time and points out trending values. To create your Graph, specify the Channel (Analogs 1-8 or Sensors 1-32), Group Interval (1-120 minutes, hours, days, or weeks), the Group Function (Average, Min, Max), and Start &...
  • Page 62: Device Access Descriptions

    The Device Access options, listed in pink on the left side of the web interface, provide options for generating reports, updating the NetGuardian 224A's firmware, and rebooting the unit. Click any of the options under Device Access to perform the desired action.
  • Page 63: Backup Configuration

    Backup Configuration With the NetGuardian 224A you can backup your current configuration from the Web Interface. These configuration files can then be uploaded later, or uploaded to other NetGuardian 224A units. The Back up Config tab is located in the Device Access menu shown above.
  • Page 64: Firmware Upgrade

    Firmware Upgrade To access the Firmware Load screen, click on the Provisioning > System menu. At the bottom of this screen, click the Restore Configuration link located in the System Controls section. To upload firmware, click on Upload on the top right corner of the web interface At the Firmware Load screen, simply browse for the firmware update you've downloaded from www.dpstele.com and click Load.
  • Page 65: Reference Section

    Reference Section 15.1 Display Mapping Description Port Address Point Discrete Alarms 1-24 1-24 Undefined 25-32 Default Configuration DIP Switch Config MAC Address Not Set IP Address Not Set LAN Hardware Error SNMP Processing Error SNMP community error Display 1 LAN TX packet drop Notification Failed 1-8 41-48 NTP failed...
  • Page 66 Description Port Address Point Analog 3 Minor Under Analog 3 Minor Over Analog 3 Major Under Analog 3 Major Over Reserved (CTRL) 9-16 Value 17-32 Display 4 Analog 3 Minor Under Analog 3 Minor Over Analog 3 Major Under Analog 3 Major Over Reserved (CTRL) 41-48 Value...
  • Page 67 Description Port Address Point Digital Sensor 5 Minor Under Digital Sensor 5 Minor Over Digital Sensor 5 Major Under Digital Sensor 5 Major Over Digital Sensor 5 Not Detected Digital Sensor 5 HVAC Fail Digital Sensor 5 Air Flow Below Normal Digital Sensor 5 Mate not detected Control 9-16...
  • Page 68 Digital Sensor 10 HVAC Fail Digital Sensor 10 Air Flow Below Normal Digital Sensor 10 Mate not detected Control 41-48 Value 49-64 Display Mapping...
  • Page 69 Description Port Address Point Digital Sensor 11 Minor Under Digital Sensor 11 Minor Over Digital Sensor 11 Major Under Digital Sensor 11 Major Over Digital Sensor 11 Not Detected Digital Sensor 11 HVAC Fail Digital Sensor 11 Air Flow Below Normal Digital Sensor 11 Mate not detected Control 9-16...
  • Page 70: System Alarms

    Digital Sensor 16 HVAC Fail Digital Sensor 16 Air Flow Below Normal Digital Sensor 16 Mate not detected Control 41-48 Value 49-64 Display Mapping 15.2 System Alarms Display Point Description Default Configuration DIP Switch Configuration MAC Address Not Set IP Address Not Set LAN hardware error SNMP Process Error SNMP Community Error...
  • Page 71: Snmp Manager Functions

    15.3 SNMP Manager Functions The SNMP Manager allows the user to view alarm status, set date/time, issue controls, and perform a resync. The display and tables below outline the MIB object identifiers. The table below begins with dpsRTU; however, the MIB object identifier tree has several levels above it.
  • Page 72: Snmp Granular Trap Packets

    224A. SNMP Trap managers can use one of two methods to get alarm information: 1. Granular traps (not necessary to define point descriptions for the NetGuardian 224A) OR 2. The SNMP manager reads the description from the Trap. UDP Header...
  • Page 73: Frequently Asked Questions

    Q. How do I connect my NetGuardian 224A to the LAN? A. To connect your NetGuardian 224A to your LAN, you need to configure the unit IP address, the subnet mask and the default gateway. A sample configuration could look like this: Unit Address: 192.168.1.100...
  • Page 74: Snmp Faqs

    A. SNMP v1, SNMPv2 and SNMPv3. Q. How do I configure the NetGuardian 224A to send traps to an SNMP manager? Is there a separate MIB for the NetGuardian 224A? How many SNMP managers can the agent send traps to? And how do I set the IP address of the SNMP manager and the community string to be used when sending traps? A.
  • Page 75: Technical Support

    3. Have access to troubled equipment. Please be at or near your equipment when you call DPS Telecom Technical Support. This will help us solve your problem more efficiently. 4. Call during Customer Support hours.
  • Page 76: End User License Agreement

    DPS Telecom which arise out of or are related to the non-fulfillment of any covenant or obligation of End User in connection with this Agreement.
  • Page 79 Warranty DPS Telecom warrants, to the original purchaser only, that its products a) substantially conform to DPS' published specifications and b) are substantially free from defects in material and workmanship. This warranty expires two years from the date of product delivery with respect to hardware and ninety days from the date of product delivery with respect to software.
  • Page 80 Free Tech Support is Only a Click Away Need help with your alarm monitoring? DPS Information Services are ready to serve you … in your email or over the Web! www.DpsTelecom.com Free Tech Support in Your Email: The Protocol Alarm Monitoring Ezine The Protocol Alarm Monitoring Ezine is your free email tech support alert, delivered directly to your in-box every two weeks.
