(2006) Sky Microwave Co. Ltd.
All Rights Reserved
T-30 Skype USB Phone Gateway User Manual
1. Skype Driver Installation
Note: Cancel this procedure if you have already installed Skype software
1.1 Install Skype
Put the CD from package into CD-ROM; click the
, install Skype software.
1.2 Sign In Skype
If you are Skype register user, please enter user name and password from sign in page.
If you are not Skype register user, you have to follow by guide.
1.3 Add A Contact
1.3.1 You add Anyone Skype name
Click the 'Add Contact' button, enter Skype name into textbox. Click "Search" button. And
Click "Add Selected Contact" Button.
1.3.2 Anyone add your Skype name
Others can add your Skype name as you accept their request.
For more information, please visit
www.skype.com
1
Advertisement
Summary of Contents for Sky Microwave T-30
- Page 1 (2006) Sky Microwave Co. Ltd. All Rights Reserved T-30 Skype USB Phone Gateway User Manual 1. Skype Driver Installation Note: Cancel this procedure if you have already installed Skype software 1.1 Install Skype Put the CD from package into CD-ROM; click the , install Skype software.
- Page 2 DTMF. It is not pulse. 3.2 Connect T-30 with PC properly via USB cable Note: Some user uses USB Hub to extend the quantity of USB port. If T-30 connects with USB Hub directly, user is recommended using external power supply USB Hub.
- Page 3 4.1 Launch T-30 software: Start -> Program -> USB Phone T-30 Skype software will auto launch at the same time. When you use T-30 software at the first time, the below screen are show up. Please choose first option. 4.2 Audio Device Setting Start ->...
- Page 4 (2006) Sky Microwave Co. Ltd. All Rights Reserved 4.3 Set location usage of T-30 from Select a location Right Click , Choose “Select a location” from list. Set location usage of T-30 from Select a location.
- Page 5 (2006) Sky Microwave Co. Ltd. All Rights Reserved 5. Dial Phone Call Via T- 30 5.1 Dial IP Phone Example: Benjamin Zhao is on the list of your Skype Contact. You want to talk with him via T-30. 5.1.1 Choose “Set Speed-Dial” from list when you right click contact name.
- Page 6 Pick up phone. Press key *. The T-30 will switch from GSM channel to Skype channel. You will listen up a dial tone. Enter 99#, T-30 will start calling Benjamin Zhao. 5.1.2.2 T-30 is not connect with PSTN Pick up phone.
- Page 7 Hang up phone or press hand free again to end call. 7. Forward Skype Call To Fixed Telephone or Mobile Phone Note: Please confirm you are Skype online. The T-30 software is running. The PSTN channel is connected. 7.1 T-30 connect with direct line The direct line means you can call anyone by pick up phone and call him (her) directly.
- Page 8 (2006) Sky Microwave Co. Ltd. All Rights Reserved ④ Right Click again ⑤ Choose “Enable Skype Forwarding to PSTN” from list. Then will display at The “Enable Skype Forwarding To PSTN” will display at “√Enable Skype Forwarding To PSTN”. This is means “Enable Skype Forwarding To PSTN” function is activated. At this time, any Skype incoming call will auto forward to mobile phone 13811111111.
- Page 9 (2006) Sky Microwave Co. Ltd. All Rights Reserved 7.2 T-30 connect with extension line The basic setting is as same as 7.1. Enter extension number first then follow by a capital letter ”P”. After that, enter the mobile phone number.
- Page 10 (2006) Sky Microwave Co. Ltd. All Rights Reserved Note: The below function is only applicant to Windows XP operation system. 8. Dial Skype Via Mobile Phone 3 Steps as follow: ① Right Click ② Choose “Free Call Forwarding – Skype Set” from list.
- Page 11 (2006) Sky Microwave Co. Ltd. All Rights Reserved Example: The T-30 has been installed on your PC of office. Now you want to take out your mobile phone and dial your online Skype contact: Benjamin Zhao. The Speed Dial Number of Benjamin Zhao is 99.
- Page 12 (2006) Sky Microwave Co. Ltd. All Rights Reserved 9. Forward PSTN Call to Skype or SkypeOut 6 Steps as follow: ① Right Click ② Choose “Input Forwarding-Skype Number ” from list. ③ Enter your Skype or SkypeOut number into textbox and save it.
- Page 13 (2006) Sky Microwave Co. Ltd. All Rights Reserved ⑤ Choose “Call Forwarding – Skype By Number Set” ” from list. Then will display at The “Call Forwarding – Skype By Number Set” will display at “√Call Forwarding – Skype By Number Set”. This is means “Call Forwarding – Skype By Number Set””...
- Page 14 (2006) Sky Microwave Co. Ltd. All Rights Reserved ⑥ Note: You need cancel “Call Forwarding – Skype By Number Set” function when you return to PC desk. Choose “√Call Forwarding – Skype By Number Set option from menu list. After that, the “√Call Forwarding – Skype By Number Set” will display at “Call Forwarding –...
