Car Solutions NB2122T2 Product Information

Car dvb-t2 digital tv box dvb-t2
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Car Digital TV Box
(DVB-T2)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NB2122T2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Car Solutions NB2122T2

  • Page 1 Car Digital TV Box (DVB-T2)

  • Page 2: Safety Instruction

    SAFETY INSTRUCTION Please read the following instructions carefully. 1.The power input is DC 12V. 2.Do not expose the receiver to rain,moisture,direct sunlight or do not place it near a heater. 3.Do not use liquid or aerosol cleaners. Use a light damp cloth for cleaning. 4.The hole on the bottom of receiver must be uncovered to allow proper airflow to the unit.
  • Page 3 FRONT AND REAR PANEL PRODUCT AND ACCESSORIES VIDEO HDMI ANT2 ANT1 AV OUT AV IN DC POWER VIDEO...

  • Page 4: Front And Rear Panel

    FRONT AND REAR PANEL FRONT AND REAR PANEL AUDIO-R AUDIO-L VIDEO HDMI ANT2 ANT1 AV OUT ACC(yellow) GND(black) POWER /B+(red) V(yellow) L(white) R(red) × 95(W) × 25(T) mm S I Z E: 160(L)
  • Page 5 ANT INSTALLATION 1.ANT Structure: 2.ANT Installation: (1).Front windshield (sunshine shield film) will cause poor reception as/since it has a metallic coating. Please install the antenna on a clear window position. (2). Shift antenna to check the signal strength, then move it to a best position. (3).The install locations are just for your reference.

  • Page 6: Remote Control Unit (Rcu)

    REMOTE CONTROL UNIT (RCU) -POWER: Power on/off Switch the receiver between stand-by & on mode -TV/RADIO: Select TV and radio mode -SEARCH: Searching all channels quickly -MUTE: Mute the audio output MUTE SEARCH TV/RADIO -Numeric Keys (0~9): For direct entry of channel number or input of alphanumeric characters -RECALL: Go back to the previously viewed...
  • Page 7 Digital tv playback function operation Press on the remote control, or touch MENU it on the screen. enter the main menu. . Search Menu：enter search menu； . Config Menu：enter config menu； . System Menu：enter system menu. Press to choose the option that you want, press to confirm.
  • Page 8 Digital tv playback function operation Select "Manual Search" , Press ENTER the remote control or touch it on the screen to enter the manual search menu. (picture-4) Press ,choose the frequency that VOL+ you want to search. ,confirm and begin to search. Press ENTER ,return to the previous menu.
  • Page 9 Digital tv playback function operation In the "Picture" menu,there are three options: ( 1 )Aspect Ratio ( 2 )Resolution (3)TV Format Press ,choose the option that you want. Press so that change the parameters. VOL+ Aspect ratio contains multiple 16:9 and 4:3 screen ratio.
  • Page 10 Digital tv playback function operation In the play menu,press ,enter the “INFO” I N F O key to show the information of current programs when it is in normal playing state. Press again to show more detail information. (picture-10) In the play menu,press ,enter the EPG menu.
  • Page 11 Digital tv playback function operation Two options in this Menu. Multimedia: contains music, photo, movie, PVR. PVR Configure: config the PVR parameters. (picture-13) In Multimedia menu, four options here Music: play songs. Photo: browse pictures Movie: watch movies PVR : record video In order to achieve these functions, you need to access external USB memory.
  • Page 12 Digital tv playback function operation Select USB Photo option, press “OK” key to confirm . Press “OK” key to enter next directory. Follow the bottom key guide to operation. (picture-16) Select USB Movie option, press “OK”key to confirm . Press “OK” key to enter next directory. Follow the bottom key guide to operation.
  • Page 13 Digital tv playback function operation The information included H/W Version, S/W Version and Model. Press “EXIT ” key to return previous menu. (picture-19) Press “OK” to return original factory default setting. (picture-20)

  • Page 14: Specification

    SPECIFICATION - RF input: 2 SMA-type terminal - Input Impedance@Antenna: 75ohm - Frequency range: 48MHz-866MHz - ANT1 Signal level:-84dBm~0dBm - ANT2 Signal level:-84dBm~0dBm - Bandwidth: 6M/7M/8M - Demodulation: QPSK,16QAM,64QAM, 256QAM - Guard interval: 1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256 - FEC : 1/2, 3/5, 2/3, 3/4, 4/5, 5/6 - Cofdm carrier mode: 1k,2k,4k,8k,16k,32k -Video Decoder:...
