USER MANUAL

Congratulations
Your MU918 Multi-Functional Charger is durable, sleek, and most of all, Handy so you can keep with the
speed of life. We've condensed all of the main features of this stunning 2-way Charger into this user
manual. In a matter of minutes, we'll show you how competent it is and how easy to operate !
Cool Features
•
User Friendly
One-button control, and the Multi-Functional Charger will do the rest to re-charge Li-ion individual
batteries or your USB device & set output between 1.0A & 2.1A.
•
Solar Energy Conversion
Intelligent solar stabilizer circuit enhance your solar panel energy conversion efficiency and ensure
intermittent-free charging even under unstable sunlight.
•
Speedy Li-ion 18650 battery Charger
Recharge 1 or 2 pcs of batteries in 2 hours with LCD display monitoring charging status.
•
Auto OFF
MCU built-in monitors all the way, to ensure safe, efficient and energy-saving during all charging.
•
LCD Fuel Gauging
Patented digital numerical indicator shows :
[1] current drained at USB output ports
[2] remaining power in %
[3] available capacity after pre-charge
[4] UPS mode in connection with solar panel power input
•
2.1A Powerbank
High speed charging to your smart phones, Action Cameras, Tablet / iPad, GPS Navigation
Your Multi-Functional Charger
Start / ON-OFF
Charge Your Individual Batteries
2
Battery Voltage Energy Level
3
4
Capacity Timer / Full
ONE
- CYLINDRICAL LI-ION BATTERY CHARGER FUNCTION
. Insert Li-ion 18650 battery following polarity marking sign engraved
. Charge 1 or 2 pcs Li-ion 18650 cylindrical cells
. Disconnect from power source when charging completed
Charge Your Device
TWO
- POWERBANK FUNCTION
• AUTOMATIC OUTPUT AT 2.1A
. Charge USB devices ON-THE-GO from charged Batteries
. Operate both in case of 1 battery or 2 battery with 30 sec. auto-off intelligence
. Default current is 2.1A in 2-battery operation ; auto-switch to 1.0A output in 1-battery operation
. Just get your device connected by a charging cable and then press the START/ON-OFF button
Output Voltage Energy Level
7
Output Current Timer / Full
5
Output Voltage Energy Level
START / ON-OFF
Timer / Full
Output Current
6
START / ON-OFF
• MANUALLY SELECTED OUTPUT AT 1.0A
. Press START/ON-OFF button until it shows on LCD ; connect to your device and it starts
charging at 1.0A
. It is recommended to do this 1.0A output current switch when charging a MP3/ 4 player , headset, handheld
game console , basic mobile phone & wireless speaker
Output Voltage Energy Level
9
10
Output Current Timer / Full
START / ON-OFF
1
Battery Voltage Energy Level
Capacity Timer / Full
13
THREE
- SOLAR ENERGY STORAGE & UPS FUNCTION
. Connect it with a solar panel as energy conversion stabilizer via the Micro USB port
. Connect your device via the USB-A port and Press the START/ON-OFF button until you see
UPS ICON on LCD
. The UPS function is activated to charge your device and individual batteries simultaneously
. At UPS operation, the output current automatically switches to 1.0A to conserve the energy in the
charged batteries
8
•
How to store charger / individual battery
Store the charger / individual battery in a cool dry place. Avoid storing the individual battery fully
discharged for any longer period of time. Charge the individual battery at least once every 6 months
to prevent excessive self discharge.
•
Battery Life time
The lifetime of the individual battery is limited. The capacity will drop progressively with use and age of cell.
The battery lifetime can vary substantially depending on storage,operation condition and exposure to
unsuitable environmental conditions.
•
Caution
Only use the charger to charge Li-ion rechargeable batteries
Do not allow charger to get wet or get exposed to moisture
Keep charger out of reach of children
Once charge is completed, unplug the charger from power source
Never use excessive force when connecting or disconnecting battery to contacts
Keep all contacts clean
Do not short circuit contacts
Never store batteries connected to the charger for an extensive period of time
Do not expose to excessive heat or naked flame
Do not leave the charger / individual battery in the trunk or dashboard of a vehicle.
Over-heating can result in leaking, fire or explosion
The charger / individual battery while on charge or in use should never increase above 60°C/140°F. If high
temperature occurs, discontinue using and stop charging immediately
Do not expose the charger / individual battery to extreme temperature (below 0°C or above 4°F) or strong
direct sunlight
Do not throw charger / individual battery in fire
11
Do not place charger / individual battery in microwave, cooker or high pressure container
Do not dismantle or carry out any alterations to the product
Dispose of charger / individual battery in accordance with appropriate regulations
Solar UPS Function
Energy Level
Output Voltage
UPS
Output Current Timer / Full
12
14
START / ON-OFF
Safety & General information
UPS
Indication
