MONSTER VISION CAMVI-0360-A Quick Start Manual

360 camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Start Guide
V2.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAMVI-0360-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MONSTER VISION CAMVI-0360-A

Summary of Contents for MONSTER VISION CAMVI-0360-A

  • Page 1 Quick Start Guide V2.0...
  • Page 2 THANK YOU Thank you for purchasing the Monster V ision® 360 camera. This quick start guide will get you using your new camera in no time. You will be able to take awesome videos and amazing photos to share with your friends and family . Feel free to share them with us and we might post them on our website, YouTube™...

  • Page 3: Features And Buttons

    FEATURES AND BUTTONS Status Screen Shutter Button Power Button WiFi Button Charging Indicator (blue) Activity Indicator (red) WiFi Indicator (red) 220° Lens Tripod mount (¼-20) USB/HDMI/Memory access Speaker...

  • Page 4: Get Started

    GET STARTED 1. MEMORY INSTALLATION – CONTACTS FACING UP! Install the microSD memory card as shown. Do not exceed 32GB card capacity. The camera’s WiFi will not work unless a memory card is installed. Note the HDMI and USB connectors are in the same location. Be sure the camera is off before a memory card is installed or removed.

  • Page 5: Battery Installation

    2. BATTERY INSTALLATION Open the cover by pushing down on the arrow and sliding in the direction of the arrow. (The camera’s serial number is located in this compartment.) Make sure the battery contacts are aligned properly, and then put the cover back on.

  • Page 6: Power On/Off

    3. CHARGING With the power turned off connect the camera with the included cable to a USB power source. We recommend 1 amp (1A) or higher. The charging indicator will be in blue when charging and will turn off when charging is complete. It can take up to 4 hours to fully charge. 4.

  • Page 7: Mode Selection

    6. MODE SELECTION Monster V ision 360 has three modes, V ideo, Dash-Cam and Photo. Modes are switched by pressing Power/Mode button or via app. VIDEO MODE The movie camera icon in the display’s upper left corner indicates status. Press the Shutter button to start and stop recording. When a recording is in progress the activity indicator will flash and the counter will advance.
  • Page 8 DASH-CAM MODE The car icon in the display’s upper left corner indicates status. When powered on, press the power/mode button to select dash-cam mode. In dash-cam mode the camera continuously creates files three minutes long. When the memory card is full, the oldest file will be overwritten, then the next etc. in a continuous loop. DASH-CAM AUTO ON After choosing dash-cam mode, turn the camera off.

  • Page 9: Photo Mode

    PHOTO MODE After switching to Photo mode, press the Shutter button to take a picture. The number of available photos will decrease by one after each photo is taken. Status Screen in Photo Mode...
  • Page 10 7. SETTINGS When the power is on, hold the WIFI button for 2 seconds to enter the settings menu. Video Menu Settings Menu Press Power button to switch between menus. Press WIFI button to move the cursor down. Press Shutter to select. Hold WIFI to cancel or exit.
  • Page 11 8. THE APP DOWNLOAD AND INSTALL THE APP “Monster Vision 360” Search for in Google Play™ or the App Store Or Scan the QR code below.
  • Page 12 2. TURN ON WiFi Turn on the camera and press the Wi-Fi button. MAKE SURE AN SD CARD IS IN THE CAMERA OR THE WIFI WILL NOT WORK! 3. CONNECT THE PHONE OR TABLET TO THE CAMERA In the device settings turn on the WiFi, select the MV360 signal. MV360 WiFi: monsterdigital...

  • Page 13: Computer Playback

    9. COMPUTER PLAYBACK First - Download and install the “Monster Vision VR Viewer”. https://monsterdigital.com/pages/applications Note: If you are on a Mac you may need to enter SYSTEM PREFERENCES, SECURITY & PRIVACY to allow the app to open. Next – Access photos and videos The memory card can be connected to the computer several different ways.
  • Page 14 Next – Open the viewer, then load a video or photo. Click the icon in the lower right corner to choose a file.
  • Page 15 Playback will start in the spherical view setting. Left click on the image and move the cursor to look around. The blue globe highlighted in the upper right of the screen indicates the playback setting.
  • Page 16 Click the icon to its LEFT (a dome with a double arrow) to flatten out the image as shown.
  • Page 17 10. TRIMMING, CONVERTING and UPLOADING Clipping points can be selected at either the front or back of the video, or both. Slide the white dot up and down the video timeline to select the trim point. You can preview the clip by clicking on the “preview” button to the right.
  • Page 18 11. CONVERTING Press the CONFIRM button in the bottom right corner. A window will open with several options to choose from. Be sure to select “HIGH” under Video Quality. Confirm or change the Output Path. Note: the “Output” or file name will be automatically generated, but like any other file, you can rename it after the file is created.
  • Page 19 12. UPLOADING Click the share button in the bottom left corner of the window.
  • Page 20 Facebook Click the Facebook icon and Facebook will open in your browser. Click “Photo/Video” and select the file you just created. Select the appropriate share setting Say something about the video if you like Finally click POST. Facebook will notify you when the post is available. It will take a few minutes for Facebook to process the VR video.
  • Page 21 YouTube Click the YouTube icon and the YouTube upload page will open. Click on the white arrow in the center of the window. Select the file you just created. Like any other upload, add tags, a description and determine the sharing criteria then click “publish”.
  • Page 22 NOTE: It may take 10-15 minutes for YouTube to process the video after it has been published. This is not a visible process like the uploading procedure. Just wait a few minutes, refresh the page and be patient. The final 360 video will have a directional button in the upper left corner as shown below.
  • Page 23 13. ALTERNATE METHODS OF UPLOADING You can also go to Facebook or YouTube and upload the file like any other video. We found video websites compress files differently so playback quality varies. Be sure to set YouTube playback setting to “Auto1080”. Click on the gear icon with red HD in the lower right corner of the YouTube window to adjust this setting.
  • Page 24 14. Accessories 1. Silicon Suction Cup Mount 2. Open Frame 3. Waterproof Case (sold separately)
  • Page 25 4. Adhesive Mounts 5. Selfie Stick (sold separately)
  • Page 26 6. Wrist Remote (sold separately) 1. Power button 2. Record button 3. Photo button 4. Button indicator (red) 5. Band 6. Buckle The remote can be used to power on/off, record videos and take pictures. Its range is about 30m or 100 feet. The two red indicators illuminate when a button is pressed.

  • Page 27: Specifications

    15. Specifications (subject to change without notice) Image sensor 8.0 million pixels (CMOS) Modes Video recording and photography Lens NEW 220-degree wide-angle lens, F2.0 f=1.1mm NEW 1440x1080/60FPS Video resolution 1920x1440P (30FPS), 1440x1080P (30FPS） Photo resolution 8MP, 5MP, 3MP (3840x2160, 3072x1728, 2560x1440) Video H.264（MOV）...
  • Page 28 FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 29 Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of the FCC rules. Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you could be required to stop operation of the equipment.
  • Page 30 REGULATORY INFORMATION To see the complete list of country certifications, visit www.monsterdigital.com Monster, the MC logo, the Monster logo, and Monster Digital, are trademarks or registered trademarks of Monster Products, Inc., or its subsidiaries in the U.S. and other countries. V illain is a trademark of Monster Digital.
