Beacon BSCTAB-750D Owner's Manual

Beacon Industries, Inc.
12300 Old Tesson Rd. • St. Louis, MO 63128-2247 USA
Phone: (314) 487-7600 Fax: (314) 487-0100
www.beacontechnology.com
E-Mail: sales@beacontechnology.com
Ergonomic Solutions
Contents
Warnings and Safety Instructions ...................... 1
Receiving Instructions .......................................... 1
Loading Instructions ............................................. 2
Installation Instructions ........................................ 2
Periodic Maintenance Instructions ..................... 2
Parts Diagram For Foot Pump ............................ 3
Operating Instructions .......................................... 3
Parts Identification For Foot Pump .................... 4
Air Bleed Procedure ............................................. 4
WARNINGS & SAFETY INSTRUCTIONS
Read owner's manual completely before operating
unit!
• Not a personnel lift. Keep clear when operating.
• Never operate lift unless you are watching it.
• Never exceed the maximum loading capacity of 750 lbs.
• Always operate unit on a level surface to insure stability.
• Load lift as uniformly as possible.
• Consult factory for uneven loading.
• Do not continue to step on the foot pump if deck is not
raising.
• Do not change pressure relief valve setting.
• Relieve system pressure by depressing foot lever after
unit has come to rest.
• Do not clamp cylinder in a vise as you may distort barrel.
• Never go under deck if there is weight on unit.
• Remove weight before working on unit.
• Use only maintenance parts supplied or approved by the
manufacturer.
• Consult factory if adding or performing any modification
to the original equipment.
• Do not use brake fluids or jack oils.
Use AW-32 Hydraulic oil or equal.
• Make sure all operator safety labels are in place (p.8).

RECEIVING INSTRUCTIONS

Every unit is thoroughly tested and inspected prior
to shipment. However, it is possible that the unit may incur
damage during transit. If you see damage when unloading
make a note of it on the SHIPPER RECEIVER.
Revised 02-00
OWNER'S
MANUAL
MOBILE ELEVATING TABLE
MODEL BSCTAB-750D
Trouble Shooting Guide ................................. 5
Hydraulic Schematic ....................................... 5
Speed Selection For Foot Pump .................. 5
Scissor Table Exploded Parts Drawing ....... 6
Parts List .......................................................... 7
Warning Label Identification .......................... 8
Material Safety Data Sheet ..................... 9-10
Limited Warranty/Service Record ..............11
Material Handling Problem Solvers ...........34
Remove all packing and strapping material,
inspect for damage. IF DAMAGE IS EVIDENT, FILE A
CLAIM WITH THE CARRIER IMMEDIATLY! Also,
check the platform size, type of power unit, etc., to
ensure that the unit is correct for the intended applica-
tion.
MODEL NUMBER AND CAPACITY
The model number, serial number and capacity are
inscribed on the nameplate. Please remember to
include these numbers in any correspondence with
your dealer or the factory.
FOOT PUMP SCISSOR TABLE
MODEL BSCTAB-750D
01-126-101
1
