Introduction
Use this document for quick installation and setup.
If you experience problems or need more information, see
the Summit Z3-16 User Manual on the Installation DVD or
at the Teledyne LeCroy web site.
2
Components
2
The package includes the following components:
•
Summit Z3-16™ exerciser card
•
Power Adapter
•
x16 to x1 Edge Adapter
•
x16 to x4 Edge Adapter
•
x16 to x8 Edge Adapter
•
USB and Ethernet cables
•
PCIe Protocol Suite Software program DVD-ROM
•
Quick Start Guide (this document)
Depending on configuration, the package may also include:
•
Pcie Gen1/2/3 Test Platform for Host Emulation
Please see the Summit Z3-16 User Manual on the
installation DVD for component specifications and further
details.
3
Unpacking the Exerciser
Unpacking the Exerciser
Inspect the received shipping container for any damage. Unpack the container and account for each of the system
Inspect the received shipping container for any damage. Unpack the container and account for each of the system
components listed on the accompanying packing list. Visually inspect each component for absence of damage.
components listed on the accompanying packing list. Visually inspect each component for absence of damage.
In the event of damage, notify the shipper and Teledyne LeCroy. Retain all shipping materials for shipper's inspection.
In the event of damage, notify the shipper and Teledyne LeCroy. Retain all shipping materials for shipper's inspection.
Summit Z3-16
PCI Express Exerciser
Quick Start
Please see the Readme file on the installation DVD for the
latest software version and for host machine requirements.
Summit Z3-16 Exerciser Card
