Summary of Contents for GoMax Electronics S-PG-303M
- Page 1 S-PG-303M Mini SD/HD/3G Pattern Generator with Serial Control User Manual Made in Taiwan...
-
Page 2: Safety And Notice
However, like all electronic equipments, the S-PG-303M should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 (SMPTE-291M) are also provided. S-PG-303M can support up to 8 channel AES compliant audio with 48KHz sample rate. With portable size, S-PG-303M is equipped three buttons and LED indications to ease the control. This device provides a cost effective way to calibrate and test SDI enable video devices and displays.
- Page 4 Specifications & Package Contents Model Name S-PG-303M Technical Role of usage Pattern generator SDI standards 3G/HD/SD-SDI Auto SDI rate detection SMPTE 259M (270Mbps / 360Mpbs) Supported protocols SMPTE 292M / HDTV (1.485 & 1.485/1.001Gbps) SMPTE 424/425M (2.97 & 2.97/1.001Gbps) Video bandwidth 2.97Gpbs...
- Page 5 Front Panel Operation Button Resolution Normally, Button Resolution is used to select different resolution for SDI outputs, and the LEDs from PAL to 1080p will indicate the selected video resolution. When all 4 lights out, the output resolution is NTSC When pushing Button Resolution and holding for 2 seconds, LED 3+4 will blink once to indicate the current resolution is saved into the embedded flash! Button Video Frame...
- Page 6 Field pattern is chosen and saved into the embedded flash! Notice that, S-PG-303M actually can support tens of video pattern and other features such as moving picture or audio level control etc! Users must be able to access those plus functions by RS-232 serial connection.
- Page 7 Software Menu Operation Menu Items 01 Format Resolution NTSC 720p 1080p 1080i Frequency 59.94 29.97 23.98 Output YCbCr 422...
- Page 8 Menu Items 02 Video Patterns SMPTE Bar 100% Bar Check Field 1 Check Field 2 Check Field 3 Gradient R1 Gradient G1 Gradient B1 Gradient R2 Gradient G2 Gradient B2 Gradient R3 Gradient G3 Gradient B3 Gradient R4 Gradient G4 Gradient B4 Red Level 1 Red Level 2...
- Page 9 Menu Items 03 Audio Mode Group Level -6dB -12dB -18dB -24dB -30dB -36dB -42dB Silence Random Mask CH 1234 CH 1 CH 2 CH 3 CH 4 CH 1+2 CH 3+4 04 Motion Motion No Motion Square 1 Square 2 2 Squares Square Inv Data Speed...
-
Page 10: Panel Descriptions
Panel Descriptions Top View Side View 1. SDI OUTPUT A: Connect to a SDI device for SDI, HD-SDI, or 3G-SDI signal output either from the chosen pattern or the converted HDMI source signal. 2. SDI OUTPUT B: Connect to a SDI device for SDI, HD-SDI, or 3G-SDI signal output either from the chosen pattern or the converted HDMI source signal. - Page 11 Notice 4. +5V DC: Connect to a 5V DC power supply unit 5. RS-232: RS-232 port for control via PC software Notice 1. Due to the high frequency bandwidth and low jitter requirement of 3G-SDI signals, it is strongly recommended to use just one SDI OUTPUT with one 75 ohm. 2.
- Page 12 Appendix Data Identification Word of Ancillary Data Packet ANC Data SDID/DBN 352M 0x41 0x01 RP-165-EDH* 0xF4 0x00 * Data Type 1(SMPTE-291M) Built-in Video Patterns...
-
Page 14: Limited Warranty
Limited Warranty The SELLER warrants the S-PG-303M Mini 3G/HD/SD-SDI Pattern Generator with Serial Control to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.
