"Docking station", converts ME 3 U CompactPCI to USB 2.0
Model overview and scope of delivery (base model)
Model overview:
• ME-Synapse-USB (ME-1-USB)
By default, the ME-Synapse-USB is sold in combination with ME DAQ and control boards. If you want to use the
ME-Synapse USB together with an ME board you already own, please contact our technical sales teams.
Scope of delivery:
ME-Synapse-USB metal housing with USB port, 1 active and 1 passive slot. This installation instruction on CD.
1 m USB cable. Power supply.
The driver software required for programming the boards is included in the delivery scope of the ME board(s).
Optional accessories:
• ME-Synapse-USB-RM-Kit
Use to mount the ME-Synapse-USB in 19" systems. Includes 2 angular guidance plates and a front panel
• UTA-130
Universal DIN rail adaptor, use to mount ME-Synapse-USB on standard DIN-rails. 2x required!
Short description
The concept: Use ME series DAQ and control boards "remotely" on the USB!
• "Docking station"/converter from 3 U CompactPCI to USB 2.0 full-speed.
• Remote and decentral: Control all supported ME series boards (3 U CompactPCI, models supported by soft-
ware driver system ME-iDS) via USB.
• Rugged industrial housing. Can be mounted in 19" racks or on DIn-rails with optional accessory.
• 1 active and 1 passive slot for ME boards.
• Uses robust, standardized CompactPCI based technology.
• ME DAQ hardware programmed via intelligent software driver system ME-iDS.
• Ideal solution also for "cross-platform" projects USB - ethernet/LAN - PCI - CompactPCI and Windows - Linux.
Meilhaus Electronic GmbH
Fischerstrasse 2
82178 Puchheim/Germany
☎
++49 - 89 - 89 01 66-0
FAX
++49 - 89 - 89 01 66-77
E-Mail support@meilhaus.com
ME-Synapse-USB (ME-1-USB)
- Rev. 2.0E
All information is subject to change
without notice.
www.meilhaus.com
© Copyright 2010 Meilhaus Electronic GmbH.
All rights reserved. Meilhaus Electronic
assumes no responsibility for any problems
or damage which may result from errors or
omissions.
Advertisement
Table of Contents
Related Manuals for Meilhaus Electronic ME-1-USB
Summary of Contents for Meilhaus Electronic ME-1-USB
- Page 1 • Ideal solution also for “cross-platform” projects USB - ethernet/LAN - PCI - CompactPCI and Windows - Linux. All information is subject to change without notice. Meilhaus Electronic GmbH www.meilhaus.com © Copyright 2010 Meilhaus Electronic GmbH. Fischerstrasse 2 All rights reserved. Meilhaus Electronic 82178 Puchheim/Germany assumes no responsibility for any problems ☎...
- Page 2 Connectors and LEDs of the ME-Synapse-USB Front side: ➂ 2x slots (1x active, 1x passive) for the supported ME series 3 U Robust metal CompactPCI baords housing Back side: Operation fl at on the side (also when stacked with other modules) or in upright position Anti-slip-pits for (also 19“...
- Page 3 How to mount the DAQ board In most cases the DAQ board is already installed in the ME-Synapse (when bought as a package). If you want to mount an existing, supported ME CompactPCI board into the ME-Synapse, please note the following: Insert the board so it can easily slide in the two rails and is held securely.
- Page 4 Specifi cations Docking station Function “Docking station”/bridge/converter for ME CompactPCI boards to USB 2.0 full speed Number of slots 1 active peripheral bus slots for 1 3 U CompactPCI board and 1 passive slot for 1 extender board, like for example ME-1000/64 with ME-1001 (= ME-1000/128) or ME-FoXX digital channels + 1 system slot for the ethernet module Supported boards...
- Page 5 Mounting the ME-Synapse into 19“ racks To mount the ME-Synapse into a 19“ systeme a mounting kit (available as optional accessory) is required. The kit includes 2 angular guidance plates and a front panel. To mount the guidance plates, screw out the 4 screws on the ME-Synapse top side.
- Page 6 Mounting the ME-Synapse-USB on DIN-rail 2 universal DIN-rail adaptors UTA-130 are required to mount the ME-Synapse-USB on standard DIN-rails. UTA- 130 adaptors are available as an option. Screw both adaptors to the bottom of the ME-Synapse-USB (use the provided holes). With the adaptors attached, the ME-Synapse-USB can now be mounted to and from DIN-rails easily.
