- Page 1 Power Supply Instruction Manual Applicable Models: APS-301A, APS-351B, APM-301A, APM-301C Thank you ■ for purchasing the CHP Assembly Tool. In order to ensure maximum performance and product life, please read this manual before operating your power supply.
- Page 2 -Table of Contents- General Safety Warnings ........................ Care/Maintenance ..........................Read Before Use ........................... Declaration of Conformity (CE) ..................………. Product Information ..........................Operation ………………..………………………………………………………………......Troubleshooting ……………..…………………………………………………...………………………...
- Page 3 1. General Safety Warnings WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Keep this manual readily accessible for reference. ■Working area safety - Keep working area clean and well lit. - Do not operate power tools in the presence of flammable liquids, gases or dust.
-
Page 4: Product Information
- Turn off the controller when not in use. Remove the power cords from the controller for long period storage. - The controller is for CHP electric screwdriver use ONLY. Do not use with any other tools. 4. Declaration of Conformity (CE) We, American Hakko Products, Inc., hereby declare that the products described in this manual are in conformity... - Page 5 AT-2000B AT-2000 AT-6800B AT-6000 AT-3000B AT-3000 AT-6500 AT-4000B AT-4000 AT-6800 AT-4000FB AT-4500 Applicable Electric Screwdriver models AT-6000B AT-6500B AT-200B AT-250B Dimension (mm) 164X64X42 mm 172X84X46 mm Weight (g) 300 g 380 g AC cable length (m) 1.8 m Safety Standards CB,CE,UL(CUL),ROHS,REACH Accessories Adjustment tool, 2P/4P socket terminal 1 pieces, and AC cable...
- Page 6 - The input voltage of the power supply is ranged between 100-240VAC, 50/60 Hz. Please make sure to use the correct voltage in order to avoid damage to the power supply. Two-stage Switch Top of the Power Supply AC input socket (C13 specification) Indicator Light Model APS-301A APS-351B APM-301A APM-301C Item ◎ ◎...
- Page 7 Picture 1 Picture2 Dry contact signal Voltage specification: DC24V/400mA MAX Brake JP-A: External controller use terminal (APS-301A & APM-301A ONLY) The power supply supports external controller to control screwdriver operation. Connect ON/OFF switch to JP-A terminal for external control (Forward only).
-
Page 8: Troubleshooting
Screw hole for the assembly of the power supply and the balancer - There are screw holes at the bottom of the power supply that allow the unit to be mounted on CHP spring balancer (optional accessory) and the fixed board. Please follow the instruction below:...
