texet PB5600 Instruction Manual

Thank you for purchasing this TEXET Power Bank, PB5600, before operating the Power Bank please read this
Instruction Manual carefully and keep for future reference.

How to charge the Power Bank

Using the USB Cable supplied, plug the USB end of the cable into the power source being used, i.e computer/Laptop,
USB Mains Charger. Plug the other end of the cable into the Micro USB port of the Power Bank, this is located at the
top of the Power Bank, the LED Light will flash Red whilst it is being charged. The flashing Red light will change to
Green once the Power Bank is approx. 33% charged and Blue once 67% charged. When fully charged the Blue LED
light will stop flashing and stay on indicating that it is fully charged. To switch off press the ON/OFF button and hold
for 2-3 sec, it will switch off after approx. 10secs.
The Power Bank has a light which can be used as a small torch, to switch on press the ON/OFF button
twice in quick succession, to switch off do the same again.
If the Power Bank is switched on but is not being used it will automatically switch off after approx. 12-15sec.
The Power Bank will take approx. 6-8 hours to fully charge depending on the power source you are using to
charge the Power Bank. If you are using a computer/laptop it will take longer as the maximum output load from
the USB 2.0 ports is 500ma.
The Power Bank can be charged directly through the mains socket outlet using a TEXET USB Mains Charger, (not
supplied).

How to charge your device.

Plug the USB end of the Cable supplied into the USB out port, located at the top of the Power Bank
USB
end of the cable into the Micro USB port of your device, a Blue LED light will come on and your device will
automatically start being charged.
When there is less than 67% charge left in the Power Bank the LED light will change to Green, when there is less
than 33% charge it will change to Red. The Power Bank will need re-charging once the Red LED light starts flashing.
The Power Bank is fitted with overload, discharge and short circuit protection. When removing the cable from either
the Power Bank or your device, always grip the connector, never pull the wire as it may damage the Cable or the
connector.

Accessories supplied.

1 x USB to Micro USB Cable.

Specification.

Battery Capacity: 5600mah
Micro USB Input: 5V 1000ma
USB Output: 5V 1000ma
Dimensions : 101 x 45 x 24mm
Weight: 120gms
Waste Electrical products/batteries should not be disposed of with normal Household waste.
Facilities exist, for your nearest facilities, see
Made in China.
PB5600 Power Bank Instruction Manual
.
TEXET is a registered Trademark of The Hira Company
Mobile Phone Battery Capacity:
iPhone6 – 1810mah iPhone 6plus – 2915mah
iPhone 5/5s – 1440-1560mah Nexus 5 – 2300mah
Galaxy 5S – 2800mah Sony Z3 Xperia - 2300mah
HTC One M8 – 2600mah One plus One - 2800mah
www.recycle-more.co.uk or in-store for details.
www.texet.com
