Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Specifications
Weight Capacity
Height Range
Max. Air Pressure 120 PSI
Air Inlet
Meets 2009 ANSI/ASME PALD standards.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2016 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
22 Ton (44,000 lb.)
8-15/16" – 1 7-3/4"
(without saddle adapter)
1/4"–18 NPT
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
REV 16f
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pittsburgh 63273
Summary of Contents for Pittsburgh 63273
- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
-
Page 2: Important Safety Information
13. Lower load slowly. If it does not work properly, bleed air from its hydraulic system as stated on page 5. 14. Apply parking brake and chock tires before lifting vehicle. Page 2 For technical questions, please call 1-888-866-5797. Item 63273... -
Page 3: Air Source
WARNING marking concerning National pipe thread, tapered Risk of Respiratory Injury. Wear NIOSH-approved dust mask/respirator. Chart continued in next column. WARNING marking concerning Risk of Explosion. SAVE THESE INSTRUCTIONS. Item 63273 For technical questions, please call 1-888-866-5797. Page 3... - Page 4 (41– 4 3) U-Bolts (39) Bolt (6) Nuts (23) Lower Adapter Handle Holder (18) (40) R-Pin (44) Figure A Figure B 2. Tighten Nuts to secure Adapter Holder to Handle. Page 4 For technical questions, please call 1-888-866-5797. Item 63273...
-
Page 5: Air Supply
Note: To prevent damage to the Bottle Jack, check 4. Depress the Air Lever completely for for excessive air and/or low hydraulic oil regularly. a few seconds to purge air. Item 63273 For technical questions, please call 1-888-866-5797. Page 5... - Page 6 Page 6 For technical questions, please call 1-888-866-5797. Item 63273...
- Page 7 Item 63273 For technical questions, please call 1-888-866-5797. Page 7...
-
Page 8: Raising A Vehicle
(not more than one full turn) to lower the vehicle. 5. To prevent accidents, lower the Jack completely and disconnect its air supply after use. Clean, then store the Jack indoors out of children’s reach. Page 8 For technical questions, please call 1-888-866-5797. Item 63273... -
Page 9: Troubleshooting
Check the oil level and refill if needed. Jack may require bleeding - see instructions. Unit may have too much hydraulic oil inside, check fluid level and adjust if needed. Item 63273 For technical questions, please call 1-888-866-5797. Page 9... - Page 10 U-Bolt Handle Socket Tie Rod-3 Adapter Holder Washer Screw Saddle Adapter A Screw Saddle Adapter B Handle Lever Saddle Adapter C Connector Handle Sleeve R-Pin Tie Rod-1 Saddle Adapter D Page 10 For technical questions, please call 1-888-866-5797. Item 63273...
-
Page 11: Please Read The Following Carefully
Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Item 63273 For technical questions, please call 1-888-866-5797. Page 11... - Page 12 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
