Summary of Contents for Intuicom RTK Bridge-M
- Page 1 Intuicom ® RTK Bridge M Installation Guide ™- ® ® Trimble EZ Guide 500 Intuicom, Inc. 4900 Nautilus Ct. Ste. 100 Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
- Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.
-
Page 3: Requirements For Installation
In order to operate an Intuicom RTK Bridge-M, you are required to have the necessary information to access and log in to the Real-Time Network. This information is entered into the RTK Bridge-M and stored in a profile. More details on setting up an RTK Bridge-M are available in the RTK Bridge-M manual. -
Page 4: Installation Instructions
Programming Cable. Details can be found in the Intuicom RTK Bridge-M User Guide. Using the Intuicom RTK Bridge-M to EZ Guide 500 data/power cable, connect the RTK Bridge-M to the COM Port on the EZ Guide 500. Version 1.3... - Page 5 Section 2: Installation Instructions Select the Tools window Go to GPS Setup Version 1.3 Intuicom, Inc.
- Page 6 Section 2: Installation Instructions Select Correction Source: RTK Select Correction Delivery: Generic CMR Radio Version 1.3 Intuicom, Inc.
- Page 7 Data Parity None o Stop Bits 1 Confirm operation – Confirm the Intuicom RTK Bridge-M is correctly configured and its antennas are connected and within cellular coverage. The main status view on the EZ Guide 500 should report that it is receiving RTK corrections.
- Page 8 EZ Guide 500. RTK Bridge-M setup The RTK Bridge-M must be configured to receive the GPS position from the data port. In the Profile Configuration menu, select ‘Positioning,’ the RTK Bridge-M will display the Positioning Sub-Menu. Press ‘1’ until positioning type is ‘DATA PORT.’ The RTK Bridge- M is now ready to receive the GPS position from the EZ Guide 500.
- Page 9 Section 3: Operation From the main screen, go to the Tools menu Select User Mode Advanced Version 1.3 Intuicom, Inc.
- Page 10 Section 3: Operation Select System, then GPS Select NMEA Output Version 1.3 Intuicom, Inc.
- Page 11 Configure Port settings o NMEA Output port COM o Baud Rate 38400bps (this must be the same as the Data Port Baud Rate on the RTK Bridge-M) o Data Parity None Message Selection o GGA must be set to 1Hz o Everything else can be set to Off Version 1.3...
- Page 12 The EZ Guide 500 should now be configured to send the GGA string to the RTK Bridge–M. Return to the Main screen to verify RTK Fix. Please contact Intuicom Technical Support at 303-449-4330 if you have any questions or need any assistance.
