Summary of Contents for Signi Fires BF023
- Page 1 Slimline Burner Manual...
-
Page 2: Important Safeguards
Operating Manual Thank you for purchasing this Icon Fires Burner. Icon Fires is very safety conscious and we have taken every care in designing, manufacturing and assembling your Icon Fires Burner to ensure it operates effectively, efficiently and safely. In return we ask that you exercise care when using this product and follow the instructions below. -
Page 3: Trouble Shooting And Operating Tips
Trouble shooting and operating tips: The hooks on the back of the Sliding Lid Handle can be used to carry the Slimline Burner by hooking it around the slotted openings in the Vent Plate as shown in the image below. -
Page 4: Content Of Packaging
CONTENT OF PACKAGING: Burner Body - qty 1 Slider - qty 1 (2 of for 1400 Burner) Sliding Lid Handle - qty 2 (1 of 500 Burner) Battery operated Fuel Pump - qty 1 Plastic Bottle 500ml - qty 1 MAKE SURE THE FIREPLACE HAS COOLED OFF COMPLETELY BEFORE CLEANING: To clean dust, wipe with a dry cloth or sponge. -
Page 5: Accompanying Accessories
Fuel Material Room Output Time On mm (L x W x H) Average *Average Capacity Area *Average Brushed BF023 500x100x100 2.75 ℓ up to 90 m³ 40 m³ 6-9 hrs 0.30 ℓ/hr 304 SS kW/hr Brushed up to 165 5.5-8.5... - Page 6 Read manual before use Do not overfill or spill Signi Fires Do not refill when hot ™ Never refill over open flame Use a funnel or pump to fill Top View - 500 Slimline Read manual before use Do not overfill or spill...
- Page 7 Cut out Mount Plate Mount Plate Model No. Length - A Width - B Depth - C Length - K Width - J BF023 530 mm 130 mm 110 mm 545 mm 145 mm BF024 830 mm 130 mm 110 mm...
- Page 8 Installation - Adapter Mount Plate Adapter Mount Plate - Sizes Cut out Length - Cut out Width - Cut out Mount Plate Mount Plate Model No. Depth - C Length - K Width - J 598 mm 233 mm 110 mm 610 mm 245 mm 898 mm...
- Page 9 1 - Filling the Slimline Burner Mount Plate Top Plate Top Plate Sliding Lid Handle Hole Filling Line Filling Line Vent Plate Burner Vent Filling Line Fuel Tank Fill the Slimline Burner Fuel Tank to the Fill Line until the fuel becomes visible at the bottom of the Burner Vent.
-
Page 10: Extinguishing The Flame
3 - Adjusting the Flame Size The flame intensity is adjusted by inserting the Sliding Lid Handle’s tip into the corresponding holes in the Top Plate Sliding Lid as indicated above. Note the flame intensity takes a few minutes to change after an adjustment has been made 4 - Extinguishing the Flame Using the Sliding Lid Handle, pull the Sliding Lid to the front / closed position. - Page 11 Purchaser to Signi Fires of any such defect or fault in the product as soon as the Purchaser becomes aware of that fault or defect. All warranty claims must be returned to Signi Fires for assessment with a receipt or other proof of payment.
- Page 12 QC Checklist Components Handles 2 of (500 Burner only 1 of)..……………... Fuel bottle 1 of………….......... Slider 1 of (1400 burner 2 of)………………………. Manual 1 of…………………………………………… Pump 1 of……………………………………………... Burner body 1 of…………………………………….. Checked by…………………………………………. www.signifires.com...
