- Page 1 Android210 Hardware Manual Boardcon Technology Limited www.boardcon.com...
- Page 2 1.3. Limited Warranty Boardcon warrants this product to be free of defects in material and workmanship for a period of one year from date of buy. During this warranty period Boardcon will repair or replace the defective unit in accordance with the following process: A copy of the original invoice must be included when returning the defective unit to Boardcon.
-
Page 3: Table Of Contents
Content 1 Android210 Introduction............................3 1.1 Summary..............................3 1.2 S5PV210AH Features..........................3 1.3 Android210 Specifications......................... 4 1.4 PCB Dimension............................5 1.5 Block Diagram............................. 6 1.6 Motherboard Power meter.........................6 1.7 CPU Introduction............................7 2 Peripherals Introduction............................10 2.1 Power (J1&J6)............................10 2.2 Power switch (S1)............................. -
Page 4: Android210 Introduction
Boardcon Android210 is an embedded computer based on a Samsung S5PV210AH-A0 at 1GHz ARM Cortex-A8 CPU. An internal 64-bit bus provides a standard set of high-end on-board peripherals. The Android210 features 512MB DDR2 and 512MB high-speed NAND flash. It is an ideal solution for applications requiring cost-effective, low power and high performance. -
Page 5: Android210 Specifications
− LPDDR1 Interface with x16 or x32 data bus (up to 400 Mbps/ pin DDR) − DDR2 interface with x16 or x32 data bus (up to 400 Mbps/ pin DDR) − LPDDR2 interface (up to 400 Mbps/ pin DDR) 1.3 Android210 Specifications Feature Specifications... -
Page 6: Pcb Dimension
USB OTG 2.0, USB Host 2.0 Ethernet 10/100M Ethernet interface, DM9000 TVOUT RCA, standard composite video signal output COM1, DB9 RS232 serial port; COM1 ~ COM4 led out from a 20-pin expansion connector; COM5 ~ COM6, RS485 serial port... -
Page 7: Block Diagram
1.5 Block Diagram 1.6 Motherboard Power meter Support 12v/2A voltage Electric Electric System Connected devices System Connected devices current(A) current(A) Power, 7 inch Android Android 12v power 0.19 resistive screen （TN92) Power, sd card, play video, U Android... -
Page 8: Cpu Introduction
1.7 CPU Introduction CM210-II is an embedded system on module used to design PDA with a Custom base board, preinstalled Android4.0 OS. The module is designed to provide a cost-effective, low-power, high performance Application Processor solution for MID, smartphone and so on. - Page 9 Pin Definition Pin Signal Pin Signal Pin Signal Pin Signal DC_IN EINT17 EINT24 136 I2C_SCL1 DC_IN EINT18 EINT25 137 DATA15 AC97_SYNC/ DC_IN EINT19 138 DATA14 i2sLRCK1 AC97_BITCLK/ VDD_IO EINT20 139 DATA13 i2sSCLK1 VDD_IO EINT21 AC97_SDI/i2sSDI1 140 DATA12 VDD_ARM...
- Page 10 MMC0_D2 VD10 114 SPI0_CLK 159 EINT2 MMC0_D3 VD11 115 SPI0_CSn 160 OM5 MMC0_CLK VD12 116 EINT28 161 OM3 MMC0_CMD VD13 117 EINT29 162 OM2 MMC0_CDn VD14 118 EINT30 163 OM1 EINT7 VD15 119 EINT31 164 EINT3 MMC1_D0 VD16...
-
Page 11: Peripherals Introduction
2 Peripherals Introduction 2.1 Power (J1&J6) Android210 supports two types of power input. Power supply: DC 12V/2A Signal Description Signal Description 12V_IN DC12V. Power in Ground... -
Page 12: Power Switch (S1)
Ground 2. Lithium-ion polymer battery 7.4V (Default not solder) Signal Description Signal Description VBAT Connect to EUP8057 Ground 2.2 Power switch (S1) The power switch is a toggle switch, controlling the evaluation board power ON/OFF. Signal Description Signal... -
Page 13: Usb Host & Usb Hub_Sel (J3, J41)
Signal Description Signal Description USB OTG USB OTG negative VBUS OTG_DM mini-Receptacle Vbus data positive OTG_DP OTG_ID USB OTG ID signal data Ground Ground Ground Ground Ground 2.4 USB Host & USB HUB_SEL (J3, J41) The Android 210 only supports a A –type USB host 2.0 at High Speed (480Mbps), Full Speed (12Mbps) and Low Speed (1.5Mbps) modes. -
Page 14: Ethernet (J35)
J41 is used to select USB HUB (effect on Host). Connect Pin3&5, Pin4&6 with Jumper is select USB HUB, USB host is available; and connect Pin1&3, Pin2&4 is not. USB HUB Select (J41) Signal Description Signal Description USBDPA... -
Page 15: Tvout (J28)
DM9000_LANLE IO Supply Voltage LANLED detect speed VDD_IO (3.3V Power in ) 2.6 TVOUT (J28) S5PV210 MCU comes with 1 TVOUT, standard composite video signal, can be connected to all kinds of video device directly. Note: The TVOUT driver is unavailable. -
Page 16: Serial Ports (J9, J11, J14, J15)
PHONE Signal Description Signal Description Left Channel Headphone Output Left Channel Headphone Output Right Channel Headphone Right Channel Headphone Output Output Ground Android 210 supports 2-chanel SPEAKER that led out from 2x 2-pin 2.0mm connectors. The SPK on/off is controlled by a 2-pin 2.0mm connector (J27). - Page 17 COM1 (J9) Signal Description Signal Description Not connect RXD0N Uart 0 receives data input TXD0N Uart 0 transmits data output Not connect Ground Not connect Uart 0 clean to send input Uart 0 request to send output CTSn0N...
-
Page 18: Spi/Ad (J29)
Connect to MAX3430(inverting Connect terminal) MAX3430(non-inverting terminal) 2.9 SPI/AD (J29) Android210 reserves 1- channel high-speed SPI and 2- channel ADC interface. SPI features: • Full duplex • 8/16/32-bit shift register for TX/RX • 8-bit Prescaler logic • 2 clock sources: PCLK and SPI_EXT_CLK from SYSCON •... -
Page 19: Camera (J17, J21)
12bit ADC CH1 input Ground Ground 2.10 Camera (J17, J21) Android210 provides 2 types of camera interfaces: header and FPC connector. can be connected to J17 is a 2mm pitch 20-pin header connector. It the 1.3M pixels OV9650 module combined with an adapter plate. - Page 20 Signal Description Signal Description VDD_5V 5V Voltage VDD_IO IO Supply Voltage Reset or Power down Ground CAMFIELD Camera Camera IIC-bus LCAMPCLK Camera clock in CAM_SCL clock CAM_SDA Camera IIC-bus CH data LCAMVSY NC Camera VSYNC in LCAMHREF Camera HSYNC in...
-
Page 21: Gpio/Keypad (J30, J31)
2.11 GPIO/Keypad (J30, J31) J30 is a 20-Pin 2.0 connector multiplexed GPIO and Keypad. Keypad Features: • Open drain design • Glitch suppression circuit design • Multiple-key detection • Long key-press detection • Support 2-point and 3-point contact key matrix J31 is GPIO interface that can connect a variety of external devices. -
Page 22: Gpio/I2C (J5)
EINT7 EINT8 Interrupt 8 EINT9 Interrupt 9 EINT10 Interrupt 10 EINT11 Interrupt 11 HDMI_INT/ Defined for HDMI HPD EINT12 Interrupt 12 EINT13 signal /Interrupt 13 EINT14 Interrupt 14 EINT15 Interrupt 15 Ground Ground 2.12 GPIO/I2C (J5) The J5 connector is used to connect the capacitive touchscreen. -
Page 23: Boot Select (Sw1)
Connect to pin3 of MAX811 Ground Ground Ground 2.14 Boot select (SW1) CPU will boot in Android210 supports booting from SD Card, USB and NAND Flash. The corresponding way automatically after getting the OM signal set by DIP switch SW1. Signal Description Signal Description... -
Page 24: Lcd (J16, J18)
2. For SW1 switch, “1”= ON, “0” = OFF. 2.15 LCD (J16, J18) Android210 supports two types of LCD interfaces, one is 40P FPC and the other is 50P header. The board comes with driver for 4.3-inch resistive, 7-inch resistive/capacitive LCD. User also can choose other size of LCD&touchscreen. -
Page 25: Hdmi (J40)
HSY NC VCLK 2.16 HDMI (J40) Android210 supports HDMI v1.3,1080p@30fps at 60Hz high-definition digital output, and it also enables HDMI/LCD audio and video synchronization output. The HDMI interface is the regular 19pins HDMI type A, with width 13.9mm and thickness 4.45mm. -
Page 26: Wifi (J19)
Ground 2.17 WiFi (J19) J19 is SDIO WIFI wireless network interface (MMC CH1). Note: The signals USB DNB / USB DPB are reserved for USB WIFI module. Features: WLAN Standards: IEEE 802 Part 11b/g (802.11b/g) Coexistence: Hardware signaling Frequency Band: 2.400 ~ 2.484 GHz... -
Page 27: Rtc (Bt1)
Features • Low voltage consumption. • Support hot-plug. • Support SD mode and SPI mode. Signal Description Signal Description SD0_D3 SD0 interface DATA3 SD0_CMD Command/Response Ground VDD_IO IO Supply Voltage SD0_CLK SD0 clock... -
Page 28: Product Configurations
3 Product Configurations 3.1 Standard Contents • Android 210 Single board computer • CD-ROM (Linux BSP, Android BSP, Documents, tools, Schematic Drawing, datasheets) • Ethernet cable • Serial Cable • USB Cable • 12V/2A DC power adaptor 3.2 Optional Parts •...
