HOME GYM OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G102 and is the answer not in the manual?

Questions and answers

Related Manuals for Treo Fitness G102

Summary of Contents for Treo Fitness G102

  • Page 1 FOR MODEL : G102 HOME GYM OWNER’S MANUAL...

  • Page 2: Table Of Contents

    INTRODUCTION CONGRATULATIONS and THANK YOU for your purchase of this Treo home gym! Whether your goal is to tone your muscles, increase your strength or simply enjoy a fuller, healthier lifestyle, a Treo home gym can help you attain it – adding club-quality performance to your at-home workouts, with the ergonomics and innovative features you need to get stronger, healthier and faster.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTONS BEFORE YOU BEGIN FOR HOUSEHOLD USE ONLY IMPORTANT: READ THESE SAFETY INSTRUCTIONS BEFORE USE! SAVE THESE INSTRUCTIONS WARNING Read all instructions before using this Treo Home Gym. It is the responsibility of the owner to ensure that all users of this Home Gym are adequately informed of all warnings and precautions. During the assembly process there are several areas that special attention must be paid.

  • Page 4: Rubber

    PARTS LIST: #ITEM DESCRIPTION SPECIFICATION #ITEM DESCRIPTION SPECIFICATION Base frame Lower weight plate 370 x 200 x 42 Curve stabilizer backrest 50 x 50 x 1.5t x 536.5 695 x 225 x 50 Front vertical support seat 240 x 150 x 290 x 50 Upper beam Cable (weight—upper beam) 3180mm...

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 1 HARDWARE BAG 1: KEY COMPONENTS: M12*1.75*150L M10*1.5*95L Bolt (100) Bolt (104) Flat washer (101) Foot cap (32) M10 x 1.5 x 75L Qty:2 M10 x 1.5 x 70L Qty:2 D20 x D11 x 2T Qty:8 50 x 50 x 76.5 x 5T Qty:4 Weight guidance M12*1.75*80L...
  • Page 6 ASSEMBLY STEP 2 ASSEMBLY STEP 3 HARDWARE BAG 2: KEY COMPONENTS: HARDWARE BAG 3: KEY COMPONENTS: Weight pin (53) Weight sleeve (55) Weight washer (54) selecting rod (24) Round buffer (40) Round buffer (39) Square plug (62) Flat washer (101) Nylon nut (102) Allen bolt (122) D10.5 x 56.5L Qty:1...
  • Page 7 ASSEMBLY STEP 4 ASSEMBLY STEP 5 HARDWARE BAG 4: KEY COMPONENTS: HARDWARE BAG 5: KEY COMPONENTS: Fixing hook (37) multi-angle knob (36) Flat washer (101) Nylon nut (102) Flat washer (120) Square plastic cap (35) Flat washer (106) Nylon nut (107) Bolt (113) 3/8”-16UNC x 138L 3/8”-16UNC x 28L...
  • Page 8 ASSEMBLY STEP 6 ASSEMBLY STEP 7 HARDWARE BAG 6: KEY COMPONENTS: HARDWARE BAG 7: KEY COMPONENTS: Flat washer (101) Nylon nut (102) Square plastic cap (35) foam (44) D20 x D11 x 2T Qty:6 M10 x 1.5 x 10T Qty:2 50 x 50 x 18.5 Qty:1 D23 x D80 x 165L Qty:2 Bushing (31)

  • Page 9: Flat Washer (101) And

    ASSEMBLY STEP 8 ASSEMBLY STEP 9 HARDWARE BAG 8: KEY COMPONENTS: HARDWARE BAG 9: KEY COMPONENTS: Nylon nut (102) Bushing (65) Raised pulley (56) Flat pulley (57) Flat washer (101) Bolt (112) Single pulley support (20) Double pulley support (19) Raised pulley (56) M10 x 1.5 x 10T Qty:4 D18 x D10 x 14.5 Qty:4...

  • Page 10: Flat Washer (101) Nylon

    ASSEMBLY STEP 10 ASSEMBLY STEP 11 HARDWARE BAG 10: KEY COMPONENTS: KEY COMPONENTS: Strap (118) Cover fixing plate (29) Cover fixing plate with rod (28) Hook (25) Flat washer (101) Nylon nut (102) Bolt (115) Bushing (65) Cable (leg curler) (52) Flat pulley (57) Qty:8 D8 x 180 x 270 Qty:4...

  • Page 11: Conditioning Guidelines

    CONDITIONING GUIDELINES STRETCH FIRST Before using your product, it is best to take a few minutes to do a few gentle stretching exercises. Stretching prior to exercise will improve flexibility and reduce chances of exercise related injury. Ease into each of these stretches with a slow gentle motion. Do not stretch to the point of pain. Make sure not to bounce while doing these stretches.
  • Page 12 DAILY LOG SHEETS DAT E S ET 1 SE T 2 SE T 3 D AT E SE T 1 SE T 2 SET 3 E X E RCIS E WE IGHT REPS WE IGHT REPS WEI GHT REPS EXE RCIS E W E IGHT REP S W E IGHT...

  • Page 13: Troubleshooting

    • Has the machine been lubricated and maintained per the maintenance schedule? Answering these and other questions will give the technicians the ability to send proper replacement parts and the service necessary to get you and your Treo Fitness home gym functioning again!

  • Page 14: Limited Home-Use Warranty

    Waste Disposal Treo Fitness. TREO Fitness products are recyclable. At the end if its useful life please dispose of this article correctly and • Incidental or consequential damages. Treo Fitness is not responsible or liable for indirect, special safely ( local refuse sites).
  • Page 15 G102 070210 © 2010 Treo Fitness Products | Made in China...
