IMPORTANT use GuIdelINes dRINkING WATeR sysTeM sPecIfIcATIONs RePlAceMeNT PARTs dIRecTORy GeTTING sTARTed INsTAllATION: cOuNTeRTOP sysTeM (Model: FP6000CT) RePlAcING The cARTRIdGe: cOuNTeRTOP sysTeM INsTAllATION: uNdeR-cOuNTeR sysTeM (Model: FP6000UC) dRIllING A hOle IN A sTAINless sTeel sINk dRIllING A hOle IN A PORcelAIN/ceRAMIc sINk...
8 For this System to continue to perform as tested and represented, use only Genuine, WQA Certified, Royal Prestige Filter Cartridges. 9 Genuine, Royal Prestige Filter Cartridges may be purchased from your Independent Royal Prestige Representative. For additional purchase information, please contact the Royal Prestige Customer Service Center at: 1-800-279-3373 .
Page 4
10 After set-up and installation, DO NOT remove the Battery Shuttle except when replacing the Filter Cartridge. Removing the Battery Shuttle prematurely may result in a loss of stored data. 11 Be sure to replace the Battery Shuttle each time a new Filter Cartridge is installed.
Independent Royal Prestige Representative or to the Royal Prestige Customer Service Center (1-800-279-3373). Be sure to request an Expandable Adapter. 7 If your kitchen faucet does not fit any of the...
Page 8
IMPORTANT Insist on Genuine, WQa Certified, Royal Prestige filter Cartridges. only Genuine, Royal Prestige Cartridges have been tested and certified by the Water Quality association to insure the performance represented in the Performance Data Sheet. failure to use Royal Prestige filter cartridges and replacement components will invalidate your warranty 1 Place a towel or other soft cloth in sink.
Page 9
Knob forward to latch T-Bolt. Tighten Knob. IMPORTANT ONly ReMOVe bATTeRy shuTTle AT TIMe Of cARTRIdGe RePlAceMeNT Removing Battery Shuttle prematurely may result in a loss of stored data. a new Battery Shuttle is included with every Genuine, WQa Certified, Royal Prestige filter Cartridge. fReSCaPURe™...
Page 10
11 To access the Battery Shuttle, slide Battery Cover upward and set on counter. Remove Battery Cover old Battery Shuttle from Monitor and discard. Insert new Battery Shuttle and re-install the Battery Cover. 12 Orient Tubing and Monitor Cable in Enclosure so that the Filter Housing can be lowered into the Enclosure without interference.
Page 11
insTallaTion: UndeR-CoUnTeR sysTem (Model: FP6000UC) cAuTION Using power tools near water may result in electrical shock or even death. Be certain that sink area is dry prior to using any power tool. IMPORTANT If you are experienced in this type of installation and choose to install yourself, please proceed with extreme caution.
TyPiCal UndeR-CoUnTeR sysTem insTallaTion Dedicated Drinking Water Faucet Cable Cold T-Valve Monitor BLUE Tubing Tubing WHITE Tubing Filter Housing dRillinG a hole in a sTainless sTeel sink: cAuTION this type of sink can be scratched very easily. Use extreme care. If you have any doubts about doing this yourself, consult a licensed plumber 1 Locate an area on your sink to install the Dedicated Drinking Water Faucet.
dRillinG a hole in a PoRCelain/CeRamiC sink: cAuTION this type of sink can chip very easily. If you have any doubts about doing this yourself, consult a licensed plumber 1 Locate an area on your sink to install the Dedicated Drinking Water Faucet. (Make certain there are no support ribs under the sink in that area.) Cover the designated location for the Faucet installation on sink with masking tape.
faUCeT insTallaTion: 1 Slide the Monitored Beauty Ring through the Red, White and Blue Tube ends and onto the Faucet Stem. 2 Insert the Red, White and Blue Tube ends (including the Monitor Cable) through the hole in sink. Insert Faucet shank into hole. 3 From under the sink, insert the Red, White and Blue Tube ends (including the Monitor Cable) through Rubber Washer and slide...
sysTem insTallaTion: Read these instructions completely before starting system Installation Make a determination whether you will be able to make a “Typical” installation (as shown in the illustration on page 10) after looking at your under-sink cabinet area. If the configuration of your under-sink area does not permit a “Typical” installation, it will be necessary to develop one of your own.
Page 16
6 Cut a 6 in. length from the 5 ft. of Blue Tubing provided. Take this short piece of Blue Tubing and insert one end into the Blue “Outlet” Collar Blue on Lid. Take the remaining Blue Tube end and push it into the “Inlet”...
Page 17
IMPORTANT Insist on Genuine, WQa Certified, Royal Prestige filter Cartridges. only Genuine, Royal Prestige Cartridges have been tested and certified by the Water Quality association to insure the performance represented in the Performance Data Sheet. failure to use Royal Prestige filter cartridges and replacement components...
Page 18
5 Remove sanitary plastic wrap from the new Filter Cartridge. Thread new Cartridge clockwise onto Lid until you feel resistance. Make an additional quarter turn. dO NOT over-tighten 6 Make certain Gasket is firmly seated onto Lid. With new Cartridge connected to Lid, lower Cartridge into Housing and align Lid with Housing.
ReAsON: The Cartridge is reaching the end of its rated capacity and will need to be replaced soon. Order a Genuine, WQA Certified, Royal Prestige Filter Cartridge now so that you will have it when the RED lamp begins flashing, signaling it is time to replace the Cartridge.
Page 21
TRoUbleshooTinG cONdITION: Water is leaking between a tube or fitting and a Collar. ReAsON #1: The tube or fitting is not completely inserted into Collar. sOluTION: Press tube/fitting firmly into Collar. ReAsON #2: Tube end has been damaged, elongated or not cut squarely.
Damage in Shipment: Hy Cite will replace any covered product damaged in shipment free of charge if you notify Hy Cite within 30 days after your receipt of the product. Simply contact the Royal Prestige Service Center. As a condition to replacement, Hy Cite may require you to make the damaged product available for pick-up at Hy Cite’s expense.
