Summary of Contents for Dat Optic eSATA_PCIe
- Page 1 PCI-Express SATAII host adapter with 1x eSATA & 1x SATA connector eSATA_PCIe2 PCI-Express SATAII host adapter with 2x eSATA connectors User’s Guide...
- Page 2 DATOptic Inc reserves the right to make changes to the products or specification to improve performance, reliability, or manufacturability. Information furnished ins believed to be accurate and reliable, but DATOptic Inc shall not be responsible for any errors that may appear in this document. DATOptic, Inc. makes no commitment to update or keep current the information contained in this document.
-
Page 3: Table Of Contents
Specifications 2 – Installing the eSATA_PCIe Install the eSATA_PCIe card Install the Disk Drives/Devices Install External Devices in the eSATA_PCIe Install the Driver Microsoft Windows 2003 Server and Windows XP To complete the drivers installation To confirm the drivers installation... -
Page 4: Getting Started
1 Getting Started This Installation Guide describes how to install the DATOptic, Inc. eSATA_PCIe(2) host bus adapter, Serial SATA II devices and device drivers. Package Contents: 1x eSATA_PCIe(2) 1x CD_ROM drive and Document System Requirements Processor Type: - Intel Pentium, Celeron or Xeon system, (or equivalent AMD Opteron or Athlon system) for Windows OS. -
Page 5: Esata_Pcie Specifications
Operating: 5% to 80%m non condensing, Non-operating 5% to 95% non condensing Install the eSATA_PCIe(2) The eSATA_PCIe(2) Serial ATA II card will fit into any available PCI-Express slot in your workstation or server computer systems ( see figure 3) Figure 3... -
Page 6: Install The Driver
2. Remove the cover of your system 3. Remove the inside slot cover of an available PCI-Express on you system motherboard 4. Install the eSATA_PCIe(2) host adapter into the open PCI-express slot, secure the host adapter by tighten the PCI bracket to system frame 5. -
Page 7: To Confirm The Drivers Installation
3. When installation is complete, click Finish. To confirm the driver installation 1. Right click at My computer icon on your desktop and choose Manage from the pop-up menu, 2. Double –click Device Manager 3. Double – click SCSI and RAID controllers 4. -
Page 8: Microsoft Windows 2000
Microsoft Windows 2000 After you install the eSATA_PCIe(2) and the external devices then power on your computer system, the Found New Hardware Wizard will open. 1. Insert the DATOptic SATA Drivers CD-ROM media into CD/DVD-ROM Drive, Click Next 2. Select Search for a suitable driver for my device (Recommended) and click Next. - Page 9 4. Click Next once the driver is found. 5. If you get the Digital Signature Not Found message. Click YES to continue installation 6. When the installation is complete. Click Finish and reboot the system...
-
Page 10: To Confirm The Drivers Installation
To confirm the driver installation After reboot the computer system 1. Right click on My Computer icon on your desktop and choose Properties 2. Select Hardware then Device Manager 3. Double click SCSI and RAID controllers 4. Verify that the Silicon Image Sil3132 SATALink Controller appear, as shown below. -
Page 11: Mac Os X Installation
MAC OS X Installation After you install the eSATA_PCIe(2). 1. Power on your computer. 2. Insert DATOptic SATA Drivers CD-ROM 3. Open the MAC Folder and click the Sil3132.pkg installer. 4. Click Continue... - Page 12 5. Review provided Readme. Click Continue 6. Review the License agreement. Click Continue.
- Page 13 7. Click Agree to accept the terms of the License agreement and proceed with the installation. 8. Select the system hard drive...
- Page 14 9. Click Upgrade to install driver 10. Enter the user name and password for the root account. Click OK...
- Page 15 11. Click Continue Installation to acknowledge the restart warning 12. Click Restart to reboot the computer and complete the installation...
-
Page 16: To Confirm The Drivers Installation
To confirm the driver installation In case of a driver installation failure, an error message will display after you reboot the computer. Follow the recommendation in the error message. If you have question or comment please email us at tech@DATopit.com Thank you for choosing DATOptic Inc., products...
