Summary of Contents for Blankom WLANIOS 5161.01
-
Page 1: Operating Instructions
Professional Headend Solutions Operating instructions 8-port switch with WLAN port WLANIOS Part N : 5161.01... -
Page 2: Table Of Contents
WLANIOS 8-port switch with WLAN port Part N : 5161.01 Contents 1. Safety and operating instructions ......................3 2. Device variants ............................3 3. General..............................3 4. Front view ............................... 3 5. Functional description..........................4 6. -
Page 3: Safety And Operating Instructions
WLANIOS 8-port switch with WLAN port Part N : 5161.01 1. Safety and operating instructions When assembling, starting-up and adjusting the modules, it is necessary to consider the system specific references in the manual instruction. The modules may only be installed and started up by authorized technical personnel. There are only permitted the mounting styles indicated in the quick start guide, which is included each module. -
Page 4: Functional Description
WLANIOS 8-port switch with WLAN port Part N : 5161.01 5. Functional description The WLANIOS module is a 8-port 10/ 100 Base-T Ethernet switch with an additional WLAN port, which was created for the SBL sy- stem. It fits seamlessly into the SBL case, control and quality concept. With the switch up to 7 SBL modules can be controlled via a PC/ laptop. -
Page 5: Adjustment And Information Menus
WLANIOS 8-port switch with WLAN port Part N : 5161.01 7.2 Adjustment and information menus Hereinafter the settings and information menu of the module are described in short form, so the user can adjust according to its en- vironment, the settings of the module. The wireless functionality is realized by the module WIZ610wi of the company WIZnet Co., Ldt. For detailed and advanced setup please refer to the WIZ610wi User‘s Manual, which can be obtained of the WIZnet company‘s home- page (http://www.wiznet.co.kr). -
Page 6: System
WLANIOS 8-port switch with WLAN port Part N : 5161.01 7.2.1.1 System In this overview, some basic settings and the status of the device are listed. By clicking the “Refresh“ button, the current values are read out and listed. 7.2.1.2 Active clients This table shows the MAC address, transmit and receive packet counter for each associated wireless client. -
Page 7: Network Setting
WLANIOS 8-port switch with WLAN port Part N : 5161.01 7.2.2 Network setting On this page you can configure the parameters of the local network, which connects to the LAN port of the access points. The set- tings for the IP address, subnet mask, DHCP , etc. are performed. 7.2.3 Wireless setting On this page you can select the various operating modes of the wireless connection. -
Page 8: Serial Setting
WLANIOS 8-port switch with WLAN port Part N : 5161.01 7.2.4 Serial setting This feature of the integrated WLAN module is not supported in WLANIOS. 7.2.5 Security This page lists the security settings. Different authentication and encryption settings are selected and set. 7.2.6 Management In the menu “Managenent“... -
Page 9: Config Data
WLANIOS 8-port switch with WLAN port Part N : 5161.01 7.2.6.3 Config data This menu allows the configuration of the system data stored on the PC or a saved system file to be loaded. 7.2.6.4 Logo data Similar to the previous menu here the logo file is stored or is loaded a new logo. The file must be in .gif format and will then appear in the upper left corner above the menu tree. -
Page 10: Ntp
WLANIOS 8-port switch with WLAN port Part N : 5161.01 7.2.6.7 NTP In this menu you can get the system time by synchronizing with a public time server over the Internet. In Germany, for example, the atomic clock in the Physikalisch-Technische Bundesanstalt in Braunschweig for the statutory period is essential, in Switzerland, that of the Federal Office of Metrology, those in Austria in the Federal Office of Metrology and Surveying. -
Page 11: Technical Data
WLANIOS 8-port switch with WLAN port Part N : 5161.01 8. Technical Data WLAN parameters Network ports Standard IEEE 802.11b,IEEE 802.11g [3] Link attributes 8x Ethernet,10/ 100 Base-T Frequency range 2.412 ... 2.485 GHz according IEEE 802.3, Output power (± 1 dBm) IEEE 802.3u, IEEE 802.3x [4] IEEE 802.11b 16 dBm @ 11 Mbps Connectors... -
Page 12: Bibliography
7.1 Häußer Options available upon request! Subjects to changes due to technical progress. BLANKOM Antennentechnik GmbH Hermann-Petersilge-Straße 1 • 07422 Bad Blankenburg • Germany • Phone +49 (0) 3 67 41/ 60-0 • Fax +49 (0) 3 67 41/ 60-100... -
Page 13: Declaration Of Conformity
Declaration of Conformity The Manufacturer BLANKOM Antennentechnik GmbH ∙ Hermann-Petersilge-Str. 1 ∙ 07422 Bad Blankenburg ∙ Germany herewith declares the conformity of the product 8-fach switch with WLAN port Product name: WLANIOS Type: 5161.01 Product number: according to the following regulations...
