- Page 1 H.264 IP Camera Server ES-IPS507 User Manual V1.3 IPS507 Three channels wired and four channels wireless video input server IPS507WD Four channels wired video input server...
-
Page 2: Table Of Contents
Welcome to use our IPS507 server Please read the manual carefully before you use it, which will provide you a great help. We do our best on improving products software, hardware function, and our service quality. Please contact the dealer once any doubt on using or product function are not the same with the manual. - Page 3 4．Server Management 4.1 Setup ⑴ 4.1- Channel Parameters ⑵ 4.1- Network System Settings ⑶ 4.1- Hardware Management ⑷ 4.1- Alarm Input/Output ⑸ 4.1- Storage on IPS507 ⑹ 4.1- Talkback ⑺ 4.1- Media Center ⑻ 4.1- User Management ⑼ 4.1- 3322 DDNS ⑽...
-
Page 4: Introduction
5.3 Motion Detection 5.4 Alarm Setting 5.5 Format hard disk Chapter 1 Introduction IPS507 server uses the latest codec algorithm to transfer the analog AV signal to digital by H.264 compression algorithm . Using TCP/IP protocol to send low-bit-rate AV encoded data to remote PC by IP package, achieve the remote transmission, monitoring and storage of AV signal to digital. - Page 5 PS507 server is designed as an embedded control solutions for IP network video and data surveillance.Using the faster computing speed DSP chipset and the latest H.264 codec algorithm, really achieve the low-rate stream high definition.Every frame on CIF is only 1.0KB to 1.5KB. Specially suitable for network transfer.The max transmission speed is up 25fps(PAL)/30fps(NTSC) IPS507 is a multi-use IP camera server.
-
Page 6: Features
2.2 Features 3 channel wired channels A/V 4 channel wireless channel Model Local A/V outputs inputs (2.4GHz) A/V inputs IPS507 Yes(4wired) IPS507WD 3 way audio/video control: front panel, remote controller, remote PC. Real time remote surveillance of multi audio/video sources. Support both WAN(via ADSL MODEM) and LAN connection.Note:3G dial-up connection is under developing. -
Page 7: Packing List
Interface 1 USB ports（USB2.0 port for storage） Storage devices Talkback port 1 USB port ( USB port for audio) 3 channels wired,4 channels wireless at 2.4GHz AV input AV output PC :4 channels.Local:1 channel Recording format RS485 PTZ Control Network interface RJ-45/10-100 Base T Support TCP/IP，UDP, ARP, HTTP, DHCP, FTP etc Network Protocol... -
Page 8: Rear Panel
Windows XP SP2 or above Windows 2000 Windows 2003 Vista Windows 7 Advise to use IE 6.0 or above browser System configuration requirements: CPU:2.4GHZ or above ● Memory:512M or above ● Network Card: 10-100M or above ● Display Card: 128M ●... - Page 9 The buttons and indicators are described as below: ① GUD: a button for system arming/disarming upon external inputs GUD stands for “guard”, armed for arming and disarming , the system manually following the same working mechanics of the remote controller. Notes: Arming manually: the system falls under surveillance when “GUD”...
-
Page 10: Operation
CHS: Channel switching button: CHS stands of “channels”, used to switch the local output channels. The switch of wireless channels is synchronous with the remote monitoring channels. The function of this button is the same as “A” on the remote controller. ⑧... - Page 11 ② Double click the “IPSClient” , it will come out a dialogue. Please entering the user name and password after click. Default user name is “admin”, no password. ③ Below image window will display upon successful login. Software interface divides into 4 parts：...
-
Page 12: Image Window Page
○ ○ Video window Basic setting and management ○ LAN searching: search video servers from LAN ○ Network setting 3.2 Image Window page ① Video window : video display of the network video server, there shows data of name, time, frame, server address under each channel. 1)Image function... - Page 13 C1 : Channel name, can be changed Time :2009-9-1 21 :29 :24 IP address : shows WAN/LAN IP address or domain name Speed : real transferring frames per second 2)Click image via right button to get follow function Close :close present channel image Record: record present channel.
- Page 14 ② Basic setting and management : basic setting of image and selected server, multi-server management. ③ LAN searching: search video servers from LAN First login client software, find LAN searching window, click , available IP address will coming out as below picture: choose it then click ④Network setting: User can add the already on line device to server list on software.
- Page 15 default。 Zoom function Chapter 4 Video server setting 4.1 Video Server Setting Select a on line video server in list, right click and choose settings, enter setting page. ⑴ 4.1- Channel parameters...
- Page 16 Name: name for each video channel CBR: fixed stream( the WAN network speed will influence the fixed stream) Mobile: set to show images in mobile phone or not Resolution: for video images, there are 4 types: ⒈ （704×576）” “D1 ⒉ （704×288）”...
- Page 17 TV systems: PAL/NTSC Name: name for server Network type：dynamic IP/static IP/ PPPOE auto dial-up Internet access Working port: used for remote client software browsing web port: for web MAC address: server MAC address IP address: server address in LAN Subnet Mask: set up comply with router Gateway: set the gateway in LAN DNS: Please fill the correct DNS(different place with different DNS address), please inquire from local Service providers.
- Page 18 4.1-⑶ Hardware setting Output to local monitor Auto: user can select auto-switch in monitor, as well as the switch time for each channel.
- Page 19 Manu: select to display one channel by manual. Notes: audio will output to monitor follow video(video and audio are in same channel) ⑷ 4.1- Alarm input/output Input/output link 1、 Input: there are 4groups external sensor signals, with Nopen(Normal open) and Nclose(Normal close) status.
- Page 20 to alarm management setting 5.4 ⑸ 4.1- Storage On IPS507 Storage: videos, Continual recording, motion detector, Prerecorded( prerecorded can work with others, but continual recording and motion detector can not). 1, User can set different video recording types toward to the 4 channels, like disable, continuous, motion and pre-record.
- Page 21 Server connected with media center, it’s easy for controlling. This function will be update, can not work right now. ⑻ 4.1- User management There are 4 kinds of user User: normal user, only can browse images. Power User：can control some function keys Admin: with all functions(can open or delete user, including power user.) Default admin: with all functions(it can be revised password, but can't be deleted) For example:...
- Page 22 ⑼ 4.1- 3322 DNS 3322 DNS: China second level free domain name. Easy for user to apply a free domain name. Then analyse IP server's IP address and port on router. To realize internet browsing. ⑽ 4.1- DYN DNS There are many free domain names appliable. User need to apply a domain name, to setup the ip addrees and port inside router, then it can access to Internet.
- Page 23 Email receiving:please fill in one available email address. Email sending:please fill in email address which support SMTP Sender name:can be any name SMTP server:sending email address need to support SMTP,and port means the SMTP server port. Verify information:please fill in the sender’s account and password ⑿...
- Page 24 Update: application upgrade. 4.2 Disconnect Disconnect the device to be on line, disconnected can be click to connect, set it to be on line again. 4.3 Login Info Login info, right click to read the server data, but can't be modified. 4.4 Talking Right click to start talking with local device, same with 4.1-6 4.5 Delete...
- Page 25 Right click to delete connected on line server on software. Chapter 5 Basic Setting To non-fixed device,you can set up the relative setting only if there has video in video window) 5.1 PC recording Select recording path: can select recording video in several partitions. After choose well path, right click video which need to be recorded.
- Page 26 5.2 Playback Select Local File: Playback recorded file on PC port. Please select channel,then choose different files(You can speed up the speed of reviewing).After setting well,please click “Play”to start playback. Select Server Data: Review recorded file from USB storage device. Please select reviewing channel,then choose different files(You can speed up the speed of reviewing).After setting well,please click”Play”to start review.
- Page 27 Choose recorded file then press press ,you reviewing speed click: 5.3 Motion Detection Choose a video to set up motion detection first, double click to amplify picture. When...
- Page 28 picture is amplified to big enough, motion menu will become black color from gray color, then user can set its sensitive, choose area(can be 2 area in one picture) then save it. Pls double click picture back to normal picture, motion detection begins. Available motion detection recording,please refer to 4.1-(5) storage on server.
- Page 29 After format the moveable storage disk,it will become a storable video file system. Steps of format:please format U disk on PC first(Note:please format the file system of U disk to FAT32),then format again on IPSclient software and it will automatically become DAT video file.
- Page 30 windows mobile 5 and 6 Summary: Only if mobile phone support WM 5 or 6, or symbian s60 V2/V3/V5 are compatible with our device. Relative mobile operation instruction is attached.
