AGR Installation and Operation Guide
The AirGlide GPS Upgrade for:
AirGuide Model 2025
w/ a metal internal frame
This Kit includes all the components necessary to upgrade the Pitot driven speedometer to GPS.
The finished gauge will look and mount exactly has it did originally. The integrated Backlights are life-time LEDs.
This document outlines the step-by-step conversion procedure and installation.
Please download the most up to date instructions:
http://nauticlaugic.com/AGR%20Manual%20for%20Airguide%202025%20Metal%20Frame.pdf
Metal
Internal
Frame
AirGlide
GPS
Upgrade
nautic Laugic
www.nauticlaugic.com
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the AirGuide 2025 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nautiques AirGuide 2025

  • Page 1 AGR Installation and Operation Guide The AirGlide GPS Upgrade for: AirGuide Model 2025 w/ a metal internal frame This Kit includes all the components necessary to upgrade the Pitot driven speedometer to GPS. The finished gauge will look and mount exactly has it did originally. The integrated Backlights are life-time LEDs. This document outlines the step-by-step conversion procedure and installation.
  • Page 2 AGR Installation and Operation Guide The AirGlide Kit, Tools, and Prep Contents QUANTITY DESCRIPTION AirGlide Retro-fit Assembly (AGR) Swift GPS Receiver (Orange) or GPS Y-Splitter (Orn-Orn-Orn) Screws, #4-40 x 5/16”, Socket Hd, SS Nuts, #4, SS Grommet, Rubber 1 set Calibration Wires General Small Tools and Material Required DESCRIPTION...
  • Page 3 AGR Installation and Operation Guide Disassembly Begin with the gauge removed from dash: Thereby, free the Pitot hose (cut if necessary). Remove the Backlight, by pulling it from the case. And remove the mounting bracket. *** Remember to always protect the Lens Face with a soft cloth or pad to avoid scratches. *** Refrain from discarding removed parts! Some are reused.
  • Page 4 AGR Installation and Operation Guide The internal mechanism pictured is not exactly the same, and is shown for reference only. 7. Now evacuate all the pressure-mechanical components from within the frame… done without separating the dial from the frame. a. Using Diagonal Cutters, snip the spindle shaft, and remove.
  • Page 5 AGR Installation and Operation Guide Assembly Insert the grommet into the case at the old Backlight hole. 2. Ensure the case Mounting-bracket studs are secure. When necessary tighten the nuts with a ¼” nut-driver 3. Point the dial face away and orient the frame’s old spindle mount to the left;...
  • Page 6: Electrical Install

    AGR Installation and Operation Guide 9. Inside the case, about ¾” from the External GPS connector, gently fold its wires over. Coarsely align the stand- offs with their corresponding case holes, and slide the Frame/Dial assembly into the case. 10. Fasten the Frame to the case: a.
  • Page 7 AGR Installation and Operation Guide Calibration A calibration is required to accurately convert reported GPS speeds into needle positions. The procedure is simple and takes two minutes. For best results read the entire procedure first. Confirm the GPS Receiver is unplugged. And the Jumper wires are correctly inserted in the PS2 mini circular connector.
  • Page 8: Warranty

    AGR Installation and Operation Guide External GPS Receiver The compatible GPS Receiver is waterproof with great reception. It is resilient and tolerant to marine surroundings. Following these constraints are key: the GPS requires a clear line-of-sight to the sky; the windshield and cloth top shouldn’t present a problem.
