Summary of Contents for Combi-Cam miniK 10
- Page 1 Combi Cam electronic cam lock cabinets lockers carts OPERATING MANUAL...
-
Page 2: Single User Mode
INTRODUCTION: Combi-Cam E – electronic cabinet lock with master/manager code, one-time-use functionality, and up to 10 years battery life. Combi-Cam E can be installed for both right and left hand installations – anywhere that needs flexibility of master/manager codes. The eco-friendly MiniK10 offers both convenience of far less frequent battery changes and a more environmentally friendly solution. - Page 3 MULTIPLE USER MODE (LOCKER MODE / ONE TIME USE MODE) In multiple user mode, opening and closing with a password process is same as Single User. However, each time lock is in open position, each user can enter in their own unique 4-digit code to lock and then open the MiniK10.
-
Page 4: Master Password
PROGRAMMING THE MINIK10 The MiniK10 can be customized from factory default settings tailored to your needs. ACCESSING THE PROGRAM MENU: Press the button and then enter the 6-digit master password. Press the button. Press the program number that you will make an adjustment to, and then press the adjustment selection. PROG. -
Page 5: Changing The Battery
PROGRAMMING OPTION DEFINITIONS: Restoring factory settings: All factory default settings are restored (see program menu). User password becomes <1-0-1-0> and master password becomes <1-0-1-0-1-0>. Individual Use or Locker Mode: Factory default is locker mode (one time use) whereby each user that walks up to an open MiniK10 can enter their 4- digit code to close and open lock. -
Page 6: General Warnings
MAINTENANCE: - Clean front of lock with a mild damp cloth with detergent if needed. - Do not use any hard or scratching cleanser. - Do not clean with chemical materials that melt plastic (e.g. thinner, acetone, etc.) -Be careful not to spill water on lock. GENERAL WARNINGS: - Read manual before using lock. -
Page 7: Quick Info
Combi Cam QUICK INFO NOTE: These are default settings by the factory. Once they are changed, be sure to right down your new code ! Opening direction varies according to type of door MiniK10 is installed. All opening illustrations depict right handed door installation. Page 7... -
Page 8: Technical Specifications
Key Pad: Silicone Keypad Operating Temperature: -5 / 55 C Storage Temperature: -10 / +70 C Operating Moisture: 20 – 80% Rh (without condensation) OTHER PRODUCTS IN THE COMBI-CAM FAMILY: www.combi-cam.com ™ ™ eco-friendly electronic lock ™ Combi Cam ™...
Need help?
Do you have a question about the miniK 10 and is the answer not in the manual?
Questions and answers
Schloss öffnet micht
The Combi-Cam miniK 10 lock may not be opening due to one or more of the following reasons:
1. Incorrect Password Entry: The user, service, or master password entered may be incorrect. The factory default user password is <1-0-1-0> and the master password is <1-0-1-0-1-0>.
2. Password Forgotten: If the correct password is forgotten, the lock cannot be opened.
3. Handle Not Rotated in Time: After entering a correct password and pressing the button, the handle must be rotated within 5 seconds to open the lock.
4. Lock is Blocked: If the service password is active and blocking is enabled (Program 9.1), the lock may be intentionally blocked.
5. Battery Issue: The lock may not have enough battery power to operate correctly.
6. Mode Confusion: If the lock is in multiple user mode, a new code must be entered when locking, and only that code can unlock it. Using the wrong code will not open the lock.
7. Factory Settings Restored: If factory settings were restored (Program 0-1), the passwords may have reverted to default, and previous passwords will no longer work.
This answer is automatically generated
