Summary of Contents for Systime HELLO II
- Page 1 0309 V3.1 SYSTIME CORPORATION LIMITED HELLO II Bluetooth Headset User’s Guide Hello2.com.tw...
-
Page 2: Table Of Contents
0309 V3.1 Contents Safety Approvals and Certification ...................... 3 Introduction............................5 Headset Features........................... 7 Charging the Headset..........................8 Wearing the Headset ........................... 10 Switching the Headset On/Off ......................11 Pairing the Headset ..........................11 Using the Headset ..........................13 Accepting a Call........................... 13 Ending a Call ............................ -
Page 3: Safety Approvals And Certification
Safety Approvals and Certification Users are advised not to make changes or modify the device in any way. Changes or modifications not expressly approved by Systime will void the warranty. FCC Notices This device complies with part 15 of the FCC rules. Operation is subject to the following two... - Page 4 0309 V3.1 CE Statement Important Notice: This device is a 2.4GHz FHSS Bluetooth headset, intended for office and home uses in all EU and EFTA member states. The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to Systime.
-
Page 5: Introduction
Bluetooth Headset is quite light, weighing just about 10g. Before you begin, you should ensure that the device you would like to use in conjunction with the Systime Hello II Bluetooth Headset is compatible with Bluetooth specification v1.1 or higher and supports the Bluetooth headset profile. - Page 6 0309 V3.1 Bluetooth Wireless Technology The Bluetooth wireless technology is set to revolutionize the personal connectivity market by providing freedom from wired connections. It is a specification for a small form-factor, low-cost radio solution providing links between mobile computers, mobile phones and other portable and handheld devices, and connectivity to the Internet.
-
Page 7: Headset Features
0309 V3.1 Headset Features 1. Talk Button: Switches the headset on/off, answers/ends a call, pairs the headset with a device, and is used for voice dialing. -
Page 8: Charging The Headset
0309 V3.1 Charging the Headset The headset has a rechargeable battery. Before using the headset for the first time, you have to charge the headset battery for approximate 150 minutes to get a full charge. A fully charged battery provides over 4 hours of talk time and over 1 week of standby time. - Page 9 0309 V3.1 To charge the headset: Connect the AC adapter to the desktop charger, then plug into an electrical outlet. Place the headset in the desktop charger. During charging, the red indicator light on the desktop charger illuminates. When the battery is fully charged, the indicator light on the charger turns green. You can now remove the headset from the desktop charger, and disconnect the desktop charger from the AC adapter.
-
Page 10: Wearing The Headset
Wearing the Headset The Systime Hello II Bluetooth Headset can be worn either on the right or left ear. The earpiece is adjustable, and the 90-degree, rotatable design ensures a snug yet comfortable fit in your ear. To put on... -
Page 11: Switching The Headset On/Off
0309 V3.1 Switching the Headset On/Off To switch the headset on Press the Talk button for about 5 seconds until you hear two high tones. The LED indicator flashes blue four times. The headset switches on and enters standby mode. The LED indicator continuously flashes blue every 3 seconds. - Page 12 Perform a device discovery from the mobile phone. (For details on device discovery, please consult your phone’s user’s guide.) Once the mobile phone discovers the headset, the text Hello II appears on the phone’s screen. Follow the phone instructions to accept pairing. When prompted to enter the passkey, enter the number: 0000.
-
Page 13: Using The Headset
0309 V3.1 Using the Headset Before using the headset, make sure that (1) the headset is switched on and connected to a paired Bluetooth mobile phone; (2) the headset is within 10 meters of the phone; and (3) the phone’s Bluetooth feature is on (see your phone’s user’s guide). -
Page 14: Volume Control
0309 V3.1 Voice activation To use voice activation, the mobile phone must support voice dialing. For details on voice dialing, please see your phone’s user’s guide. Press the Talk button once on your headset. After a short tone sounds, speak the name of the person you wish to connect (if he or she has a voice tag in your phone). -
Page 15: Transferring A Call Between Headset And Mobile Phone
0309 V3.1 To increase the volume, press the volume up button repeatedly until you reach the desired level. To decrease the volume, press the volume down button repeatedly until you reach the desired level. Transferring a Call between Headset and Mobile Phone To transfer a call from the headset to the mobile phone, initiate it from the mobile phone. -
Page 16: Headset Led Indicator
0309 V3.1 Headset LED Indicator Status Blue LED Red LED Interval Remarks Turning on 4 times Turning off 4 times Pairing mode Flashes blue and red alternatively until the pairing is complete or time out. Standby mode Once Once 3 seconds Flashes red when low battery For Nokia handsets, flashes blue three times every three... -
Page 17: Audio Tones
To transfer a call from the mobile phone to the headset when the headset is switched on after a call has been initiated, first answer the call from the phone, and then press the Talk button on the headset. The phone’s screen shows “Connect with Hello II?”. Press “Accept” to transfer the call. -
Page 18: Specifications
0309 V3.1 Specifications Standard Compliant with Bluetooth specification v1.1 Chipset BlueCore2-Audio single chipset Profile Supported Bluetooth Headset profile Radio Frequency 2402 MHz ~2480 MHz Transmitter Power Class 2 (max 4dBm) Transmission Range Up to 10 meters Receiver Sensitivity -77 dBm Charger Power Supply 5VDC / 500 mA Temperature Operating: -20°C to 60°C;... -
Page 19: Limited Warranty
Systime Corporation Limited warrants this product against defects in materials and workmanship for its warranty period. If a defect is discovered, Systime will, at its option, repair or replace the product at no charge provided it is returned during the warranty period with transportation charges prepaid to the authorized Systime dealer from whom you purchased the product. - Page 20 0309 V3.1 SYSTIME CORPORATION LIMITED Hello2.com.tw Tel: +886 2 2368-6171 17F, No. 100, Sec.2, Roosevelt Rd., Taipei 100, Taiwan, R.O.C.
