- Page 1 7” DIGITAL TFT LCD MXN71A ALL ROUND VISION MONITOR OWNER’S MANUAL...
-
Page 2: Specification
SPECIFICATION SPECIFICATION ITEM LCD Screen Size 7” Wide Diagonal Dimensions 190(W) × 142(H) × 42.85(D)mm 152.4 × 91.44mm Display dimensions Power Input DC 12 to 30 Volt Free Input 12 Watt Max. Power Consumption Video System NTSC / PAL Auto Detection Sync. -
Page 3: Operation
] button to adjust monitor volume. ▼ ▼ Use [ ] button to change OSD setting during system setting. ▼ DIMMER DAY/NIGHT SENSOR(CDS) Automatic brightness control sensor. VIEW AREA 7” DIGITAL TFT LCD ALL ROUND VISION MONITOR MXN71A OWNER’S MANUAL... -
Page 4: System Setting
SYSTEM SETTING FUNCTION DIMMER AUTO/OFF LANGUAGE ENGLISH/SWEDISH/DANISH/NORWEGIAN/DUTCH/SUOMI DIRECTION 0° SCALE 16:9 AUTO POWER AUTO/OFF/ON RESET ▶ FUNCTION >>> DIMMER (Automatic Brightness Control) Select AUTO to have Automatic or Manual brightness of the monitor. REMARK: By activating DIMMER AUTO function, the monitor adjusts the brightness according to the environment. - Page 5 Select monitor activation function as below. [AUTO] Monitor keeps the last setting in memory. [OFF] Monitor starts up『STAND-BY』mode automatically. [ON] Monitor starts up『POWER-ON』mode automatically. >>> RESET Press『▲』button to go the factory default setting. 7” DIGITAL TFT LCD ALL ROUND VISION MONITOR MXN71A OWNER’S MANUAL...
- Page 6 SYSTEM SETTING PICTURE CONTRAST 50 (0-100) BRIGHTNESS 50 (0-100) COLOR 50 (0-100) TINT 50 (0-100) PICTURE Press [ ] button to adjust preferred PICTURE of the monitor. ▲/▼...
- Page 7 TRIGGER When a trigger wire is connected to a pulse DC power signal (e.g. direction indicator lights) then the TRIGGER DELAY function avoids repeating ON/OFF monitor. >>> DIST ON/OFF 7” DIGITAL TFT LCD ALL ROUND VISION MONITOR MXN71A OWNER’S MANUAL...
- Page 8 SYSTEM SETTING DISTANCE MARKER ADJUST User can adjust location of distance marker. At Power mode, select distance marker by pressing [ ] buttons. ▲/▼ When color of distance markers is seen as color, user can adjust the lines or LEFT/RIGHT. UP/DOWN When both distance markers are seen as RED color, both lines can be adjusted LEFT/RIGHT.
- Page 9 MODE button pressed for 10 seconds to set up LOCK OFF function. UNLOCKED When is displayed on the screen, user can use all functions of the set up menu. 7” DIGITAL TFT LCD ALL ROUND VISION MONITOR MXN71A OWNER’S MANUAL...
- Page 10 CONNECTION MAIN POWER 12V/30V DC (Red) Ground (Black) Trigger 1 (Green) CAM 1 CAMERA INPUT +12V DC OUTPUT, HEATER & SHUTTER AUDIO INPUT +12V DC OUTPUT, POWER VIDEO INPUT GROUND...
- Page 11 MEMO MXN71A 7” DIGITAL TFT LCD ALL ROUND VISION MONITOR OWNER’S MANUAL...
- Page 12 7” DIGITAL TFT LCD MXN71A ALL ROUND VISION MONITOR OWNER’S MANUAL...
