Remote keypad with LCD display
for VISION series control panels
Summary
Summary
Summary
Summary
1.0. Description ......................................................................................................... 2
2.0. Connections ....................................................................................................... 2
3.0. Buttons and indicators ...................................................................................... 3
4.0. Access code ....................................................................................................... 5
4.1. Self-learning of access code ....................................................................... 5
5.0. Maintenance status .......................................................................................... 6
6.0. Disarming ............................................................................................................ 6
7.0. Total arming (DAY mode) ................................................................................. 7
8.0. Partial arming (NIGHT mode) ........................................................................... 8
9.0. Arming Test-Control (DAY mode)..................................................................... 9
10.0. Arming Test-Control (NIGHT mode) ................................................................. 10
11.0. By-passing zones ............................................................................................... 11
12.0. Tamper keypad ................................................................................................... 12
13.0. Technical characteristics................................................................................... 12
Digit-KD instruction manual
ENGLISH
Page
Page
Page
Page
Pag. 1
Advertisement
Table of Contents
Summary of Contents for Digit-KD VISION series
-
Page 1: Table Of Contents
ENGLISH Remote keypad with LCD display for VISION series control panels Summary Summary Page Page Summary Summary Page Page 1.0. Description ......................2 2.0. Connections ....................... 2 3.0. Buttons and indicators ..................3 4.0. Access code ....................... 5 4.1. Self-learning of access code ............... 5 5.0. -
Page 2: Description
ENGLISH Congratulations on your purchase of the Digit-KD, a remote keypad with LCD display for use with the VISION series control panels. The unit has been built using the most advanced microprocessor technology and production methods. Tested by means of special computerized test jig, the Digit-KD offers security and durability in time. -
Page 3: Buttons And Indicators
The signalling will remain active until the control panel is re-armed. TEST Test-control - In Maintenance mode, the LED flashes slowly. - In Programming mode, the LED flashes quickly during all phases. - The LED will light while by-passing zones and Test-control arming mode. Digit-KD instruction manual Pag. 3... - Page 4 The dots (flashing or with fixed light) on the display MAINT indicate the zones in alarm or alarm memory. In the example on the right zones 3 and 4 have been triggered and an alarm has taken place. Page 4 Digit-KD instruction manual...
-
Page 5: Access Code
ENGLISH 4.0. ACCESS CODE In order to execute the desired function of the Digit-KD, it is necessary to enter an access code and press a function button. - The code may be made from of a minimum of 1 digit to a maximum of 4 digits (from 0 to 9). -
Page 6: Maintenance Status
Bat (low battery), Tmp (tamper) and In the above example, the Firendio (fire). Next to each triggered "zone 3" has triggered an alarm zone a dot will appear that flashes slowly (see example on the right). Page 6 Digit-KD instruction manual... -
Page 7: Total Arming (Day Mode)
The flashing dots will remain vis- appear that flashes quickly. ualized only during the exit time. To remove the menu from the display, press the button "FORWARD" or wait for automatic cancellation that takes place after approximately 40 seconds. Digit-KD instruction manual Pag. 7... -
Page 8: Partial Arming (Night Mode)
To remove the menu from the display, press the button "FORWARD" or wait for automatic cancellation that takes place after approximately 40 seconds. Page 8 Digit-KD instruction manual... -
Page 9: Arming Test-Control (Day Mode)
TEST access the menu by pressing the button "FORWARD". Next to each zone that has triggered an alarm a dot will appear that flashes slowly (see on the right). "zone 3" has triggered an alarm Digit-KD instruction manual Pag. 9... -
Page 10: Arming Test-Control (Night Mode)
To verify if there have been other alarm events, access the menu by pressing the button "FORWARD". Next to each zone that has triggered an alarm a dot will appear that flashes slowly (see on the right). "zone 3" has triggered an alarm Page 10 Digit-KD instruction manual... -
Page 11: By-Passing Zones
7 and 8 are by-passed. To exit by-passing zones at any moment, press more times the button until on the display the message of control panel disarmed (OFF) will appear. Digit-KD instruction manual Pag. 11... -
Page 12: Tamper Keypad
ENGLISH 12.0. TAMPER KEYPAD The Digit-KD is protected against tampering in the case of attempts to change the control panel status with a false code. If the control panel detects for 5 consecutive times an unknown code, the keypad goes into block by ignoring all the following codes.
